Minco TI108FX1B6C Operating Instructions

Handheld digital thermometer

The Minco TI108FX1B6B is a handheld digital thermometer designed for accurate

temperature measurement in calibrating the heater assembly in a dry silver film processor.

The TI108FX1B6B is designed for Minco sensor model S19639 (or any sensor equivalent

to model S11029). It is match calibrated to the sensor at 121.1°C (250°F) to provide the

best accuracy over the range of 115 to 127°C (240 to 260°F). Sensors are not

interchangeable. The meter must bee recalibrated to a new sensor to maintain stated

accuracy. Contact Minco for a copy of the calibration procedure.

Install a 9 volt battery in the battery compartment.

Insert the sensor plug into the jack on top of the meter. Veryfy that the process

numbers on the sensor and the thermometer match.

Move the power switch to the on position.

Select the appropriate scaling (Fahrenheit or Celsius). For maximum resolution and

accuracy, use the EC scale.

7300 Commerce Lane / Minneapolis, MN 55432-3177 U.S.A.

Telephone: (763) 571-3121

MINCO Model TI108FX1B6C

Handheld Digital Thermometer

Operating Instructions

PRODUCTS, INC.

FAX: (763) 571-0927

Table of Contents

Do you have a question about the TI108FX1B6C and is the answer not in the manual?

Page 1: Operating Instructions
The TI108FX1B6B is designed for Minco sensor model S19639 (or any sensor equivalent to model S11029). It is match calibrated to the sensor at 121.1°C (250°F) to provide the best accuracy over the range of 115 to 127°C (240 to 260°F).
Page 2 TROUBLESHOOTING GUIDE Condition Causes Remedy Display shows “1” RTD is open. Disconnect from meter, check the RTD continuously in only the continuity and connections. Replace the leftmost digit. RTD if faulty. Switch to EF scale. Meter will read to Over range 600 EF, but system is accurate to temperature.
Page 3 Weight: 7.3 ounces (with battery) WARRANTY INFORMATION: Items returned within one year from the date of sale, transportation prepaid, which Minco Products, Inc. (the Seller) reasonably determines to be faulty by reason of defective materials or faulty workmanship will be replaced or repaired at the Seller's discretion, free of charge.
Page 4 MINCO MINCO PRODUCTS, INC. 7300 Commerce Lane / Minneapolis, MN 55432-3177 U.S. Telephone: (763) 571-3121 FAX: (763) 571-0927 © 2001, Minco Products, Inc. Page 4 of 4...
