DESCRIPTION:
The Minco TI142 is a handheld digital thermometer designed for accurate temperature
measurement in the laboratory or field. High accuracy, normally found only in expensive bench
instruments, is achieved when the meter is used with a Minco Model S900 series handheld probe.
The meter can also interface with any 100ohm @ 0°C, Platinum RTD by using the optional AC742
binding post adaptor.
OPERATION:
1)
Install a 9 volt battery in the battery compartment.
2)
Insert the sensor plug into the jack on top of the meter.
3)
Move the power switch to the on position.
4)
Select the appropriate scaling (Fahrenheit or Celsius).
For maximum resolution and accuracy, use the °C scale.
MINCO
7300 Commerce Lane / Minneapolis, Minnesota 55432-3177 U.S.A.
Telephone: (763) 571-3121 / FAX: (763) 571-0927
MINCO MODEL TI142
Handheld Digital Thermometer
Operating Instructions
PRODUCTS, INC.
Advertisement
Related Manuals for Minco TI142
Summary of Contents for Minco TI142
-
Page 1: Operating Instructions
High accuracy, normally found only in expensive bench instruments, is achieved when the meter is used with a Minco Model S900 series handheld probe. The meter can also interface with any 100ohm @ 0°C, Platinum RTD by using the optional AC742 binding post adaptor. - Page 2 TROUBLESHOOTING GUIDE: Condition Causes Remedy Disconnect from meter, Display shows "1" RTD is open. ohm RTD continuity and continuously in only the connections. Replace the leftmost digit. RTD if faulty. Over range temperature. Switch to °F scale. System is only accurate to 400°F, but meter will read to 600°F.
- Page 3 GENERAL SPECIFICATIONS: Display 3.5 digit LCD (Liquid Crystal Display). Display Mode: Fahrenheit or Celsius. Input: Models available for 100 ohm at 0°C (Pt) and 604ohm at 0°C. Sensor Connection: Two standard .75” spaced banana plugs. Power Supply: 9 volt alkaline battery (supplied). Ambient Temperature: Operating: 0 to 50°C (32 to 122°F)
- Page 4 WARRANTY INFORMATION: Items returned within one year from the date of sale, transportation prepaid, which Minco Products, Inc. (the Seller) reasonably determines to be faulty by reason of defective materials or faulty workmanship will be replaced or repaired at the Seller's discretion, free of charge.
