docking station when working on the USB keyboard or when using a
USB mouse.
4.
Network jack (RJ45):
Connects to an Ethernet 10/100 Base-T network.
5.
Modem jack (RJ11):
Supports a 56kbps v.90 internal modem, US and international for
you to connect to a phone line.
6.
VGA-Out port:
Connects an external (VGA) display monitor.
7.
DC-in jack:
Plug the AC-DC adapter into this jack and to power the system.
Before you plug the AC power cord, you must first check the voltage
toggle switch setting is appropriate for your geographical area.
Chapter 3 - System Overview
Figure 10
Figure 11
