WARNING
Read the SAFETY section and Complete
the ASSEMBLY procedures before oper-
ating the Shopsmith Dust Collector.
Dust Collector
330002
T T T T T a a a a a b b b b b le of
le of Contents
le of
le of
Contents
Contents
Contents
le of
Contents
Parts List ...................................................... 2
Introduction/Safety .................................... 4
General Information ................................... 7
Assembly ..................................................... 8
Maintenance and Troubleshooting ........ 10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Shopsmith DustCollector
Summary of Contents for Shopsmith DustCollector
-
Page 1: Table Of Contents
WARNING Read the SAFETY section and Complete the ASSEMBLY procedures before oper- ating the Shopsmith Dust Collector. Dust Collector 330002 T T T T T a a a a a b b b b b le of le of le of Contents... -
Page 2: Parts List
515670 Power Cord ... 1 515126 Star Washer ... 2 513897 Hex nut, #10-32 ... 2 †Not available as a service part. Shopsmith, Inc. 6530 Poe Avenue Dayton, Ohio 45414 937/898-6070 937/890-5197 Fax 330002 Shopsmith Air FIltration System DC3300 Qty. - Page 3 330002 Dust Collector Figure 1 Page 3...
-
Page 4: Introduction/Safety
The large air- flow of the Shopsmith Dust Collector can be “observed” by placing a few fingers into the end of the hose. The airflow of the Shopsmith Dust Collector is much higher than any home or shop vacuum. - Page 5 Dust Collector. NEVER use non-Shopsmith replacement parts or ac- cessories. They are not designed like Shopsmith parts. Using non Shopsmith parts may cause a hazardous condition and will void your war- ranty. • Do not leave the Dust Collector running unat- tended.
-
Page 6: Electrical Requirements
This powerful Dust Collector draws a substantial amount of starting current. Therefore, it should not be run on the same circuit as the Shopsmith Mark V. You could over- load the circuit. Before starting the Dust Collector, attach hose(s) and set up as intended for use. -
Page 7: Specifications
3-way inlet port(s) that are not in use. 12. Two Extension Wands 13. Floor Pickup 14. Elbow Brush 15. Reducer - Allows you to connect the Shopsmith Mark V Model 500 (sold separately). 16. Utility Pickup Specifications The Dust Collector’s specifications will give you an idea of its capabilities. -
Page 8: Assembly
When you have completed install- ing both legs, the circled “r” registration mark after the word “Shopsmith” on the legs should be near the larger diameter end (top) of the main housing. Also, the... - Page 9 (41), lock washers (42) and nuts (43). Hand tighten all eight fasteners. Install the Rear Wheels 6. With the Dust Collector still on its side, install the rear wheels, by inserting a re- tainer (44) into a 5/8. socket (or closed-end wrench).
-
Page 10: Using The Dust Collector
25. For each inlet you are not currently using, push an inlet plug (50) with a cap (51) into the open inlet. 26. Plug the Dust Collector into a wall socket. Refer to the section, “Electrical Require- ments.” Using the Dust Collector... -
Page 11: Cleaning The Exterior
A reducer allows you to connect to equipment with 1-1/4" chutes such as the Shopsmith Mark V Model 500 (having a serial number 222396 or lower). Three 2-1/ 2" diameter hoses can be connected to the 3- way inlet and used simultaneously. -
Page 12: Troubleshooting Guide
MKV TABLE SYSTEM RETRO KIT - 500 TO 510 Troubleshooting Guide Dust Collector problems usually have simple solutions. Under normal use, you should rarely have to service your Dust Collector. Most problems can be corrected by maintenance or a change of work habits. Maintenance and Troubleshooting Problem Unit will not start.
