Eagletone M10S User Manual

Operating instructions

Hold the megaphone in your hand by
1
its handle and press the yellow Power
Switch located on the inner side of the
handle with your forefinger. The power
LED on the upper side of the handle will
light up.
Set the Function Switch located above
2
the handle to the right position and hold
the MIC in a suitable position to speak
into. Your voice will be amplified.
Rotate the yellow Volume Control
located on the upper side of the handle
until you reach the desired volume.
Set the Function Switch to the left
position in order to activate the SIREN
mode.

Battery replacement

Slide out the key located at the end of
1
the handle to open the handle.
Take out the battery container and put
2
6 C type batteries in. Make sure the
polarity is correct.
Insert the battery container back into
3
the handle again paying attention to the
polarity.
Close the cover by sliding the key back
in.

Attention

• Make sure the batteries are inserted
with their polarity respected.
• Take out the batteries when the mega-
phone is not going to be used for a long
period of time.
• The batteries should be replaced as soon
as the sound volume weakens.
• The power LED lights up red to indi-
cate the batteries are low. The batteries
should be replaced or the volume should
be adjusted accordingly.
• Switch off the yellow power switch when
you are not using the megaphone. The
power led will turn off.
User's guide megaphone M10S
1
2

Technical specifications

Power output ...................................................................................... 10W
Power supply .................................... AA type (UM-3) 6 batteries (9V DC)
Operating time .................................................10 hours (Speech setting)
Receive Range ........................... 0.45km (quiet suburban), 0.25km (city)
Dimensions ..................................................... 310mm, diameter 185mm
Weight (without batteries) ............................................................... 0.9kg
Power supply switch
Microphone
Power On/Off
Function selector
Volume control
1
2
3
