ENGLISH Digital Video Camcorder SCD5000 Auto Focus Charge Coupled Device Liquid Crystal Display Owner’s Instruction Manual Before operating the unit, please read this instruction manual thoroughly, and retain it for future reference. ELECTRONICS US PATENT 4415844...
Page 2
FCC Warning Class B Computing Device Information to the User This Equipment has been tested and found to comply with the limits for a class B digital device pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
OSD (On Screen Display in CAMERA / M.PLAY Modes) ............................23 Turning the OSD on/off (On Screen Display) ..............................24 Preparation How to use the Remote Control(SCD5000 only) ..............................25 Battery Installation for the Remote Control ................................25 Self Record using the Remote Control ................................25 Adjusting the Hand Strap ......................................
Page 4
Set the Camcorder to CAMERA or PLAYER Mode and M.REC or M.PLAY Mode ................... 40 Availability of Functions in CAMCORDER Mode..............................41 CLOCK SET ......................................... 42 WL.REMOTE(SCD5000 only) ....................................43 DEMONSTRATION ......................................44 DATE/TIME ........................................... 45 TV DISPLAY ......................................... 46 EASY Mode (for Beginners) .....................................
Page 5
Fade In and Out ........................................71 To Start Recording ....................................... 71 To Stop Recording (use FADE IN / FADE OUT) ..............................71 Audio Dubbing(SCD5000 only) ....................................72 Dubbing Sound ........................................72 Dubbed Audio Playback ...................................... 73 PHOTO Image Recording ......................................74 Searching for a PHOTO Picture ..................................
Page 6
Playback Pause ........................................80 Picture Search (Forward/Reverse) ..................................80 Slow Playback (Forward/Reverse)(SCD5000 only) ............................80 Frame Advance (To Play back Frame by Frame)(SCD5000 only) ........................81 ZERO MEMORY(SCD5000 only) ..................................... 82 PB DSE (Playback Digital Special Effects) ................................83 PB ZOOM ..........................................84 IEEE 1394 Data Transfer Transferring usingIEEE1394 (i.LINK)-DV Standard Data Connections ........................
Page 7
ENGLISH Advanced Technic FOCUS LOCK ........................................... 96 Digital Zoom in CAMERA Mode ....................................97 MACRO Mode ........................................... 98 CONT. SHOT (Continuous Shot) ....................................99 Using the FLASH ........................................100 FLASH SELECT ........................................101 WHT. BALANCE (WHITE BALANCE) - CAMERA Mode ............................102 DSE(Digital Special Effects) SELECT in CAMERA Mode .............................
Page 8
ENGLISH USB Interface Transferring a Digital Image through a USB Connection ............................120 System Requirements ......................................120 Installing the DVC Media 5.0 Program ..................................121 Connecting to a PC ........................................122 Maintenance After Finishing a Recording ..................................... 123 Cleaning and Maintaining the Camcorder ................................124 Cleaning the Video Heads ....................................
Do not use the flash close to another's eyes. The flash emits a strong light that may cause damage similar to direct sunlight on one's eyesight. If the device is out of order, please consult your nearest dealer or authorized Samsung service facility. Disassembling the device yourself may cause irrecoverable damagewhich will be difficult to repair.
ENGLISH Start Quick Start ✤ This device provides a variety of functions because it is a Camcorder and Digital Still Camera in one system. Please read this manual thoroughly. ✤ Before using the device, install the accessories in the following order: 1.
ENGLISH Notes and Safety Instructions Notes Regarding the Rotation of the LCD Screen Please rotate the LCD screen carefully as illustrated. Over rotation may cause damage to the inside of the hinge that connects the LCD screen to the Camcorder. 1.
Page 12
ENGLISH Notes and Safety Instructions Notices Regarding COPYRIGHT Television programs, video tapes, DVD titles, films, and other program materials may be copyrighted. Unauthorized copying of copyrighted material may be against the law. Notes Regarding Moisture Condensation 1. A sudden rise in atmospheric temperature may cause moisture condensation to form inside the camcorder. For Example: - When you take the camcorder from a cold place to a warm place (e.g.
