Outback Power Systems Power Systems FW-IOB-D-120VAC Installation Instructions Manual

Input/output/bypass assembly

Advertisement

T M
FW-IOB-D-120VAC
Input/Output/Bypass Assembly
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Systems FW-IOB-D-120VAC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Outback Power Systems Power Systems FW-IOB-D-120VAC

  • Page 1 FW-IOB-D-120VAC Input/Output/Bypass Assembly Installation Instructions...
  • Page 2: Contact Information

    About OutBack Power Systems OutBack Power Systems is a leader in advanced energy conversion technol- ogy. Our products include true sine wave inverter/chargers, a maximum power point charge controller, system communication components, as well as breaker panels, breakers, accessories, and assembled systems.
  • Page 3 Requirements and Warnings The OutBack FW-IOB-D-120VAC is intended as a system compo- nent and is included in a listing by ETL as indoor enclosures to UL standard UL 508A Industrial Control Panels. This enclosure is intended for battery circuits confi gured for 12 to 48 volts nominal.
  • Page 4 FW-IOB-D-120VAC Parts List AC Breaker Bypass Breaker Label Set Slide Plate AC Breakers Hardware Kit Ground Conductor Neutral Conductor (Green) (White) Figure 1: FW-IOB-D-120VAC Black Terminal Bus Bar Insulators White Terminal Bus Bar Insulators Bus Bars Positive Conductor (Black)
  • Page 5 AC IN HOT LEG 1, BLACK INSULATORS GROUND BUS BAR AC NEUTRAL INPUT AND OUTPUT, WHITE INSULATORS NOTE: Use 10-32 X 7/16 self-tapping stainless steel fasteners to secure this hardware. Figure 2: Placement of Bus Bars AC OUT HOT LEG 1, BLACK INSULATORS...
  • Page 6 Figure 3: Sample Wiring Diagram...
  • Page 7 Installing the FW-IOB-D-120VAC Dual-Pole Bypass Breaker Output Breakers Input Breakers (installed upside down) Figure 4: AC Breaker Installation for FW-IOB-D-120VAC To install the FW-IOB-D-120VAC: • Remove the appropriate quantity of breaker knockouts from the breaker bracket. • Pull the yellow tabs out from each breaker. •...
  • Page 8 Installing the AC Breaker Bypass Slide Plate Figure 5: AC Breaker Bypass Slide Plate Installation Parts: 1. 8-32 X .75 Machine Screw (2) 2. Nylon Washer (4) 3. 8-32 Nylock Nut (4) 4. AC Breaker Bypass Slide Plate (1) 5. FLEXware AC Breaker Bracket (1) To Assemble: 1.
