FREEWAY T80 Assembly Instructions & User Manual

Assembly Instructions & User Guide
Shower / Commode / Toilet Chair
Dear customer,
Thankyou, for purchasing a Freeway T80 / T80 Paediatric shower chair from
our extensive range of shower / commode / toilet chairs.
Please ensure that all the accessories you ordered have arrived with your
chair, and all accessories are free from any damage.
Please read the following instructions carefully to enable you to use your
chair in a safe manner, as they contain important safety information.
Safety Note: Assembly of this chair may require 2 persons

1. Fitting the backrest to the frame.


Remove the backrest and chair from the
packaging and place on a flat surface. Be
careful as you move the backrest, as the
reclining lever is already attached.

Remove the two white plastic nut covers
and using the 13mm spanner provided,
undo the two M8 nuts and washers from
the backrest.

Fit the backrest into the rear-most sockets
at the rear of the frame, with the handles
facing backwards and push into position.

Fit the M8 washers & M8 nuts onto the
threads and tighten up using the 13mm
spanner. Fit the 2 white plastic covers over
the nuts ( see photo )

Fit the cable tie around the brake cable and
frame of the chair to stop excessive
movement of the brake cable
T80 Reclining Shower chair
T80 & T80 Paediatric Reclining
Rev 1 Nov 2014 page 1