Page 13
ENGLISH Notes and Safety Instructions Notes Regarding the Battery Pack - Make sure that the battery pack is fully charged before starting to record. - To preserve battery power, keep your camcorder turned off when you are not operating it. - If your device is in CAMCORDER mode with a tape installed, and it is left in STBY mode without being operated for more than 5 minutes it will automatically turn itself off to protect against unnecessary battery discharge.
Page 14
ENGLISH Notes and Safety Instructions Note Regarding the LENS - Do not film with the camera lens pointing directly at the sun. Direct sunlight can damage the CCD(Charge Coupled Device). Notes Regarding Electronic Viewfinder 1. Do not position the camcorder such that the viewfinder is pointing towards the sun. Direct sunlight can damage the inside of the viewfinder.
Page 15
ENGLISH Notes and Safety Instructions Precautions Regarding the Lithium battery 1. The lithium battery maintains the clock function and user settings; even if the battery pack or AC adapter is removed. 2. The lithium battery for the camcorder lasts about 6 months under normal operation from the time of installation. 3.
ENGLISH Getting to Know Your Device Features • Digital data transfer function with IEEE1394 By incorporating the IEEE 1394 (i.LINK™ : i.LINK is a serial data transfer protocol and interconnectivity system, used to transmit DV data) high speed data transport port, both moving and still images can be transferred to a PC, making it possible to produce or edit various images.
ENGLISH Getting to Know Your Device Right & Top View 5. Zoom Lever 1. PHOTO button 2. Viewfinder button 3. START/STOP 4. Power switch 1. Photo Button 4. Power switch 2. Viewfinder 5. Zoom Lever 3. Start/Stop Button...
ENGLISH Getting to Know Your Device Rear & Bottom View 1. Function Button FADE 13. TAPE EJECT S.SHOW 12. Tripod receptacle DELETE 2. Speaker 11. MACRO Button 3. Hook for shoulder strap 4. DC Jack 8. AV/S-Video 5. USB Jack 7.
1 2 : 0 0 AM O C T . 1 0 . 2 0 0 3 E N T E R : 25. Self Recording and Waiting Timer (See page 25) (SCD5000 only) VOL. [ 1 1 ] 26. EIS (See page 60) 27.
ENGLISH Getting to Know Your Device OSD (On Screen Display in CAMERA/M.PLAY Modes) 1. Battery Level (See page 28) OSD in CAMERA mode 2. DSE (Digital Special Effects) Mode (See page 103) 3. SPOT AE Mode (See page 105) 4. Focus Area 5.
ENGLISH Getting to Know Your Device Turning the OSD ON/OFF (On Screen Display) Turning OSD ON/OFF Press the DISPLAY button. - Each press of the button toggles the OSD function ON and OFF. - When you turn the OSD OFF, In CAMCORDER / CAMERA mode: The STBY, REC, EASY.Q modes are always displayed on the OSD, even when the OSD is turned OFF.
ENGLISH Preparation How to use the Remote Control(SCD5000 only) Battery Installation for the Remote Control ✤ You need to insert or replace the lithium battery when : - You purchase the camcorder. - The remote control doesn’t work. ✤ Make sure that you insert the lithium cell correctly, following the + and - markings.
ENGLISH Preparation Adjusting the Hand Strap It is very important to ensure that the Hand Strap has been correctly adjusted before you begin recording. The hand strap enables you to : - Hold the camcorder in a stable, comfortable position. - Press the Zoom START/STOP, and PHOTO button without having to change the position of your hand.
ENGLISH Preparation Connecting a Power Source There are two types of power sources that can be connected to your camcorder. - The AC Power Adapter with the AC cord : used for indoor recording. - The Battery Pack : used for outdoor recording. To Use the AC Power Adapter and DC Cable 1.
ENGLISH Preparation Using the Lithium Ion Battery Pack ✤ The amount of continuous recording time available depends on : - The type and capacity of the battery pack you are using. - How often the Zoom function is used. It is recommended that you have several batteries available. Charging the Lithium Ion Battery Pack 1.
ENGLISH Preparation Using the Lithium Ion Battery Pack Table of Continuous Recording Time Based on Model and Battery Type. ✤ If you close the LCD screen, it switches off and the viewfinder switches on automatically. ✤ The continuous recording times given in the table above are approximations. Actual recording time depends on usage.
