Summary of Contents for Kuassa efektor FZ3603 fuzz
- Page 2 Thank you for choosing Kuassa products! We encourage you to take the time to read this User Manual thoroughly to ensure trouble free and proper operation of the software.
- Page 3 The grandfather of ‘artificial’ effect units. Recognizable from its distinct sound, heavily clipped and compressed to the point where the waveform is squared, adding harsh and complex harmonics and inharmonics, almost synth like. Select from five models of fuzzboxes: • Big Fuzz: the gritty and wooly sustaining note. •...
- Page 4 Key Features: • Five types of effects in every unit. • Independent Gain, Tone, and Output volume controls. • Bypass switch button. • Dry-Wet control. • Up to 8x oversampling. • CV inputs for automation (RE Only) System Requirements Windows: Windows XP or Later (32/64 bit) Intel Pentium 4, or AMD Athlon XP or better (Core2 Duo, Athlon64, or better is recommended) with 512MB minimum RAM...
-
Page 5: Installation
Note for Windows Vista, 7, or later: We recommend installation with Administrator rights using “Run as Administrator” for both Kuassa Installer and Sequencer/Host installer. For Windows Installer (.exe), double-click the installer and follow the instructions. The installer automatically point to your system's default plugins path (see below). - Page 6 /Users/[YourName]/Music/Audio Music Apps/Kuassa/*/* Windows XP or Later Use “Add/Remove programs” or “Programs and Features” from the Windows Control Panel. If EFEKTOR Plug-in(s) does not listed, delete the .dll file from your VST plug-in folder. And other EFEKTOR file resources at ~\Documents\Kuassa\*\*...
- Page 7 AUTHORIZATION On evaluation mode, you will To start the authorization Locate License File this pop-up window process, click the [File] button [ E f e k t o r F Z 3 6 0 3 . k u a s s a ] when you first start the plugin.
- Page 8 AUTHORIZATION (Cont’d) After you locate the License check have File, a pop-up box confirming completed the authorization that successfully process, just simply load the authorize your plug-in will About Box by clicking the show. Efektor logo on the bottom left corner.
- Page 9 FUNCTIONS : FZ3603 [FILE] BUTTON: The Menu button contains several functions; preset saving, license file authorization, and shortcuts to the user manual and Kuassa website. PRESET SELECTOR: Select from available Presets, press left-right buttons or select from drop down menu.
-
Page 10: Preset Management
Preset Management (1/3) Presets for EFEKTOR Plug-in(s) are located in the following folders*: To save a preset, set your plugin to the desired • Mac: Users/[YourName]/Music/Audio Music Apps/Kuassa/Presets/EfektorFZ3603 parameter settings, then select: • Win: ~\Documents\Kuassa\Presets\EfektorFZ3603 • “Save Preset”: Overwrites All presets inside these folders will be recognized by the plugin as individual presets, currently active preset. - Page 11 Preset Management (2/3) When you create a new preset using “Save Preset As...”, make sure that you have chosen the correct preset folder as aforementioned on point 1 above to make sure that it will be recognized automatically by EFEKTOR plug-ins.
- Page 12 Preset Management (3/3) To add new additional preset banks, create a new folder by clicking “New Folder” button and rename it. Sub-folders are also recognized to manage presets into groups, useful to manage additional preset bank, or grouping presets based by their use.
- Page 13 RACK EXTENSION VERSION...
- Page 14 FUNCTIONS : FZ3603 BYPASS Level Knob Turns on, off or bypass the rack extension. Controls the overall output level from the plug-ins. Dry / Wet Knob INPUT KNOB & INPUT METER Adjusts the balance between the direct signal and the Control and show the amount of input level received by processed signal.
- Page 15 CV INPUTS CV Input Socket: Receives incoming CV message for controlling each of EFEKTOR's CV control enabled parameters from another device’s CV output. CV Input Trim: Turn counter-clockwise for each corresponding input to trim or reduce the intensity of incoming CV message. MIDI CC PARAMETER LIST (Propellerhead reason) OVERSAMPLING:...
- Page 16 Kuassa Efektor Series Created by: Muhammad Abduh Intan Zariska Daniyanti Iman Firman Amarullah Juan Prahamma Hartjamt Dimitar Nalbantov Arie Ardiansyah Raden Pratama Kusuma Adhitya Sulistiya Wibisana Bramantyo Ibrahim Cil Satriawan Grahadea Kusuf Iqbal Ansyori Sundawan Sukmaya Presets and Audio Demos by: Dimitar Nalbantov (http://www.nalbantov.com)
- Page 17 A Product of KUASSA. Bandung, West Java. Indonesia © 2010-2017 PT Kuassa Teknika Kuassa and Efektor FZ3603 are trademarks of PT Kuassa Teknika, Indonesia . All other commercial symbols, product and company names are trademarks or registered trademarks of their respective holders.
