Replacement Kit Instructions

Replacement kits may be ordered through customer care .
Instructions for Installing/Removing/
Replacing the Power Cord
1) Make sure system is powered off and unplugged .
2) Remove the screw retaining the power cord cover
using a 1/16" hex driver .
3) Remove the power cord cover .
4) Remove the power cord .
5) Install new power cord and reassemble power cord
cover .

Telescoping Bed Hanger Replacement

1) The telescoping bed hanger piece can be
removed and replaced if necessary .
2) To replace the bed hanger, hold down release
button on the back of the system and firmly pull
bed hanger out of the body of the system .
3) Discard the broken or ineffective hanger . To
install the new bed hanger, slide the new hanger
back into the body of the device and set at
desired length .

Instructions for Replacing Fuses

1) Remove the power cord . Refer to the 'Instructions for
installing/removing/replacing the power cord' section .
2) Remove fuse holder from power entry module .
3) Remove fuses from fuse holder .
4) Replace any blown fuses with 250V, 2A, IEC fast acting
5X20mm fuses .
5) Reassemble fuse holder and replace power cord per
previous instructions .
14

Cleaning Instructions

Both the pump case and the tube assembly can be cleaned with a mild soap solution,
antiseptic or disinfectant wipes . DJO tested numerous disinfectants on the device and
found no adverse effects using isopropyl alcohol and hydrogen peroxide (Oxivir Tb) .
According to the results, it is advised to avoid using Dimethyl benzyl ammonium
chloride or Dimethyl ethylbenzyl ammonium chloride (Tec-Surf II), or solutions
containing chlorine . Apply using a dampened cloth or wipes . Do not submerge the
device in any liquid .

Disposal

All contaminated product or accessories should be disposed of properly according to
hospital policy and/or state law .

Warranty

For consigned systems: DJO, LLC will repair or replace all or part of the 30B-S and
30B-SB systems for material or workmanship defects for the life of the customer
contract . Warranty and maintenance terms are specified for each consignment contract .
For purchased systems: DJO, LLC will repair or replace all or part of the 30B-S or 30B-SB
systems for material or workmanship defects for 3 years from the date of sale . For
disposable cuffs, tubing and battery pack purchases: DJO, LLC will repair or replace all
or part of the cuffs, tube units and battery packs for material or workmanship defects,
not including normal depreciation of battery life or charge capacity, for a period of six
months from the date of sale .

Optional Tube Alarm Verification Test

The Tube Alarm Verification Test is provided for facility verification purposes only and is
not required prior to use .
Attach tube assembly to pump and connect power cord to electrical outlet . Simulate
a kinked tube situation by folding the tube over onto itself once and holding it for 4-6
minutes . The second cycle after the simulated kink should activate an audible alarm
and this symbol will appear with "CHECK TUBES" on the graphical display and the
pump indicator lights on the side of the system will flash red .