ENGLISH Preparation Battery Level Display • The battery level display indicates the amount of power remaining in the battery pack. a. Fully Charged b. 20~40% Used c. 40~80% Used d. 80~95% Used e. Completely Used (flickers) (The device will turn off soon, change the battery as soon as possible) ✤...
ENGLISH Preparation Setting to CAMCORDER / CAMERA modes ✤ This device is switched between the DVC (Digital Video Camcorder) mode and the DSC (Digital Still Camera) mode by revolving the Lens Body Block. ✤ Switching between CAMCORDER/CAMERA Modes To set your device to CAMERA Mode from CAMCORDER Mode: Rotate the Lens Body Block 180° counterclockwise while pressing the Rotation Release Button (Left View).
ENGLISH Preparation Setting the Power Switch ✤ Use the Power Switch to select the working modes of the device. RECORD mode: Record onto a tape or store images on the Memory Stick. RECORD M.PLAY OFF: Turn the device off. To recharge the battery, connect the power cable while the Power Switch is set to OFF.
ENGLISH Preparation Adjusting the LCD ✤ Your camcorder is equipped with a 2.5 inch color Liquid Crystal Display(LCD) screen, which enables you to view what you are recording and play back directly. ✤ Depending on the conditions under which you are using the camcorder (indoors or outdoors), you can adjust ;...
ENGLISH Preparation 8. Press the MENU DIAL. Use the MENU DIAL to adjust the value of BRIGHT ADJUST and COLOR ADJUST. You can set the values for BRIGHT ADJUST between 0 ~ 35 and COLOR ADJUST between 0 ~ 35. 9.
ENGLISH Preparation Adjusting the LCD during PLAY ✤ You can adjust the LCD during playback. ✤ The adjustment method is the same as is used while in CAMERA mode. (See page 31) Controlling Sound from the Speaker The Speaker only works in PLAYER mode. FADE When you use the LCD screen for playback, you can hear the recorded sound from S.SHOW...
ENGLISH Functions Using MENU ✤ Use the MENU button to change or select recording settings and Hardware functions. ✤ MENU instructions are displayed both on the LCD and the viewfinder. It is easier to manipulate your device using the LCD. MENU SUB MENU Functions...
Page 38
ENGLISH Functions MENU SUB MENU Functions Page PB DSE SELECT Selecting PB DSE(Digital Special Effects) PHOTO SEARCH Searching Pictures recorded in TAPE PLAY CAMCORDER PHOTO COPY Copying Pictures from TAPE onto the Memory Stick AUDIO SELECT Selecting the Sound Quality of Playback CONT.
ENGLISH Functions Setting the Camcorder to CAMERA or PLAYER Mode and M.REC or M.PLAY Mode 1. Press the MENU button. 2. The MENU OSD is displayed. The cursor ( HIGHLIGHT ) indicates the feature you are currently adjusting. 3. Use the MENU DIAL to move between items and press the MENU DIAL to select and activate an item.
ENGLISH Functions Availability of Functions in CAMCORDER Mode. Digital Requested Digital functions special NITE PIX Mode Operating PHOTO SLOW D.ZOOM effects Mode (TAPE) SHUTTER D.ZOOM ✕ ✕ ✕ ✕ PHOTO ✕ SLOW SHUTTER Digital Special Effects ✕ NITE PIX O : The requested mode will work in this operating mode. ✕...
ENGLISH Functions CLOCK SET ✤ CLOCK setup works in CAMCORDER or CAMERA mode and PLAYER, M.PLAY modes. ✤ The DATE/TIME is automatically recorded onto the tape and Memory Stick. Before recording or taking photos, please set the DATE/TIME. 1. Press the MENU button. CAMCORDER REC MODE The menu list will appear.
ENGLISH Functions WL.REMOTE(SCD5000 only) ✤ The WL.REMOTE function works in CAMCORDER or CAMERA mode and PLAYER, M.PLAY modes. ✤ The WL.REMOTE option allows you to enable or disable the remote control for use in CAMCORDER and CAMERA modes. CAMCORDER REC MODE 1.
