1. Introduction

Thank you for choosing RME's Digiface AVB. This compact, portable Windows audio interface
is capable of transferring digital audio data into AVB networks. The latest Plug and Play tech-
nology guarantees a very simple installation. Numerous unique features as well as RME's ro-
bust drivers enable a quick, efficient and comfortable operation of the Digiface AVB.
The package contains drivers for Windows 7 / 8 / 10.

2. Package Contents

Digiface AVB
Cable USB 3.0, 1.8 m (6 ft)
RME Driver CD, includes manual as PDF file

3. System Requirements

Windows 7 or up
1 USB 2.0 port or USB 3 port
Computer with at least Intel Core i3 CPU

4. Brief Description and Characteristics

RME MADIface series driver with support for WDM, ASIO and multiple interfaces
128 channels 48 kHz/24 bit record/playback, 128 channels I/O AVB
64 channels 96 kHz/24 bit record/playback, 128 channels I/O AVB
32 channels 192 kHz/24 bit record/playback, 60 channels I/O AVB
Buffer sizes/latencies from 32 up to 8192 samples selectable
Gigabit ethernet port, 100 Mbit/s compatible
Outgoing network latency selectable: 0.3125 ms up to 2 ms
Word clock input and output
Clock modes slave and master
TotalMix for latency-free submixes and perfect ASIO Direct Monitoring
TotalMix: 4096 channel mixer with 46 bit internal resolution
Analog/Line headphone output, separate output for independent submix
DIGICheck DSP: Level meter in hardware, peak- and RMS calculation
USB error analysis, displayed in the Settings dialog
High compatibility to existing AVB devices
