PCIEXT64U / UB PCI bus 32/64-Bit
Universal 5/3.3v Live Insertion Bus Extender
With software for Windows Vista, XP, 2K, 98,95
WARNING! EMPLOY ESD PROTECTION MEASURES AT ALL
TIMES WHEN USING A BUS EXTENDER TO PREVENT
DAMAGE TO SYSTEM, EXTENDER AND UNIT-UNDER-TEST
INTRODUCTION:
FEATURES:
LIVE (HOT) INSERTION:
INSTALLING THE PCIEXT64U OR PCIEXT64UB INTO A SYSTEM:
EXTERNAL POWER: (OPTIONAL AND RISKY)
LIVE INSERTION SOFTWARE FOR WINDOWS VISTATM, XPTM, 2000, 98 AND 95
LIMITED WARRANTY
5/3/2010
Page 1
ULTRAVIEW CORPORATION
34 CANYON VIEW, ORINDA, CA
PHONE (925) 253-2960
User Manual
REV. I 5/3/10
- TABLE OF CONTENTS -
COPYRIGHT c 2010 Ultraview Corporation
94563
FAX (925) 253-4894
(925) 253-2960
www.ultraviewcorp.com
2
2
2
4
5
6
7
9
Advertisement
Related Manuals for UltraView PCIEXT64U
Summary of Contents for UltraView PCIEXT64U
- Page 1 DAMAGE TO SYSTEM, EXTENDER AND UNIT-UNDER-TEST - TABLE OF CONTENTS - INTRODUCTION: FEATURES: LIVE (HOT) INSERTION: INSTALLING THE PCIEXT64U OR PCIEXT64UB INTO A SYSTEM: EXTERNAL POWER: (OPTIONAL AND RISKY) LIVE INSERTION SOFTWARE FOR WINDOWS VISTATM, XPTM, 2000, 98 AND 95 LIMITED WARRANTY 5/3/2010 (925) 253-2960 www.ultraviewcorp.com...
-
Page 2: Block Diagram
User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB INTRODUCTION: FEATURES: The PCI-EXT64U and PCIEXT64UB are General: high-speed 32/64 Bit PCI Bus Extender Cards with 5 Volt, 3.3V and VIO Power LEDs switchable bus isolation switches supporting 32 and... - Page 3 User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB Power switch off, which removes power and isolates all Power Limit Switch: signals to the connector of the UUT. The POWER LIMIT switch allows selection of a power With the Slot Power switch off, a user can then remove limit value of 15, 25 or 35 watts.
- Page 4 User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB You may control the Slot Power via a software driven parallel port signal, or other TTL control signal, by simply installing a small N-channel FET (such as BS170) DO NOT INSTALL THE +12V and -12V ENABLE as shown in the photo on the previous page.
- Page 5 User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB a board with 5V signaling environment (despite the Remember that the SLOT POWER switch on the PCIEXT64U or UB being installed in a 3V slot), but only PCIEXT64U or UB must always remain off when using external power.
- Page 6 User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB Live Insertion Software for Windows the contents of these registers. We just want to save the register contents, so that we can power off and remove Vista , XP...
- Page 7 User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB Installing and running PCINT.EXE under We just save the contents of these registers, so that we can power off and remove the UUT and then later restore 32-bit Windows Vista...
-
Page 8: Limited Warranty
User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB contents to a new UUT from the saved file, as the If you suspect this problem is occurring, try the registers are not always configured with the same base PCIEXT64U or UB in a different system. - Page 9 User Manual ~ UNIVERSAL PCI BUS EXTENDER Model PCIEXT64U and PCIEXT64UB 5/3/2010- REV I (925) 253-2960 COPYRIGHT 2010 Ultraview Corporation...