ENGLISH Functions DEMONSTRATION ✤ Demonstration automatically shows you the major functions that are included with your camcorder so that you may use them more easily. ✤ The DEMONSTRATION function may only be used in the CAMCORDER mode without a tape inserted in the camcorder. ✤...
ENGLISH Functions G DATE/TIME ✤ The DATE/TIME function works in CAMCORDER or CAMERA mode and PLAYER, M.PLAY modes. ✤ The date and time are automatically recorded on a special data area of the tape. 1. Press the MENU button. The menu list will appear. 2.
ENGLISH Functions G TV DISPLAY ✤ The TV DISPLAY function works in CAMCORDER or CAMERA mode and PLAYER, M.PLAY modes. ✤ You can select the output path of the OSD (On Screen Display). OFF: The OSD appears on the LCD screen only. ON: The OSD appears on the LCD screen, EVF and TV.
ENGLISH Functions EASY Mode (for Beginners) ✤ The EASY mode allows a beginner to easily make good recordings. The EASY mode only operates in CAMCORDER and CAMERA modes. 1. Set the Power Switch to RECORD mode. 2. By pressing the EASY button, all functions on the camera will be set to OFF and the recording settings will be set to the following basic modes: Battery level, recording mode, counter, DATE/TIME, and EIS ( ) will be displayed.
ENGLISH Functions MF/AF (Manual Focus/Auto Focus) ✤ The MF/AF function works in CAMCORDER and CAMERA modes. ✤ In most situations, it is better to use the automatic focus feature, as it enables you to concentrate on the creative side of your recording. ✤...
ENGLISH Functions Zooming In and Out with DIGITAL ZOOM ✤ The Zoom works in CAMCORDER and CAMERA modes. Zooming In and Out ✤ Zooming is a recording technique that lets you change the size of the subject in a scene. For more professional looking recordings, do not use the zoom function too often.
ENGLISH Using the CAMCORDER - Basic Recording Inserting and Ejecting a Cassette ✤ When inserting a tape or closing the cassette holder, do not apply excessive force. This may cause a malfunction. ✤ Do not use any tapes other than Mini DV cassettes. 1.
ENGLISH Using the CAMCORDER - Basic Recording To select the CAMCORDER mode ✤ You can select either a tape or the Memory Stick as the storage media for motion clips. ✤ Use M.Play mode to view the motion clips stored on the Memory Stick. 1.
ENGLISH Using the CAMCORDER - Basic Recording Making Your First Recording 1. Connect a Power source to the camcorder. (See page 27) (A battery pack or the AC power adapter) RECORD Insert a cassette. (See page 50) M.PLAY 2. Set the device to CAMCORDER and set the power switch to CAMCORDER mode.
ENGLISH Using the CAMCORDER - Basic Recording When a cassette is loaded and the camcorder is left in the STBY mode for more than 5 minutes without being used, it will automatically turn off. To use it again, push the START/STOP button or set the Power switch to OFF and then back to CAMERA. This Auto Power Off feature is designed to save battery power.
ENGLISH Using the CAMCORDER - Basic Recording Hints for Stable Image Recording ✤ When recording, it is very important to hold the camcorder correctly. ✤ Fix the LENS cap firmly by clipping it to the hand strap. (refer to the diagram) Recording with the LCD Monitor 1.
ENGLISH Using the CAMCORDER - Basic Recording Playing Back a Tape You Have Recorded on the LCD ✤ You can monitor the playback picture on the LCD monitor. ✤ Make sure that the battery pack is in place. 1. Set the device to CAMCORDER and Set the Power Switch to PLAYER mode. RECORD M.PLAY 2.
ENGLISH Using the CAMCORDER - Advance Recording PROGRAM AE ✤ The PROGRAM AE function works in CAMCORDER mode only. ✤ PROGRAM AE mode allows you to adjust shutter speeds and apertures to suit different recording conditions. ✤ It gives you creative control over the depth of field. I AUTO Mode - Auto balance between the subject and the background.
