ENGINEERING COMPANY INC.
51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: (860) 526-9504
Fax: (860) 526-4078
Internet: www.whelen.com
Sales e-mail: autosale@whelen.com
Canadian Sales e-mail: canadiansales@whelen.com
Customer Service e-mail: custserv@whelen.com
Safety First
This document provides all the necessary information to allow your Whelen product to be properly and safely installed.
Before beginning the installation and/or operation of your new product, the installation technician and operator must
read this manual completely. Important information is contained herein that could prevent serious injury or damage.
Proper installation of this product requires the installer to have a good understanding of automotive electronics,
systems and procedures.
Failure to use specified installation parts and/or hardware will void the product warranty!
If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or other
vital parts could be damaged by the drilling process. Check both sides of the mounting surface before drilling
begins. Also de-burr any holes and remove any metal shards or remnants. Install grommets into all wire
passage holes.
If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro®, clean the
mounting surface with a 50/50 mix of isopropyl alcohol and water and dry thoroughly.
Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted or
located in the air bag deployment area will damage or reduce the effectiveness of the air bag, or become a
projectile that could cause serious personal injury or death. Refer to your vehicle owner's manual for the air bag
deployment area. The User/Installer assumes full responsibility to determine proper mounting location, based
on providing ultimate safety to all passengers inside the vehicle.
For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be
made. The recommended procedure requires the product ground wire to be connected directly to the NEGATIVE
(-) battery post.
If this product uses a remote device to activate or control this product, make sure that this control is located in
an area that allows both the vehicle and the control to be operated safely in any driving condition.
Do not attempt to activate or control this device in a hazardous driving situation.
This product contains either strobe light(s), halogen light(s), high-intensity LEDs or a combination of these
lights. Do not stare directly into these lights. Momentary blindness and/or eye damage could result.
Use only soap and water to clean the outer lens. Use of other chemicals could result in premature lens cracking
(crazing) and discoloration. Lenses in this condition have significantly reduced effectiveness and should be
replaced immediately. Inspect and operate this product regularly to confirm its proper operation and mounting
condition. Do not use a pressure washer to clean this product.
It is recommended that these instructions be stored in a safe place and referred to when performing
maintenance and/or reinstallation of this product.
FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO
THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS!
For warranty information regarding this product, visit www.whelen.com/warranty
©2001 Whelen Engineering Company Inc.
Form No.13617H (062911)
®
Page 1
Installation Guide:
Responder® HD Lightbar
Model(s): R2HD**, R9HD**, R10HD**

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Responder R2HD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Whelen Engineering Company Responder R2HD Series

  • Page 1 FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS! For warranty information regarding this product, visit www.whelen.com/warranty ©2001 Whelen Engineering Company Inc. Form No.13617H (062911) Page 1...
  • Page 2: Operation

    Operation: R2HD** / Rotator Model: Applying +12 volts to the RED wire activates the lightbar and rotators. No features are available for this lightbar. R9HDM* / R9HDV* / R10HDM* / R10HDV* / Linear TIR™ & GEN III Models: Plug cigar cord into vehicle lighter and turn the cigar plug switch on to activate the lightbar.
  • Page 3 Halogen Bulb Replacement: Rotator & Mirror The new rotator must be mounted in the same location Replacement: Remove as the old one to avoid the lens. interference with any existing SNAP-IN LAMP H50SN12 Snap-In parts. The illustration shows Insert P/N 34-0041987-01 Bulb where to locate the fastex flat-blade...
  • Page 4 RESPONDER® HEAVY DUTY / MODEL R2HD ITEM PART NUMBER DESCRIPTION 0 1 - 0 6 8 3 6 11 _ _ M RESPONDER HEAVY DUTY (MAGNET) 0 1 - 0 6 8 3 6 11 _ _ P RESPONDER HEAVY DUTY (PERMANENT) 0 1 - 0 4 6 1 6 4 0 - 0 7 KIT, 80LB MAG.
  • Page 5 RESPONDER® HEAVY DUTY / MODEL R9HD** Available Flash Patterns # FLASH PATTERN OUTLET FUNCTION QTY QTY QTY ITEM PART NUMBER DESCRIPTION 0 1 - 0 6 8 4 6 8 8 _ _ P RESPONDER HEAVY DUTY PERMANENT ® SignalAlert™ 1 Alternates with 2 0 1 - 0 6 8 4 6 8 8 _ _ M RESPONDER HEAVY DUTY MAGNET...
  • Page 6: Wiring Diagram

    RESPONDER® HEAVY DUTY / MODEL R10HD_ _ Available Flash Patterns: 1.ActionScan™ 14 15 16 QTY QTY QTY ITEM PART NUMBER DESCRIPTION 2.SignalAlert™ (Alt) 0 1 - 0 6 8 4 6 9 1 _ _ P RESPONDER HEAVY DUTY PERMANENT ®...
