Summary of Contents for Elitegroup Computer Systems TP10RA1
- Page 1 Quick Start Guide Tablet TP10RA1...
- Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
- Page 4 Be sure to keep the power cord away from younger children Please ensure that students understand the following: As with all electrical products, precautions should be observed during handling and use to prevent electric shock. The power supply (adapter) should not be handled by the children.”...
-
Page 5: Package Contents
Do not place near the fire or other sources of heat. Do not expose to magnetic fields. Do not expose to direct sunlight. Do not expose to rain or moisture. Do not place heavy objects to add heavy pressure on the computer. Do not drop the computer. - Page 6 Tablet layout Name Name Front facing camera Touchscreen Microphone Stylus holder Input/output cabinet (See page 7)
- Page 7 Name Name Windows button (for Windows 8.1) Power button Home button (for Android) Input/output cabinet Volume up/down (See page 7) Rear facing camera Speaker Stylus holder...
- Page 8 Name Name Headphone jack Micro HDMI port Windows button (for Windows 8.1) Micro SD card slot Home button (for Android) Micro USB DC IN / Micro USB port...
- Page 9 Name Name Camera indicator Charging indicator...
-
Page 10: Charging Your Tablet
Charging your tablet If your tablet is just being unpacked from the box, you need to charge the tablet first. It will take around 4 to 5 hours to be fully charged. 1. Plug the USB head of the cable into the adapter. 2. - Page 11 Powering ON/OFF your tablet To power on your tablet Press down the power button (normally 3 to 4 seconds) until you see the screen turn on. To power off your tablet For Android, follow these steps: 1. Press and hold the Power Lock button. 2.
- Page 12 For Windows, follow these steps: 1. Press and hold the power button for at least four seconds, and you will see an instruction appears in the middle of the screen, which is as shown below. 2. Slide your finger on the screen downward, and the system will power off itself.
-
Page 13: Inserting A Storage Card
Inserting a storage card Your tablet supports micro-SD cards with maximum storage space up to 64G. You can insert the micro SD card and pull it out without powering down the tablet. To do so, follow the steps below. Install your Micro SD Card 1. -
Page 14: Specifications
Specifications Intel Bay Trail-T-CR Z3735G/ Z3735F Processor Base 1.33 GHz, Burst to 1.83GHz 2MB L2 Cache DDR3L- 1333 Memory Default: 1 GB ( Max. 2G) eMMC v4.51 Storage 16GB/32GB Wi-Fi 802.11 b/g/n Wireless Bluetooth 4.0 10.1-inch TFT Color LCD (1280 x 800) Touchscreen 10 point touch Win 8.1 certified touch solutions... - Page 15 1 x micro-USB 2.0 (OTG) 1 X micro HDMI port Input/Output 1 x Mic/head phone jack combo 1 x micro-SD card slot Speaker & Build-in Speaker x 2 Internal MIC x 1 DC Output: 10W/5V/2A AC-Adapter Input Voltage: 100 - 240VAC Input Frequency: 47 - 63Hz Dimension 272 (W) x 183.5 (H) x 12.8 (D)
