Subject: P0052 Bed Locator Installation Instructions
Tools required:
Standard drill
Phillips head screwdriver
5/16" hex nut driver
Level
As-built drawings
Safety glasses
Dustpan
Parts required:
(1)
(1)
(4)
(1)
(1)
(1)
149814, Bag assembly, Bed Locator, includes these items:
(6)
(6)
(4)
(9)
(6)
(6)
(3)
(2)
(4)
(4)
(8)
(4)
(2)
(12)
1. Basis® is a registered trademark of WittRock Healthcare Services, Inc.
© 2013 by WittRock Healthcare Services, Inc. ALL RIGHTS RESERVED.
No part of this text shall be reproduced without written permission from WittRock Healthcare
Services, Inc. May 14, 2013
131617
Installation guide bracket
149814
Bag assembly, Bed Locator
50590
Screw, #6-20, oval, cross head, recessed
P005270
Flatwall Headwall System interconnect (for
units installed with the Flatwall Headwall
System only)
P2102AT0052B
Basis®
units installed with the Basis® Headwall
System only)
M21020069
Bag assembly, Bed Locator 1 gang mud ring
16114
Screw, #6-32 x ½", phillips, flat head, zinc-
plated, full thread
29591
Screw, #8, self-drilling
5294502
Screw, #6 x 3/8", type B, truss head
5314301
Screw, #12—self-drilling, hex head
55408
Grommet edging, 2"
55409
Grommet edging, 3"
55691PL
Face ring, wall box
50854-03
Screw
57185
Wall anchor
55138
Screw (for wall anchor)
16115
Screw (installed on assembled bed locator)
50590
Screw (installed on assembled bed locator)
3869
Washer
52553
Cable tie
1/4" and 5/8" diameter drill bits
Screwdriver
Tape measure
Power screwdriver
Stud finder
Broom
Pencil
1
Headwall System interconnect (for
150685 REV 4
Page 1 of 38

Advertisement

loading
Need help?

Need help?

Do you have a question about the P0052 and is the answer not in the manual?

Questions and answers

Related Manuals for WittRock P0052

Summary of Contents for WittRock P0052

  • Page 1 1. Basis® is a registered trademark of WittRock Healthcare Services, Inc. © 2013 by WittRock Healthcare Services, Inc. ALL RIGHTS RESERVED. No part of this text shall be reproduced without written permission from WittRock Healthcare Services, Inc. May 14, 2013...
  • Page 2 • Flatwall Headwall System (P670E) • ImageBuilders® Cabinet Headwall Collection (P796) • Basis® Headwall System (P2102A) 1. ImageBuilders® and Basis® are registered trademark of WittRock Healthcare Services, Inc. Page 2 of 38 150685 REV 4 May 14, 2013...
  • Page 3 (see Figure-8) is powered by a factory installed 12 V DC, 500 ma fuse limited, WittRock Healthcare 149425 Power Supply Unit (Rated Input: 120/240 V AC, 2 A, 50/60 Hz). This 15 Watt ITE power supply may also be used as a remote DC power source in WittRock Healthcare speci-fied applications.
  • Page 4 A est conforme à la norme NMB-003 du Canada. NOTE: Changes or modifications to equipment not expressly approved in writing by WittRock Healthcare could void the user's authority to operate the equipment. Setup Before you start the installation, refer to the as-built drawings to determine the correct location for the bed locator.

