Curtiss-Wright POP-A-PLUG SYSTEM Operating Instructions Manual

EST GROUP
ORIGINAL INSTRUCTIONS
HYDRAULIC RAM PACKAGE OPERATING INSTRUCTIONS
EST Group Hydraulic Ram Package consist of an Air Activated Hydraulic Pump, a High
Pressure Hydraulic Hose with quick connects, and a Hydraulic Ram. EST Group Ram Kits are
used for installation and removal of Pop-A-Plug Heat Exchanger Tube Plugs manufactured by
Operating Instructions for:
Part Number
PAP-6600-SIL
PAP-123-RK
PAP-1750
Workstation Sound Pressure Level: 84 dB(A) at Rated Capacity
Authorized European Distributor: EST Group B.V. Hoorn 312a, 2404 HL Alphen aan den Rijn, The Netherlands.
Questions? Contact EST Group Customer Service at any of the following locations.
www.cw-estgroup.com
POP-A-PLUG
Curtiss-Wright EST Group.
Description
Small Ram Package
Medium Ram Package
Large Ram Package
Operation Air Pressure: 90 – 120 PSIG (6.2 – 8.2 BARG)
MAX Pump Pressure: 7500 PSIG (517 BARG)
Year of Construction: _____
North, Central & South America
EST Group Corporate Office
2701 Township Line Road
Hatfield, PA 19440-1770 USA
P: +1.215.721.1100
+1.800.355.7044
F: +1.215.721.1101
est-info@curtisswright.com
®
SYSTEM
Components Description
PAP-6605 5 Ton Ram Assembly
PAP-1010 Hose Assembly
PAP-1000 Pump Assembly
PAP-123-RA 12 Ton Ram Assembly
PAP-1010 Hose Assembly
PAP-1000 Pump Assembly
PAP-1755 17.5 Ton Ram Assembly
PAP-1010 Hose Assembly
PAP-1000 Pump Assembly
Updated at date of mfg.
Europe / Middle East / Africa
EST Group B.V.
Hoorn 312a
2404 HL Alphen aan den Rijn
The Netherlands
P: +31.172.418841
F: +31.172.418849
est-emea@curtisswright.com
DC4042 06/18
PAGE 1 OF 6
China
P +86.400.636.5077
est-china@curtisswright.cn
Singapore
P +65.3158.5052
est-asia@curtisswright.com
©2018 Curtiss-Wright
