- Page 1 USER MANUAL LDB 2 ASK LDB 2 DESKTOP READER ASK R&D Réf. : RD-ST-03022-10 Rév.: 1.0 1 / 10 5 traverse des Brucs. Les Bouillides R&D001-Form1 06560 VALBONNE SOPHIA ANTIPOLIS Tel : 04 97 21 40 00 Fax : 04 92 38 93 21...
- Page 2 (1) This device may not cause harmful interferences. And (2) this device must accept any interference received, including interference that may cause undesired operation. The ASK LDB 2 reader was submitted and a grand of authorization received from the FCC as device under the intentional radiator requirements of Part 15, Subpart C.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SCOPE OF MANUAL 1.1 UNPACKING AND INSPECTION LDB 2 READER 2.1 READER COMPONENTS 2.1.1 Coupler board 2.1.2 Antenna board 2.1.3 Power supply board 2.1.4 Contact card interface board 2.2 Assembly READER SETUP 3.1 INSTALLING A NEW SAM IN READER 3.2 READER CONNEXION... -
Page 4: Scope Of Manual
LDB 2 DESKTOP READER SCOPE OF MANUAL This manual describes ASK LDB 2 reader main features and setup information. This manual is intended for use by end users. No specific tools are required for operation described in this document. 1.1 UNPACKING AND INSPECTION... -
Page 5: Reader Components
LDB 2 DESKTOP READER 2.1 READER COMPONENTS LDB 2 consists of a control board called ”coupler board”, and antenna board, a DC supply converter board (with two extra SAM sockets) and a contact card interface board. 2.1.1 COUPLER BOARD The coupler board contains a microprocessor, non-volatile memory and a radio frequency transmitting circuitry. -
Page 6: Antenna Board
9V to 36V DC. Typically an AC power bloc with output 12V 500mA (without regulation) should be used. SAM location Figure 5 : LDB 2 DC conversion / SAM extension board : GEN 351 ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0... -
Page 7: Contact Card Interface Board
This card has been added for allowing standard contact card transactions. Contact card connector Figure 6 : LDB 2 contact card interface board : GEN 362 2.2 ASSEMBLY Inside the plastic case these boards are stacked together (Figure 7). This way, no cables are... -
Page 8: Reader Setup
Caution : In a first time, µSIM SAMs must be gently inserted in the open door socket (Figure 8), then in a second time the door should be locked. Figure 8 : SAM in open door ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 8 / 10 Copyright ASK SA - 2003... -
Page 9: Reader Connexion
Plug the main adapter included in the « Power-Jack » connector. The main adapter should provide 12V DC – 500mA. Turn on the switch located at the front side, the red LED will light at power-on. The LDB 2 is then in power and ready to work. Serial connector To computer... -
Page 10: How To Use The Reader
HOW TO USE THE READER 4.1 CONTACTLESS OPERATIONS All the top surface of LDB 2 reader is active. Contactless smart card must be laid flat on the reader, yellow LED is turned on when operation is correct. 4.2 CONTACT OPERATIONS The smart card should be inserted, chip on top, in the front slot of the LDB 2 reader (card contact faces triangle on reader front side).
