Note: Most sensors will automatically identify allowing the software to set up a
default experiment. If you are using a sensor that does not auto-ID, you will need
to manually identify the sensor in the software.

LED Behavior

Power LED
State Meaning
Off Unit is off
Green Unit is on
Charging LED
State Meaning
Off Sufficient battery charge for normal use or unit is not charging
Orange Unit is charging
Green Charging is complete; battery is fully charged
Red (Flashing) Battery level is low
Red (Solid) Charging circuit timeout (~10 hr), battery fault, or no battery
found
Bluetooth LED
State Meaning
Off Blueooth connection not available
Blue (Flashing) Available for Bluetooth connection
Blue (Solid) Connected to host via Bluetooth; ready for data collection
Red Bluetooth system failed
USB LED
State Meaning
Off Not connected to USB host or no power from USB host
Orange USB connected; not communicating with software
Green Connected to host via USB; ready for data collection
Red USB host failed to enumerate or USB port underpowered
5

Specifications

Resolution
Battery
Battery life
(single full charge)
Battery life
(long term)
USB specification
Wireless specification
Maximum wireless range
Maximum sample rate (Computers via
USB)
Maximum sample rate (Wireless or
Chromebooks via USB)
Minimum sample rate
(USB or wireless)
Dimensions
Weight
Safe-use temperatures (operating)
Safe-use temperatures (storage)
Care and Maintenance
Battery
LabQuest Stream uses a high-quality lithium-ion battery. This is the same
chemistry used in premium laptop and cell phone batteries, and you can expect
similar performance.
Use the supplied AC adapter, USB cable, or optional Charging Station
(order code LQ2-CRG) to charge the battery. The battery takes 8 to 10 hours to
fully charge. The battery cannot be overcharged, and it can be safely recharged
after a partial discharge. It is safe to leave the battery charging indefinitely, and
there is no need to fully discharge the battery before needing to charge it.
The discharge time for a fully charged battery will depend on the sensors used. In
most cases, you can obtain 24 or more hours of use before recharging. We
recommend charging LabQuest Stream overnight to start the next day with a full
charge.
12 bit
High-capacity, lithium-ion rechargeable
battery
~24 hours
(varies depending on sensors used)
~500 full charge cycles
(several years depending on usage)
2.0 full speed
®
Bluetooth v4.1
30 m (unobstructed)
100,000 samples per second (one
sensor)
10,000 samples per second (two or
more sensors)
10,000 samples per second
0.00125 samples per second
(800 seconds/sample)
8.8 cm × 15.4 cm × 2.5 cm
220 g
0°C to 45°C (32°F to 113°F)
–30°C to 60°C (–22°F to 140°F)
