norweco Hydra-Max Installation And Operation Manual

INSTALLATION AND OPERATION MANUAL

INTRODUCTION

The Hydra-Max dechlorination system is designed
to provide automatic dosing of dechlorination tablets
to remove chlorine residual from pressurized water
flows. Constructed of 6061-T6 high strength, aircraft
grade aluminum for maximum strength and durability,
the Hydra-Max system requires no electro-mechanical
components. It can accommodate flows from 150 to
900 gallons per minute (GPM). The compact size and
built-in handle on the system
provide easy transportation
between jobsites. The device
comes equipped with a 2 ½"
NST coupling at the inlet and
a flow directional swivel elbow
on the outlet. This unique
feature allows the direction of
the outflow to be locked into
place. When properly installed
and operated, the Hydra-Max
system will provide complete
removal of free and combined
chlorine. Please familiarize
yourself with the contents of
this manual before proceeding
with installation and operation.

SYSTEM APPLICATION

The Hydra-Max dechlorination
system is designed to accept
2 ⅝" diameter Enviro-C or
Bio-Max dechlorination tablets.
application for the Hydra-Max system is dechlorination of
water flows during fire hydrant flushing. The system can
also be utilized for flushing new water mains or backflushing
swimming pools. An aluminum tablet cartridge contains
multiple ¼" flow ports to provide the proper amount of
mixing and contact with tablets. This allows for complete
neutralization of chlorine and chloramines while keeping
chemical waste to a minimum. The Hydra-Max system
provides a fast and simple set-up that saves operators time
and money. There are no mechanical parts that require
adjustment or components that can be easily damaged
or broken. The compact, durable one piece construction
offers operators a low cost, low maintenance system.
DECHLORINATION SYSTEM
HYDRA-MAX DECHLORINATION SYSTEM
®
The most common
HOW THE HYDRA-MAX
The Hydra-Max system is a flow rated device designed
to safely apply chemicals in pressurized applications to
remove residual chlorine. The Hydra-Max dechlorination
system provides consistent and precise neutralization of
chlorine to meet stringent water treatment requirements
mandated by Federal, State and Local regulations.
The Hydra-Max system can be used for treating water
flows discharging from fire hydrants, swimming pools
the flow. It is recommended that you check the removable
tablet cartridge after 15 minutes of operation. If needed,
add tablets and continue flushing.

SYSTEM PERFORMANCE

The Hydra-Max dechlorination system has been designed
for a flush rate of 150 to 900 GPM with chlorine levels
up to 4 ppm. The complete set-up time is 1-3 minutes
and typically requires only one operator. The Hydra-Max
system provides a fast and easy way to dechlorinate
pressurized flows in the most cost effective and efficient
manner when utilizing Norweco's Enviro-C or Bio-Max
dechlorination tablets.
SYSTEM WORKS
®
and new water mains. When
backflushing swimming pools or
flushing new water mains, the
Hydra-Max system is typically
installed at the discharge
point of the water flow and
connected to a hose specified
for these applications.
Hydra-Max system incorporates
a 2 ½" NST coupling for easy
and fast connection to any fire
hydrant. The outlet incorporates
2 ½" NST male threads for use
with hoses, pilot gauges or
other test equipment.
operation, flow enters through
the inlet hub and is channeled
through the compact dosing
chamber. As flow passes
through the system, it dissolves
the dechlorination tablets to
provide complete removal of
free and combined chlorine from
The
During