  • Page 5: Hardware Requirements

    • Seismic walls are constructed to prevent damage from an earthquake. • Fire-rated walls are constructed to prevent the spread of fire. Do one of these: • For seismic walls, install wall backing plates according to the Office of Statewide Health, Planning, and Development (OSHPD)-approved drawings and the as-built drawings, and then go to “Hardware Requirements”...
  • Page 6 Table 1. Seismic-Rated and Fire-Rated Dry Wall Hardware Item Part Number Description 5314301 Screw, #12-14 x 1 ½", self-drilling, hex head 29591 Screw, #8-18 x ½", self-drilling 16114 Screw, #6-32 x ½", phillips, flat head, zinc- plated 5294502 Screw, #6 x 3/8", type B, truss head 12483 Lockwasher, #8 dish-type 15359...
  • Page 7 If you install the bed locator with a Flatwall Headwall System or Basis® Headwall System, get the hardware from the interconnect module. Removal of the Plastic Cover from the Backplate Assembly Remove the two screws (E) that attach the face plates (AN) through the plastic cover (D) to the backplate assembly (R).
  • Page 8 • If you install the bed locator with the Flatwall Headwall System, go to “Install the Bed Locator with the Flatwall Headwall System” on page 13. • If you install the bed locator on the ImageBuilders® Cabinet Headwall Collection, go to “Install the Bed Locator on the ImageBuilders® Cabinet Headwall Collection”...
  • Page 9 Install the Bed Locator as a Stand-Alone Unit Install the flat head screws (F) to attach the face rings (P) on the line voltage and low voltage wall boxes (Q) (see figure 3 on page 9). Figure 3. Backplate Assembly and Installation Guide Bracket Remove the knockouts from the backplate assembly (R) that align with the wall boxes (Q).
  • Page 10 Figure 4. Bed Locator—Typical Installation Dimensions Page 10 of 38 150685 REV 4 May 14, 2013...
  • Page 11 Measure 23 7/8" (60.64 cm) from the floor line (T) up the wall, and make a mark to show the location on the bed centerline (S). Make a plumb line at least 20" (51 cm) on both sides of the mark to show the horizon- tal centerline (U) of the mounting holes.
  • Page 12 WARNING: Wear eye protection. Failure to do so could cause eye injury. Put on safety glasses. Do one of these: • If the wall has a metal backplate, choose three knockouts to create holes near the left edge, center, and right edge of the backplate assembly. •...
  • Page 13 Install the Bed Locator with the Flatwall Headwall System Mark the bed centerline (S) (see figure 5 on page 13): If a finished floor has not been installed, make a mark to show the location of the intended finished floor line (T). Make a plumb vertical bed centerline (S) on the wall 25"...
  • Page 14 WARNING: Failure to wear eye protection could cause eye injury. Put on safety glasses. Align the installation guide bracket (Z) with the lines (S) and (Y). Install three #12 self-drilling screws (A) at a location free from obstruction to attach the installation guide bracket (Z) to the wall (see figure 6 on page 14).
  • Page 15 WARNING: Do not leave the backplate assembly unattended in the installation guide bracket and not attached to the wall. The backplate assembly could fall and cause injury or equipment damage. Put the backplate assembly (R) in the installation guide bracket (Z). Slide the backplate assembly (R) flush with the headwall assembly (AB).
  • Page 16 WARNING: Make sure the self-drilling screws go through the wall stud or backing plate. Failure to do so could cause injury or equipment damage. Install two #12 self-drilling screws (A) to attach the lower flange (BB) to the wall studs or backing plate at a location free from obstruction (except for 20-gauge mini- mum thick steel studs).
  • Page 17 Install the Bed Locator on the ImageBuilders® Cabinet Headwall Collection Find the openings in the front of the center cabinet (AK) (see figure 7 on page 19). Halfway between the two rows of openings, make a vertical plumb line to show the bed centerline (S).
  • Page 18 Measure 16" (41 cm) from the bed centerline (S) on each side of the center cabinet (AK), and make marks to show the location of the lowest raceway (AA) of the back- plate assembly (R). At the marks, drill a 3/16" (4.75 mm) hole through the back of the backplate assembly (R) at a location free from obstruction.
  • Page 19 Figure 7. Center Cabinet May 14, 2013 150685 REV 4 Page 19 of 38...
  • Page 20 Install the Medical Headboard as a Stand-Alone Unit Install the flat head screws (F) to attach the face rings (P) on the line voltage and low voltage wall boxes (Q) (see figure 8 on page 20). Figure 8. Backplate Assembly and Installation Guide Bracket Remove the knockouts from the backplate assembly (R) that align with the wall boxes (Q).
  • Page 21 Make a plumb line at least 20" (51 cm) on both sides of the mark to show the horizon- tal centerline (U) of the mounting holes. Measure 23" (58 cm) for the Medical Headboard from the floor line (T) up the wall, and make a mark to show its location on the bed centerline (S).
  • Page 22 Figure 9. Medical Headboard—Typical Installation Dimensions Page 22 of 38 150685 REV 4 May 14, 2013...
  • Page 23 Install the Bed Locator with the Basis® Headwall System Prepare the Basis® Headwall System for the Bed Locator Connection Remove the filler strip (BC) from the bottom access panel (BD) of the headwall (see figure 10 on page 23). Remove the four screws (BE) that attach the access panel (BD) to the headwall frame. NOTE: On a headwall with devices, it may be necessary to remove the backbox and backplate so that you can put the wiring and conduit through to the bed locator.
  • Page 24 Measure 26 3/32" (66.28 cm) from the floor line (T) up the wall, and make a mark to show its location on the bed centerline (S). Figure 11. Typical Installation Dimensions At the mark on the bed centerline (S), make a plumb line from the side of the headwall (AB) at least 47"...
  • Page 25 Install three #12 self-drilling hex head screws (A) at a location free from obstruction (except for 20-gauge minimum thick steel studs) to attach the installation guide bracket (Z) to the wall (see figure 12 on page 25). Figure 12. Headwall Interconnect Remove the face plate (AN), plastic cover (D) and front panel (AM) from the back- plate assembly (R) (refer to “Removal of the Plastic Cover from the Backplate Assembly”...
  • Page 26 • If the wall has studs, choose three knockouts or create holes that align with studs near the left edge, center, and right edge of the backplate assembly (R). WARNING: Make sure the self-drilling screws go through the wall stud or backing plate. Failure to do so could cause injury or equipment damage.
  • Page 27 WARNING: Completely tighten the #10-24 screw assembly in the wall. Failure to do so could cause injury or equipment damage. Completely tighten the #10-24 screw (J). WARNING: In accordance with NFPA 70, do not mix different services, such as critical power, low voltage, or normal power, in the same raceway level of the back- plate assembly.
  • Page 28 Install the Bed Locator as a Stand Alone Unit on the Wall Panel System Install the flat head screws (BG) to attach the face ring (BH) on the line voltage and low voltage wall box (Q) (see figure 13 on page 28). Figure 13.
  • Page 29 f. Put the wall panel (BJ) into position on the Wall Panel System. Remove the knockouts from the locator’s backplate assembly (R) that align with the wall panel cutout (BJ). Install the grommet edging around the removed knockout. Make a mark to show the bed centerline (S) (see figure 14 on page 30): Refer to the as-built drawings, and determine the bed centerline (S) as it relates to the backplate assembly (R).
  • Page 30 Figure 14. Bed Locator—Typical Installation Dimensions Page 30 of 38 150685 REV 4 May 14, 2013...
  • Page 31 WARNING: Wear eye protection. Failure to do so could cause eye injury. Put on safety glasses. Install three 1/4" self-drilling screws (BM) at a location free from obstruction (except for 20-gauge minimum thick steel studs) to attach the installation guide bracket (Z) to the wall panel (BI) and wall (see figure 13 on page 28).
  • Page 32 WARNING: Make sure the self-drilling screws go through the wall stud or backing plate. Failure to do so could cause injury or equipment damage. At the mounting holes (X) (see figure 14 on page 30), install three 1/4" self-drilling screws (BM) at a location free from obstruction (except for 20-gauge minimum thick steel studs) to attach the backplate assembly (R) to the wall studs or backing plate (see figure 13 on page 28).

