Chiayo QR-2000N Operation Manual

Dual-channel modular base
Hide thumbs Also See for QR-2000N:

Advertisement

QR-2000N
Operation manual
Dual-Channel Modular Base
CHIAYO ELECTRONICS CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QR-2000N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chiayo QR-2000N

  • Page 1 QR-2000N Operation manual Dual-Channel Modular Base CHIAYO ELECTRONICS CO., LTD.
  • Page 2 BLUETOOL modules. Before operation, please read this manual thoroughly to familiarize with the function of each part and the flexibility of this versatile product. Parts and functions of QR-2000N Front 1. Power switch. 2. Channel A: RECEIVER module, also can be MP3 RECORDER, BLUETOOTH , or REPEATER module.
  • Page 3 Instructions Audio output connection  Balanced output: XLR connector provides balanced audio output signal from this jack to the mixer/amplifier. Use an audio output cable with “XLR” or “Cannon” connector, connect one end to the balanced output jack of the module, and the other end to the “MIC IN”...
  • Page 4 Rack mounting QR-2000N has a half-19"-casing design. It can be cabinet-mounted with either 1 or 2 units. Individual kits for mounting 1 or 2 QR-2000N are available and please refer to the following assembly illustration. mount 1 unit mount 2 units...
