  • Page 1 Sim Pedals Sprint Baseplate product manual...
  • Page 2 You have acquired a Heusinkveld Sim Pedals Sprint Baseplate! This product provides a solid mounting platform for your Sim Pedals Sprint.
  • Page 3 12x M5 flanged nut. - Schematics. - Installation. Rig mounting: 4x M5x16 bolt. Packing list 8x M5 large washer. The Sim Pedals Sprint Baseplate box contains the 4x M5 nylock nut. following: Tools: Main parts: 1x M2 hex key. 2x Powdercoated C-bracket.
  • Page 4 7mm for M4 (pedal mounting plate). 8mm for M5 (pedals to mounting plate). Videos In the Support section of the heusinkveld.com website you will find tutorial videos further demonstrating a number of the instructions shown in this manual. Manual version & digital download This is version 1.0 of the manual.
  • Page 5 Sim Pedals Sprint Baseplate. All dimensions are in millimeters (mm). The bottom mounting points for your Sim Pedals Sprint Baseplate have a width of 235mm. This is compatible with the mounting holes for TM T3PA and T3PA Pro (235mm) pedal sets.
  • Page 6 Baseplate, top view. Baseplate, bottom view.
  • Page 7: Installation

    Installation This section explains how to assemble the baseplate, mount the pedals and install the assembly onto your simulator. We recommend following the instructions in chronological order. Pedal mounting plate installation 1. Locate the powdercoated pedal mounting plate and the two C-shaped brackets.
  • Page 8 Heel plate installation - raised position Two sets of metal spacers (20mm en 40mm length, four pieces each) are included with your baseplate. You can use these to increase the heigth of the heel plate. This may be usefull if you have small feet or drive without shoes. Note that you can also adjust the pedal plates on the pedal arm to achieve a similar effect.
  • Page 9 Mounting the pedals to the pedal plate Before mounting the pedals to the pedal plate, determine if you want to adjust the angle of the pedal arms. If yes, this should be done now. Refer to the Sim Pedals Sprint manual on how to adjust the pedal angle.
  • Page 10 Note on 2-pedal sets Please note than in case of a 2-pedal set (no clutch) the throttle and brake must be positioned next to eachother, otherwise the wire to connect the throttle to the controller in the brake may be too short. Mounting the baseplate to your rig We provide the following mounting hardware to mount the baseplate to your rig:...
  • Page 11 When using the middle row of mounting holes (row B - also see Schematics section), your baseplate + pedal setup will be roughly similar to the ergonomics of TM T3PA and T3PA Pro pedal sets. This may ease the setup on rigs which have support for those pedal types.
