Summary of Contents for Xoro MPA 38 PRO
- Page 1 PORTABLE ANTENNA SYSTEM XORO MPA 38 PRO INSTALLATION AND OPERATING MANUAL...
-
Page 2: Table Of Contents
GENERAL........................3 SAFETY INSTRUCTIONS..................3 PACKING LIST ......................3 SET-UP LOCATION ....................4 CONNECTION SCHEME.................... 5 INSTALLATION ......................5 FRONT PANEL ......................6 REAR PANEL ......................6 OPERATING INSTRUCTIONS .................. 7 WARRANTY TERMS ....................8... -
Page 3: General
Do not use the control box without appropriate fuse. Using an inappropriate fuse or bypassing the fuse may cause dangerous situations PACKING LIST Antenna Unit XORO MPA 38 Pro Control Box Control Panel 1x 8 meters RG6-U-4 Coax cable (Connection between Control box and Antenna unit) 1x 1.5 meters RG6-U-4 Loop out cable (Connection between Control box and... -
Page 4: Set-Up Location
SET-UP LOCATION Make sure there are no physical obstacles between the antenna and line of sight to satellite which may prevent to get the signals. Any tall objects will block the signal. The antenna unit requires “direct line of sight” to satellites for optimal signal reception. The signal receiving performance of the system may decrease during heavy rainfall or snowfall. -
Page 5: Connection Scheme
The fuse protects it from damages caused by e.g. a shortcut or cable fire. NOTE: The XORO MPA 38 Pro has an auto skew functionality that automatically sets the polarization angle for the LNB and a GPS-receiver for accurate and quick positioning. -
Page 6: Front Panel
FRONT PANEL ON/OFF Switch Power LED Indicator USB LED Indicator USB Port REAR PANEL Loop-out connection for external receiver Antenna-in connection for antenna unit Control panel connection 12/24V Power connection... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Operating the system Make sure all the connections between antenna system and control box and between receiver and control box using the loop out port are connected properly. Make sure the handle of the antenna points towards the floor while in operation in order to prevent a limited signal reception. -
Page 8: Warranty Terms
RMA number to the following adress: ERS GmbH Electronic Repair Service Weidegrund 3 21614 Buxtehude Germany Free call-back service (please visit our homepage) www.xoro.de/service Customer service E-mail: support@ersservice.de... - Page 9 Notes...
- Page 10 TECHNICAL SPECIFICATIONS Antenna motion: Two axis; azimuth and elevation Satellite search: Automatic at stationary position only Connection: Through single coax cable Azimuth moving range: 0° ~ 380° limited Elevation moving range: 0° ~ 80° Operating voltage: 12-24V DC Operating power consumption: Dimensions (in closed position): 45x48x46( LxWxH in cm) Weight:...
