- Page 1 FW-IOB-T-120/208VAC Input/Output/Bypass Assembly Installation Instructions...
- Page 2 Charger and a second AC source, facilitating maintenance and power continuity. About OutBack Power Systems OutBack Power Systems is a leader in advanced energy conversion technology. Our products include true sine wave inverter/chargers, a maximum power point charge controller, system communication components, as well as breaker panels, breakers, accessories, and assembled systems.
- Page 3 Requirements and Warnings The OutBack FW-IOB-T-120/208VAC is intended as a system component and is included in a listing by ETL as indoor enclosures to UL standard UL 508A Industrial Control Panels. This enclosure is intended for battery circuits configured for 12 to 48 volts nominal. Grounding Instructions –...
- Page 4 FW-IOB-T-120/208VAC Parts List AC Breakers Bus Bars Red Terminal Black Terminal Blue Terminal Bus Bar Insulators Bus Bar Insulators Bus Bar Insulators White Terminal Bus Bar Insulators AC Breaker Bypass Breaker Slide Plate Label Kit Hardware Kit Neutral Conductor Hot Conductors Ground Conductor Hot Conductor Hot Conductor...
- Page 5 Figure 2: Placement of Bus Bars...
- Page 6 Figure 3: Sample Wiring Diagram...
- Page 7 Installing the FW-IOB-T-120/208VAC Bypass Breakers Output Breakers Input Breakers (installed upside down) Figure 4: AC Breaker Installation for FW-IOB-T-120/208VAC To install the FW-IOB-T-120/208VAC: • Remove the appropriate quantity of breaker knockouts from the breaker bracket. • Pull the yellow tabs out from each breaker. •...
- Page 8 Installing the AC Breaker Bypass Slide Plate Figure 5: AC Breaker Bypass Slide Plate Installation Parts: 1. 8-32 X .75 Machine Screw (2) 2. Nylon Washer (4) 3. 8-32 Nylock Nut (4) 4. AC Breaker Bypass Slide Plate (1) 5. FLEXware AC Breaker Bracket (1) To Assemble: 1.
