- Page 1 USER MANUAL RDR 417 RDR 417 USB contactless reader user manual ASK R&D Réf. : RD-MU-05179-10 1 / 13 2260 Route des Crêtes R&D001-Form1 06560 VALBONNE SOPHIA ANTIPOLIS Tel : 04 97 21 40 00 Fax : 04 92 38 93 21...
-
Page 2: Table Of Contents
Annexe 5.3.1 Coupler board 5.3.2 Antenna board 5.3.3 Assembly ASK R&D Réf. : RD-MU-05179-10 2 / 13 2260 Route des Crêtes R&D001-Form1 06560 VALBONNE SOPHIA ANTIPOLIS Tel : 04 97 21 40 00 Fax : 04 92 38 93 21... -
Page 3: Scope Of Manual
RDR 417 USB contactless reader SCOPE OF MANUAL This manual describes ASK RDR 417 contactless reader main features and setup information. This manual is intended for use by end users. Sam installation requires a “Philips” screwdriver for case opening. READER DESCRIPTION The RDR417 is a high speed, low cost, multi-standard, multi-application USB contactless reader. -
Page 4: Main Applications
SRIX4K, Sharp B, all ASK cards and tickets. ICODE SLI. 2.2 Architecture This diagram describes the general architecture of the RDR417 reader. The reader is an assembly of the ASK CPL407 USB coupler, and its dedicated local antenna ANT400. 27.120 MHz 3.3V regulator 13.56 MHz... -
Page 5: Mechanical Aspects
USER MANUEL RDR 417 USB contactless reader 2.3 Mechanical aspects Case: ABS light grey (RAL 7035) Soft side "grip" plastic: grey (RAL 7012) diam2.8 5 / 13 ASK R&D Réf. : RD-MU-050179-10 Copyright ASK SA - 2006... -
Page 6: Attached Usb Cable Definition
An adhesive cover film is added to the top case. It supports ASK logo. For volume order, it may be modified in order to support customer’s logo. Material is polycarbonate 250 µm, and adhesive 3M 468. 6 / 13 ASK R&D Réf. : RD-MU-050179-10 Copyright ASK SA - 2006... -
Page 7: Reader Setup
READER SETUP 3.1 Unpacking and inspection For end user unity packaging, the RDR 417 is delivered with an installation CD. It includes user manuals in *;pdf format, USB drivers, and a few demonstration software. 3.2 Installing the SAM in the reader In most applications, one SAM (Security Application Module) is required. - Page 8 Caution: In a first time, µSIM shape SAM must be gently inserted in the opened cover, then in a second time the cover should be closed and locked. Close and screw again the reader before use. 8 / 13 ASK R&D Réf. : RD-MU-050179-10 Copyright ASK SA - 2006...
-
Page 9: Reader Connection To Usb
Insert the installation CD, and follow the instructions on screen. You will be asked to choose between: Standard virtual COM driver, Card reader ASK (dll) proprietary driver, or PC/SC driver. Chosen driver will depend on the customer application software requirements. -
Page 10: How To Use The Reader
USB contactless reader HOW TO USE THE READER 4.1 Contactless operation All the top surface of RDR 417 reader is active. Card must be laid on the top of the reader. 4.2 Cleaning To clean, simply wipe with a wet cloth. -
Page 11: Standard Compliance
(1) This device may not cause harmful interferences. And (2) this device must accept any interference received, including interference that may cause undesired operation. The ASK RDR 417 reader was submitted and a grand of authorization received from the FCC as device under the intentional radiator requirements of Part 15, Subpart C. -
Page 12: Annexe
RDR 417 USB contactless reader 5.3 Annexe RDR 417 is an assembly of a control board called ”coupler board”, and an antenna board. 5.3.1 Coupler board The coupler board contains a microprocessor, non-volatile memory and a radio frequency transmitting circuitry. This board communicates with smart cards via RF link (provided by the antenna board), and to the terminal via “USB to serial”... -
Page 13: Antenna Board
5.3.3 Assembly Inside the plastic case, these boards are stacked together, using M3 x 10 spacers. Internal SMD Leds are replicated to front panel using light guides. 13 / 13 ASK R&D Réf. : RD-MU-050179-10 Copyright ASK SA - 2006...
