- Page 1 RTX 7234 Quickguide RTX7234 consists of: RTX7232 Headset RTX7431 Base Station Technical Reference Document Version 1.0 © Mar-2018 RTX A/S, Denmark...
-
Page 2: Part Overview
Thank you for purchasing the RTX7234 headset. In this quick guide, you will find all necessary information regarding your new RTX7234 headset. RTX 7234 Key features: • Wideband audio • Noise-cancelling microphone • DSP assisted echo & noise-cancellation • Convertible wearing styles: Headband, Ear-hook and neckband •... -
Page 3: What Is In The Box
Press the top of the right ear cushions (the one with the boom arm) and tip the headset to the left. You will feel a soft click when the headset releases. WEARING THE HEADSET: All RTX corded headsets have a flexible and adjustable headband. For best audio experience the microphone should be placed on the left ear. -
Page 4: Adjusting The Headband
Adjusting the headband: Place the headband on your head with the headset on your ear, and adjust the headband for a comfortable fit. Positioning the microphone: For optimal sound quality, adjust the bendable boom arm until it is right in front of your mouth and less than 3-4 cm (1,25-1,5”) away. -
Page 5: Rotating The Bendable Boom Arm
Rotating the bendable boom arm: The boom arm can be rotated 270° Replacing the ear cushions: To replace the ear cushions, softly remove the old ear cushions with your fingers and gently attach the new ones. -
Page 6: How To Charge
HOW TO CHARGE: Connect the base station into a wall charger, using the power plug that is delivered with the headset. Place the headset in the base station. (The earcup with the boom arm goes into the base station) It takes 3 hours to fully charge the headset. The headset can only by powered, by AC Power plug Battery status: The LED on the charging cradle have different battery status indicators. -
Page 7: How To Connect
HOW TO CONNECT: Simply plug-in the RJ9, RJ12 or RJ45 cable into the phone. HOW TO USE: Left ear cup touch functions. There are 3 touch terms: Short press – 300 ms to 1,5 sec press Double Press (two short presses) Long Press –... -
Page 8: Touch Area
Touch area Status Mute light Microphone Muted Microphone Un-Muted Answer Call Short press End Call Double press, when call is active Reject Call Double press Volume up Slide up Volume Down Slide down Mute Short press, when call is active Un-mute Short press, when call is muted Put call on hold... -
Page 9: Configuration Tool
Firmware update Not ready yet Support: For support please contact productsupport@rtx.dk Security: Important safety information: Read the instruction manual carefully before using this product. If this product is passed on to a third party, this manual must follow the product. - Page 10 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 11 RTX 7232 Quickguide RTX7232 consists of: RTX7232 Headset RTX7441 Base Station Technical Reference Document Version 1.0 © Mar-2018 RTX A/S, Denmark...
- Page 12 Thank you for purchasing the RTX7232 headset. In this quick guide, you will find all necessary information regarding your new RTX7232 headset. RTX 7232 Key features: • Wideband audio • Noise-cancelling microphone • DSP assisted echo & noise-cancellation • Convertible wearing styles: Headband, Ear-hook and neckband •...
- Page 13 Press the top of the right ear cushions (the one with the boom arm) and tip the headset to the left. You will feel a soft click when the headset releases. WEARING THE HEADSET: All RTX corded headsets have a flexible and adjustable headband. For best audio experience the microphone should be placed on the left ear. Adjusting the headband:...
- Page 14 Positioning the microphone: For optimal sound quality, adjust the bendable boom arm until it is right in front of your mouth and less than 3-4 cm (1,25-1,5”) away. Rotating the bendable boom arm: The boom arm can be rotated 270°...
- Page 15 Replacing the ear Cushions: To replace the ear Cushions, softly remove the old ear Cushions with your fingers and gently attach the new ones.
- Page 16 HOW TO CHARGE: Connect the base station into a wall charger, using the power plug that is delivered with the headset. Place the headset in the base station. (The earcup with the boom arm goes into the base station) It takes 3 hours to fully charge the headset. The headset can only by powered, by AC Power plug Battery status: The LED on the charging cradle have different battery status indicators.
- Page 17 HOW TO CONNECT: The first time you plug-in the USB cable (Into base Station and PC), the headset driver will automatically load and the headset is now ready for use. HOW TO USE: Left ear cup touch functions. There are 3 touch terms: Short press –...
- Page 18 Touch area Status Mute light Microphone Muted Microphone Un-Muted Answer Call Short press End Call Double press, when call is active Reject Call Double press Volume up Slide up Volume Down Slide down Mute Short press, when call is active Un-mute Short press, when call is muted Put call on hold...
- Page 19 Firmware update Not ready yet Support: For support please contact productsupport@rtx.dk Security: Important safety information: Read the instruction manual carefully before using this product. If this product is passed on to a third party, this manual must follow the product.
- Page 20 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
