2. SAFETY PRECAUTIONS

Warnings
• This unit is intended for indoor user only.
• Do not allowa for any flammable liquids, water,
or metal objects to enter the unit.
• To reduce the risk of fire or electric shock, do
not expose the unit to rain or high levels of
moisture.
• No user serviceable parts inside, do not dis-
mantle the unit yourself.
• Repairs must be done by qualified personnel
only.
• Please do not allow children to play and tamper
with this product.

3. FRONT PANEL OVERVIEW

1
1. Fixture buttons (1-12): Used to select relevant
fixtures for control.
2. Channel faders (1-8): Used to control the output
of each corresponding fixture channel.
3. Channel Bank button: Used to switch between
9
2
Cautions
• When unpacking, please ensure that the unit
is not damaged. Should something be wrong,
please contact us immediately.
10 11
3 4 5 6 7
channels 1-8, 9-16, 17-24 and 25-32).
4. Speed fader: Used to adjust chase speed (range
is 0.1 second to 10 minutes per step).
5. Fade Time fader: Used to adjust chase fade
time (range is 0 to 30 seconds).
12
13
14-19
8
