- Page 1 Smoke detector for Roof Top ACTIVA 017 / 175 Options and Accessories, Installation manual Ref.: N-40438_EN 0913...
-
Page 2: Table Of Contents
Index Index Smoke detector ........................1 General information........................2 Technical specifications......................2 General dimensions.........................2 Assembly..........................3 Operation..........................7 Installation..........................8 1.6.1 Installation..........................8 1.6.2 Wiring diagram.........................9... -
Page 3: Smoke Detector
Smoke detector... -
Page 4: General Information
Smoke detector General information 1.1 General information When the ion sensor detects smoke, the DAD activates the fault relay and indicates it on the YKN2Open board and on the DPC-1 thermostat and closes the contact on the accessory board relay. 1.2 Technical specifications This accessory includes the following components: •... -
Page 5: Assembly
Smoke detector Assembly Smoke control board Accessory board Green LED. 1.4 Assembly The ion sensor is fitted inside the Rooftop, on the return air side. The DAD control and the smoke detector board are fitted to the inside of the electrical box in the holes provided for this accessory on the side of the boards. - Page 6 Smoke detector Assembly Detail of sensor assembly Models 017 / 040 A: Control board access. B: Ionic sensor. C: Access to the supply air section Models 100 / 175 A: Control board access. B: Ionic sensor. C: Access to the supply air section Assembly of units without economiser Models 017 / 040 A: Smoke sensor location...
- Page 7 Smoke detector Assembly Assembly in units with economiser (optional) Models 017 / 040 Models 100 / 175 A: Smoke sensor location B: Economiser side frame Assembly in units with or without economiser (models 045 / 090)
-
Page 8: Models
Smoke detector Assembly Detail of control assembly Models 017 / 040 1: Control board 2: DAD control 3: Support attached to the interior partition panel (the holes for the bolts are covered by the insulation) Models 045 / 090 1: Control board 2: DAD control... -
Page 9: Operation
Smoke detector Operation Models 100 / 175 1: Control board 2: DAD control Wiring table Colour From A-Green XI ‑ ┴ DAD ‑ ┴ Blue XI ‑ N DAD ‑ N Black XI ‑ L DAD ‑ L A9 ‑ J4 DAD ‑... -
Page 10: Installation
Smoke detector Installation The YKN2Open board (A1) indicates smoke faults with a 4-5 flashing sequence of the red LED. If thermostat DPC-1 is fitted, the incident is indicated on the screen where the time is displayed along with fault code 45. Once the presence of smoke has disappeared, the thermostat must be manually reset and the YKN2Open board (A1) reset to delete the incident. -
Page 11: Wiring Diagram
Smoke detector Installation 1.6.2 Wiring diagram L1 IN L1 OUT I-2453e Green LED. Power cables. Reset. 1. A-Green. Battery test. 2. Blue. Remote reset. 3. Black. Coil. Connection cables. Connect red wire to terminal +. L1 OUT: Brown. Accessories. L2: White. APOLLO sensor.
