PCIeEXT-16HOT
Smart Live Insertion PCI-Express Bus Extender
PCIEXT-64U / UB
Live Insertion 32/64-Bit Universal 5/3.3v
PCI Bus Extender
With software for Windows 7, Vista, XP, 2K, 98, 95
Product Specifications and User Manual
v1r05 – August 15, 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCIeEXT-16HOT and is the answer not in the manual?

Questions and answers

Summary of Contents for UltraView PCIeEXT-16HOT

  • Page 1 808 Gilman Street Berkeley, CA., 94710 p:925.253.2960 E-mail: support@ultraviewcorp.com Visit us at: www.ultraviewcorp.com PCIeEXT-16HOT Smart Live Insertion PCI-Express Bus Extender PCIEXT-64U / UB Live Insertion 32/64-Bit Universal 5/3.3v PCI Bus Extender With software for Windows 7, Vista, XP, 2K, 98, 95 Product Specifications and User Manual v1r05 –...
  • Page 2 808 Gilman Street Berkeley, CA., 94710 p:925.253.2960 www.ultraviewcorp.com PRODUCT IMAGES MODEL: PCIeEXT-16HOT MODEL: PCIEXT-64U / UB r1v05 Page 2 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 3: Table Of Contents

    UUT IS NON-RESPONSIVE AFTER REINSTATING CONFIGURATION SPACE..........19 WARNING! EMPLOY ESD PROTECTION MEASURES AT ALL TIMES WHEN USING A BUS EXTENDER TO PREVENT DAMAGE TO SYSTEM, EXTENDER AND UNIT-UNDER-TEST r1v05 Page 3 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 4: Limited Warranty

    Ultraview Corporation does not warrant that the operation of the hardware, software or firmware products will be uninterrupted or error free. Ultraview products are not intended to be used as critical components in life support systems, aircraft, military systems or other systems whose failure to perform can reasonably be expected to cause significant injury to humans.
  • Page 5: Introduction

    UUT’s configuration space, for quick board swapping without system shutdown or reboot. MODEL: PCIeEXT-16HOT The PCIeEXT-16HOT is a live insertion 16 lane PCI Express (PCIe) bus extender card supporting x16, x8, x4, x2 and x1 PCIe cards. PCIe signal integrity requirements are met with high-speed trace layout parameters (controlled high impedance and low ground inductance).
  • Page 6: Features

    Test points with 1V/A outputs indicate current consumption of UUT on +5V, +3.3V, and VIO. • Current limiting prevents most damage on +12, +3.3, +3.3AUX supplies. • Selectable power limit switch with 15, 25 and 35 watt cutoff values, and overload LED. r1v05 Page 6 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 7: Installation

    INSTALLATION PCIeEXT-16HOT: To install the PCIe extender, power down the host computer and install the PCIeEXT-16HOT into a x16 PCIe slot on the motherboard. Properly secure the extender by installing a retention screw through the metal bracket into the host system, and engage the retention mechanism (if present). For proper operation, the PCIeEXT-16HOT must be installed in a PCIe slot with all voltages (+12, +3.3, +3.3aux)
  • Page 8: External Power: (Optional And Risky)

    5V or Universal (3.3V and 5V capable) board to be inserted. In the rare case that you have a 3.3V-only board-under-test, the Ultraview PCIEXT64U must be used, but that model is not recommended for most high-volume applications, due to the ability for some boards-under-test to be installed in a misaligned manner.
  • Page 9: Live (Hot) Insertion

    This is done by installing the “DISABLE BUS SWITCHES ALWYS” jumper. This feature is useful for avoiding system crashes while programming FPGAs on the UUT, although the system cannot communicate with the UUT with this jumper in place. r1v05 Page 9 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 10: Live Insertion Software

    UUT (of the same type as the one removed). Once you are in the correct window (entitled “Edit PCI Configuration Space”) for your UUT, the r1v05 Page 10 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 11 UUT. Every time the system is re-booted, you must have your UUT installed in the extender and the slot power switch turned ON for correct live insertion operation. r1v05 Page 11 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 12: Installing Command Line Software Under 32-Bit Windows 7/Vista/Xp

    4. Typing “liveinsert” will show the usage cases of the program. NOTE: The Ultraview Live Insertion software uses an unsigned driver. Depending on your system type and security settings, it may be necessary to disable driver signature enforcement. In order to do this in most Windows™...
  • Page 13 Therefore, on each system reboot, you should make a new disk file, and should not use the pre-existing “live.dat” file. r1v05 Page 13 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 14: Installing Software Under Linux

    Device #14 = 00:0e.0 Class 0604: Device 10de:0375 (rev a2) Device #15 = 00:0f.0 Class 0604: Device 10de:0377 (rev a2) Device #16 = 00:18.0 Class 0600: Device 1022:1100 Device #17 = 00:18.1 Class 0600: Device 1022:1101 r1v05 Page 14 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 15 The newly installed UUT is now ready for your user program to access. You may use the board, later un-install it, and then replace it with yet another board by repeating the above process. If at any point r1v05 Page 15 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 16 If the system is re-booted, some of the configuration data written to your board may change. Therefore, on each system reboot, you should make a new disk file, and should not use the preexisting live.dat file. r1v05 Page 16 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 17: Current Measurement Test Points

    CURRENT MEASUREMENT TEST POINTS PCIeEXT-16HOT: The PCIeEXT-16HOT allows real-time measurement of power consumption during board operation. A voltmeter or oscilloscope can be connected with it's positive (+) lead to either the +12 CURR, +3.3 CURR or +3.3AUX CURR white test points, and its negative (-) lead to the black GND test point. The voltage output on these test points has a 1:1 Volt-to-Ampere correspondence.
  • Page 18: Pcieext-16Hot Advanced Features

    For such systems, installing the jumper at the M1 pair will cause the power-un ramp to approximately 600 microseconds. r1v05 Page 18 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
  • Page 19: In Case Of Trouble

    These devices require the device driver to be reloaded after the configuration space is re-instated. r1v05 Page 19 of 19 Copyright © 2008 – 2010 Ultraview Corporation...
