kenall Sentinall S511 Series Installation Instructions

SENTINALL
™
Luminaires for High Abuse Applications
S511 SERIES
INSTALLATION INSTRUCTIONS
1. Read all fixture markings and labels to insure correct installation of the fixture. Additional information may be
located on the fixture, separate from this instruction sheet, regarding orientation and mounting restrictions.
2. For Peace of Mind Guarantee
(4 point mounting). Attachment to the electrical box only will not insure proper fixture performance.
3. Disconnect power to the circuit before wiring fixture.
4. Remove lens/housing. Remove reflector by popping it out..
5. Place fixture over an installed electrical junction box. Locate and drill 4 pilot holes in mounting surface. Use
fixture base as template. Using 1/4-20 fasteners and anchors appropriate for the mounting surface, (not
supplied), mount fixture base to building. Orient base of S511L so that socket is up when lamp is installed.
6. Connect fixture leads to power supply leads using connectors suitable for the gauge and number of wires being
used (not included). Connections are to be made in the junction box, not the fixture. Black fixture lead connects
to the supply conductor, white fixture lead connects to the neutral supply conductor, and the grounding wire
must be connected to a suitable ground.
7. As applicable, reassemble ballast housing, reflectors, wireway covers, etc. to the base. Install lamp. Mount
diffuser/refractor to base using Torx
NOTE: Check gasket for proper seal between lens/housing and mounting surface. To ensure the fixtures watertight
integrity, especially if the fixture is mounted in direct exposure to the elements, caulk between the mounting surface
and base using a high quality caulking material.
, fixture must be mounted to building with at least 4 fasteners
®
fasteners (included) and 9500 screwdriver (ordered separately).
®
www. kenall.com P: 800-4-Kenall
INSTALLATION INSTRUCTIONS

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety precautions
should always be followed, including the following:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND
THE HAZARDS INVOLVED. DISCONNECT POWER TO ALL CIRCUITS
BEFORE WIRING FIXTURE. INSTALL IN ACCORDANCE WITH
ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT CONNECT
TO AN UNGROUNDED SUPPLY. READ ALL FIXTURE MARKINGS
AND LABELS TO ENSURE CORRECT INSTALLATION OF FIXTURE.
SUPPLEMENTAL INSTRUCTIONS MAY BE LOCATED ON THE
FIXTURE, IN ADDITION TO THIS INSTRUCTION SHEET, REGARDING
ORIENTATION, OR MOUNTING RESTRICTIONS.
SAVE THESE INSTRUCTIONS
F: 847-360-1781 1020 Lakeside Drive Gurnee, Illinois 60031
1
S511-092613