  • Page 33: Final Steps

    Final Steps Refer to the as-built drawings, and determine the bed locator’s internal wiring configuration and hook-up information. WARNING: Failure to connect the electrical wiring correctly could cause injury or equip- ment damage. Have the electrical contractor connect all the wiring from the wall boxes (Q) to the backplate assembly (R) according to the applicable national, state or provincial, and local codes, and these (see figure 3 on page 9): For USA installations National Fire Protection®...
  • Page 34 Medical Headboard Cover Install the four screws (AH) to attach the front panel (AM) on the backplate assembly (R) (see figure 15 on page 34). Install the plastic cover (D). Mark the locations on the wall for wall anchors (N) using the holes (AO) on the bot- tom edge of the plastic cover (D).
  • Page 35 Bed Locator Cover Install the four screws (AH) to attach the front panel (AM) on the backplate assembly (R) (see figure 16 on page 35). Install the plastic cover (D). Install the screws (E) to attach the face plates (AN) to the backplate assembly (R) through the plastic cover (D).
  • Page 36 Flatwall Headwall System Cover Install the two truss head screws (G) to attach the raceway cover (AJ) to the backplate (AC) (see figure 17 on page 36). Install a truss head screw (G) and lockwasher (H) to attach the ground wires (AI) to the backplate assembly (R).
  • Page 37 Basis® Headwall System Covers Install the cover (BF) on the interconnect backplate (AC) (see figure 18 on page 37). Install the four screws (G) to attach the cover (BF) to the interconnect backplate (AC). Figure 18. Interconnect Cover Put the access panel (BD) into position on the headwall frame, and install the four screws (BE) to attach the access panel to the headwall (see figure 10 on page 23).
  • Page 38 NOTES: Page 38 of 38 150685 REV 4 May 14, 2013...
