FG085 Function Generator
Quick Use Guide
Applicable Model: 08503, 08503K, and 08504K
Panel & Connectors
Frequency
or period
Cursor
Amplitude
Output
connector
Power ON/OFF
Incremental
Select
adjustment
Mode
(push for setting
change)
Output
connector
Power connector
( central pole positive )
USB connector
Headers & Adjustment
U5 program port
+5V GND GND
J8
PIN 1
MOSI nRST SCK MISO
Sy nc pulse output
( Freq. Sweepi ng mode)
+5V GND GND
J 6
PIN 1
MOSI nRST SCK MISO
U6 program port
www.jyetech.com
Visit
Rev. 02
detailed and updatoed documents
Waveform DC offset
Correction
or exit
Select waveform
Select unit
Select
Data entry
parameter
LCD contrast
adjustment
Operating
for
1. Constant Waveform (CW) Mode
2. Frequency Sweeping Mode
3. Servo Position Mode
4. Servo Run Mode
5. Mode Selection
Tips
( 1 )
( 2 )
Alternative
USBconnector
Function Operations
Set Frequency
[F/T] + [Data Entry Keys *] + [Unit Key]
or Period
Set Amplitude
[AMP] + [Data Entry Keys *] + [Unit Key]
Set Offset
[OFS] + [Data Entry Keys *] + [Unit Key]
Incremental
Select parameter and turn [ADJ] dial
Adjustment
(Incremental step size can be set to any value).
Select Waveform Press [WF] key
* Note: Use [ESC] to correct or cancel input
Function Operations
Set sweep
Turn [ADJ] to select parameter. Press [F/T] to change.
parameters
Use buttons [1], [2], [3], and [4] for quick access.
Set Amplitude
[AMP] + [Data Entry Keys *] + [Unit Key]
Set Offset
[OFS] + [Data Entry Keys *] + [Unit Key]
Select Waveform Press [WF] key
Function Operations
Set Pulse Width
[F/T] + [Data Entry Keys *] + [Unit Key]
Set Amplitude
[AMP] + [Data Entry Keys *] + [Unit Key]
Incremental
Select parameter and turn [ADJ] dial
Adjustment
Change Settings Push [ADJ] (refer to detailed manual)
* Note: Use [ESC] to correct or cancel input
Use [WF] key to start and hold servo running.
[MODE] + {Turn [ADJ] to select} + [WF]
Under CW mode [ADJ] incremental step can be changed to any value
To do this type in the step size you need and end with [Hz] or [mS] buttons.
[Hz] sets the step for frequency adjustment. [mS] sets the step for time
adjustiment.
Quick access parameters in Frequency Sweeping mode
Under frequency sweeping mode you can use digit buttons [1], [2], [3], and
[4] to access Start Frequency, Stop Frequency, Sweep Time, and Time Step
Size respectively.
