Heatmaster HMVF-R 24LP Installation And Operating Instructions Manual

Natural & lp gas unvented gas log heater
Hide thumbs

Advertisement

Table of Contents

Installation and Operating Instructions for Natural & LP Gas
State and local codes may only allow operation of this appliance in a vented configuration. Check your local and state codes.
WARNING: FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY AND WITHOUT
ERROR OR FAILURE TO HEED ANY AND ALL WARNINGS IN THESE INSTRUCTIONS CAN
RESULT IN AN EXPLOSION, FIRE OR THE PRODUCTION OF CARBON MONOXIDE GAS
WHICH CAN CAUSE PROPERTY DAMAGE, BODILY INJURY OR DEATH.
WARNING
or explosion may result, causing property damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch.
•
Do not use any telephone in your building.
•
Immediately call your gas supplier from a neighbor's telephone.
•
Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is in-
stalled. Provisions for adequate combustion and ventilation air must be provided. Refer to
page 8.
"This appliance may be installed in an aftermarket, permanently located, manufactured (mobile)
home, where not prohibited by local codes. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not convertible for use with other gases."
IMPORTANT: READ INSTRUCTIONS CAREFULLY BEFORE
BEGINNING INSTALLATION OF THIS ROOM HEATER.
INSTALLER: Leave this manual with the appliance.
IM-115
CONSUMER: Retain this manual for future reference.
10/2018
Unvented Gas Log Heater
HMVF-R-24 & 30/36"
HMVF-IPI-ECO 24" & 30/36"
ANSI Z21.11 2-2016 APPROVED / ANSI Z21.60 -2017 CSA 2.26 2017
If the information in this manual is not followed exactly, a fire
This appliance is intended for supplemental heating.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HMVF-R 24LP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heatmaster HMVF-R 24LP

Summary of Contents for Heatmaster HMVF-R 24LP

  • Page 1 Installation and Operating Instructions for Natural & LP Gas Unvented Gas Log Heater HMVF-R-24 & 30/36” HMVF-IPI-ECO 24” & 30/36” ANSI Z21.11 2-2016 APPROVED / ANSI Z21.60 -2017 CSA 2.26 2017 State and local codes may only allow operation of this appliance in a vented configuration. Check your local and state codes. WARNING: FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY AND WITHOUT ERROR OR FAILURE TO HEED ANY AND ALL WARNINGS IN THESE INSTRUCTIONS CAN RESULT IN AN EXPLOSION, FIRE OR THE PRODUCTION OF CARBON MONOXIDE GAS...
