Summary of Contents for Audiolab MAGNA 121A

  • Page 1 USER MANUAL MAGNA 121A Self-powered subwoofer – 1 x 21” P. 1 - AUDIOLAB Magna 121A...
  • Page 2: Specifications

    Thanks to its D-type amplification, the equipment • 1 XLR-3/Plug combo achieves great power with a very good sound • 1 XLR-3 quality and a very low weight design. Magna 121A • Output: 2 XLR-3 has a frequency response ranging from 40Hz • Link: 2 XLR-3 to 120Hz and has a control panel that allows •...
  • Page 3: Safety Related Symbols

    Describes precautions that should be observed to collection. prevent damage to the product. Before replacing the fuse, make sure that the 1. Read this Manual carefully before operation. product is OFF and disconnected from AC outlet. P. 3 - AUDIOLAB Magna 121A English version...
  • Page 4 The apparatus shall be connected to a mains sock- et outlet with a protective earthing connection. The mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. P. 4 AUDIOLAB Magna 121A - English version...
  • Page 5: Back Panel Description

    5. Left line mono input Combo connector 13. Power and activity indicator green LED 6. Right line input XLR connector 14. Voltage selector 7. High pass filter or bypass selector 8. Normal/Reverse phase switch (Polarity) P. 5 - AUDIOLAB Magna 121A English version...
  • Page 6: Connection Plate

    Out Left/Right, and the other side of the cable nets, then the mixer. into the Line Input Left/Right of your active Line Line Input Input Pole Pole Main Out Right Main Out Left Line in Line in Left/Mono Right/Mono Mixer P. 6 AUDIOLAB Magna 121A - English version...
  • Page 7: Frequency Response Diagram

    For 1/4" Phone jack Ring Ring Sleeve Sleeve Sleeve TS Type Unbalanced TRS Type Balanced TRS Type Unbalanced P. 7 - AUDIOLAB Magna 121A English version...
  • Page 8 Unbalanced Ring Sleeve Tip Ring Sleeve Sleeve Tip Sleeve Center Screen Sleeve Sleeve Tip Sleeve Sleeve Tip Ring Ring Sleeve Sleeve Tip Ring Sleeve Sleeve Ring Tip Center Sleeve Screen Tip Sleeve P. 8 AUDIOLAB Magna 121A - English version...
  • Page 9 The responsibility of AMPRO by any defective • Deteriorations produced by the course of the product is limited the repair of the replace- P. 9 - AUDIOLAB Magna 121A English version...
  • Page 10 Note: The supplier will not assume responsibility for errors or omissions in the manual. The information in this manual is subject to change without prior notice. P. 10 AUDIOLAB Magna 121A - English version...
  • Page 11: Especificaciones

    Gracias a su amplificación de tipo D, el equipo alcanza una gran potencia con una muy Conectores buena calidad de sonido y un diseño de muy bajo peso. Magna 121A cuenta con una respuesta de • Entrada: frecuencia que va desde los 40Hz hasta los 120Hz •...
  • Page 12: Instrucciones De Seguridad

    Esto prevendrá el riesgo ON: Equipo encendido. de choque eléctrico. Nunca corte los cables in- ternos o externos. Asímismo, nunca remueva la OFF: Equipo apagado. conexión a tierra. P. 12 AUDIOLAB Magna 121A - Versión Español...
  • Page 13 Son diseña- dos teniendo en cuenta su seguridad. No quite la conexión a tierra! 0,25 o Concierto de rock Conecte el equipo a un tomacorriente cercano, de menos P. 13 - AUDIOLAB Magna 121A Versión Español...
  • Page 14: Descripción Del Panel Trasero

    10. Conector de salida de línea XLR Dere- cha/Izquierda 11. Selector de Punto de Crossover 60Hz/80Hz/100Hz 12. Luz indicadora de señal y limitación (Luz Roja) 13. Indicador de Encendido Verde y de Actividad 14. Selector de voltaje de entrada P. 14 AUDIOLAB Magna 121A - Versión Español...
  • Page 15: Diagrama De Conexiones

    *Si se utiliza la salida "Left/Right" ro el gabinete activo y después el mezclador. Entrada Entrada Línea Línea Pedestal Pedestal Salida Principal Salida Principal Izquierda Derecha Entrada Línea Entrada Línea Derecha/Mono Izquierda/Mono Mezclador P. 15 - AUDIOLAB Magna 121A Versión Español...
  • Page 16: Respuesta De Frecuencia

    Los siguientes son unos ejemplos de cómo se pueden alambrar estos conectores: Para 1/4" Phone jack Ring Ring Sleeve Sleeve Sleeve TS Type No balanceado TRS Type Balanceado TRS Type No balanceado P. 16 AUDIOLAB Magna 121A - Versión Español...
  • Page 17 No balanceado Ring Sleeve Tip Ring Sleeve Sleeve Tip Sleeve Center Screen Sleeve Sleeve Tip Sleeve Sleeve Tip Ring Ring Sleeve Sleeve Tip Ring Sleeve Sleeve Ring Tip Center Sleeve Screen Tip Sleeve P. 17 - AUDIOLAB Magna 121A Versión Español...
  • Page 18 Esta unidad podrá presentarse para su repa- unidad. ración, junto a la factura de compra (o cualquier • daños ocasionados por la presencia de arena, otro comprobante donde conste la fecha de P. 18 AUDIOLAB Magna 121A - Versión Español...
  • Page 19 Observación: El proveedor no asumirá responsabilidad por los errores u omisiones del manual. La información de este manual está sujeta a cambios sin previo aviso. P. 19 - AUDIOLAB Magna 121A Versión Español...
  • Page 20 P. 20 AUDIOLAB Magna 121A -...