ENGLISH Using the CAMCORDER - Advance Recording Setting PROGRAM AE 1. Press the MENU button. CAMCORDER REC MODE CAMCORDER REC MODE The menu list will appear. CAMCORDER SET INITIAL RECORD SET CAMCORDER RECORD SET CAMERA PLAY SET PLAY SET MEMORY 2.
ENGLISH Using the CAMCORDER - Advance Recording WHT. BALANCE (WHITE BALANCE) - CAMCORDER Mode ✤ The WHITE BALANCE function in CAMCORDER mode is a recording function that preserves the unique color of the object under any recording conditions. ✤ You may select the appropriate WHITE BALANCE mode to obtain high quality color in the CAMCORDER REC MODE INITIAL image.
ENGLISH Using the CAMCORDER - Advance Recording Digital Zoom in CAMCORDER Mode ✤ Zooming more than 10x is achieved digitally. ✤ The picture quality may deteriorate depending on how CAMCORDER REC MODE much you zoom in on the subject. INITIAL CAMCORDER RECORD SET ✤...
ENGLISH Using the CAMCORDER - Advance Recording EIS (Electronic Image Stabilizer) ✤ The EIS function works in CAMCORDER mode only. ✤ EIS (Electronic Image Stabilizer) is a function that compensates for any shaking or hand movement while holding the camcorder (within reasonable limits). ✤...
ENGLISH Using the CAMCORDER - Advance Recording DSE(Digital Special Effects) SELECT in CAMCORDER Mode ✤ The DSE function works in CAMCORDER mode only. ✤ The digital effects enable you to give a creative look to your recording by adding various special effects. ✤...
ENGLISH Using the CAMCORDER - Advance Recording Selecting a Digital Effect in CAMCORDER Mode 1. Set the device to CAMCORDER and set the power switch to RECORD mode. CAMCORDER REC MODE 2. Press the MENU button. INITIAL RECORD SET CAMCORDER The menu list will appear.
ENGLISH Using the CAMCORDER - Advance Recording G REC MODE ✤ The REC MODE function works in both CAMCORDER and PLAYER(DV IN) modes. ✤ This camcorder records and plays back in SP (standard play) mode and in LP (long play) mode.
ENGLISH Using the CAMCORDER - Advance Recording G AUDIO MODE ✤ The AUDIO MODE function works in CAMCORDER mode. ✤ This camcorder records sound in two ways. (12bit, 16bit) CAMCORDER REC MODE 12bit : You can record two 12bit stereo sound tracks. INITIAL The original stereo sound can be recorded onto the MAIN (SOUND1) track.
Using the CAMCORDER - Advance Recording G WIND CUT ✤ The WIND CUT function works in CAMCORDER, and PLAYER(SCD5000 only) modes. ✤ The WIND CUT function minimizes wind noise or other noise while recording. - When the wind cut is on, some low sounds are eliminated along with the sound of the wind.
- Each time you select DATE/TIME and press the MENU DIAL, it will be displayed in the order of DATE - TIME - DATE/TIME - OFF(See page 51). I WL.REMOTE( )(SCD5000 only) - Each time you select WL.REMOTE and press the MENU DIAL, the WL.REMOTE is switched to either enabled (...
PROGRAM AE If you are using the Manual FOCUS(MF) function, WHT. BALANCE you cannot use the Quick Menu. WL.REMOTE FOCUS (SCD5000 only) SHUTTTER If you want to use the Quick Menu function, SHUTTER EXPOSURE EXPOSURE 1 0 : 0 0 AM exit the Manual FOCUS(MF) mode.
ENGLISH Using the CAMCORDER - Advance Recording SHUTTER SPEED & EXPOSURE ✤ You can set SHUTTER SPEED and EXPOSURE only in CAMCORDER mode. ✤ SHUTTER SPEED and EXPOSURE values can only be set in the Quick Menu. ✤ SHUTTER SPEED and EXPOSURE are automatically switched and/or deactivated. 1.
ENGLISH Using the CAMCORDER - Advance Recording SLOW SHUTTER (Low Shutter Speed) ✤ The SLOW SHUTTER function works in CAMCORDER mode only. ✤ The shutter speed can be controlled, allowing you to record slow moving objects. 1. Set the device to CAMCORDER and set the power switch to RECORD mode. 2.
