- Page 1 CX6182 Clex prime Electronic double knob cylinder Operating and Assembly Manual...
- Page 2 CX6182 ABLE OF CONTENTS Imprint Operating and assembly manual (english) Electronic double knob cylinder CX6182 Document number: 07C6 Version: 1.01 Status as on: 04.07.2018 Manufacturer Uhlmann & Zacher GmbH Gutenbergstraße 2–4 97297 Waldbüttelbrunn Germany Phone: +49 931 40672-0 E-Mail: contact@UundZ.de http://www.UundZ.de...
-
Page 3: Table Of Contents
CX6182 ABLE OF CONTENTS Table of contents About this document ................ 3 Warnings .................... 3 Symbols ....................3 Safety .................... 4 Proper use ..................4 Improper use ..................4 General safety instructions ..............4 Product description ................5 Functional description ................5 Design .................... -
Page 4: About This Document
CX6182). It is part of the product and contains important information that is necessary for proper operation and maintenance. This operating and assembly manual is valid for all versions of CX6182 and is intended for technicians, who are responsible for assembling and disassembling, as well as for end customers. -
Page 5: Safety
DIN lock with Europrofile. Only the components approved by Uhlmann & Zacher should be used for installation. The CX6182 can be used in interior as well as exterior areas (depending on the product version). Improper use... -
Page 6: Product Description
Product description Functional description The electronic double knob cylinder CX6182 is a product in the Clex prime system. The reading unit, the communication electronics, the mechanical system and power supply, are integrated within the knob module on the protected inside. - Page 7 3.1.4 Radio network If a corresponding radio network is installed in the building, then the knob cylinder CX6182 can be integrated with this network. The following functions can be then be executed via radio: Programming authorizations ...
- Page 8 3.1.6 Battery management The electronic double knob cylinder CX6182 comes with a battery management system, which indicates the need for battery replacement by means of a visible and audio signal when the battery power reduces (capacity loss) during the last 1,000 operations of battery (see chapter 7.2.1 battery replacement).
- Page 9 CX6182 RODUCT DESCRIPTION 3.1.7 Event log The last 512 events of the knob cylinder are stored in the event log. The following events are logged: Not authorized Authorized Service opening Time switching Open Time switching Close ...
-
Page 10: Design
CX6182 RODUCT DESCRIPTION Design Outer knob Sleeve-locking pin Fixing screw Inner knob Cylinder casing Knob sleeve Battery Versions Different versions of the electronic double knob cylinder are available for selection: For inside or outside use Security version ... -
Page 11: Technical Data
CX6182 RODUCT DESCRIPTION Technical data 3.4.1 General technical data Description Value Cylinder lengths From 30/30 mm to 200/200 mm in 5-mm steps Dimensions of the Length 44.3 mm outer knob Diameter 31.4 mm Dimensions of the Length 42.7 mm inner knob Diameter 40.0 mm... -
Page 12: Management Accessories
CX6182 RODUCT DESCRIPTION Management accessories The components of the Clex prime system described below are used to manage a Clex prime locking system. 3.5.1 CX6530 Keyvi management software The locking system can be managed centrally and conveniently from the PC using the Keyvi management software for Clex prime. -
Page 13: Assembly
Assembly Assembly instructions 4.1.1 General assembly instructions Before assembling the CX6182 knob cylinder in a fire/smoke-resistant door, please check the fire certification to ensure conformity. Carry out the assembly necessarily with the door open. Ensure that the latches or seals fitted to the door do not hinder the proper operation of the CX6182. -
Page 14: Assembly
CX6182 SSEMBLY Assembly Insert cylinder casing into the lock. The cylinder body must not project outside its enclosing fitting by more than 1 to 3 mm, but it should not also be installed sunk in the upholstery. Fasten cylinder casing with fixing screw. Tighten the fixing screw by hand, do ... - Page 15 CX6182 SSEMBLY The electronic inner knob is mounted into the cylinder casing by inserting and turning at the same time.
-
Page 16: Commissioning
CX6182 OMMISSIONING Commissioning Managing the locking system The locking system can be managed using the Keyvi management software. Before a locking system unit can be used, it has to be personalized and the settings have to be customized. 5.1.1 Personalization... -
Page 17: Operation
CX6182 PERATION Operation Automatic wake up The knob cylinder is in sleep mode as long as it is not used. To check the authorization of a key, it needs to be woken up from the sleep mode. This normally happens automatically if a key is held in front of the reader unit. -
Page 18: Toggling The Door Handle
CX6182 PERATION The knob module is now engaged, the door can be locked and unlocked by rotating the knob module. When the door is in unlocked state, the door can be opened with the door handle. The time duration for which the knob cylinder remains engaged can be set (1 to 15 seconds, the default value is 5 seconds). -
Page 19: Indications
CX6182 PERATION Indications Function Signal (audible and visible) and explanation Sleep mode No audible or visible signal ● ● Start of service mode Two audible signals of increasing intensity but equal length ● ● End of service mode Two audible signals of decreasing intensity but equal length... -
Page 20: Cleaning And Maintenance
CX6182 LEANING AND MAINTENANCE Cleaning and maintenance Cleaning Clean the knob cylinder only with a commercially available household cleaning agent and a damp cloth. Do not use any abrasive or caustic cleaning agents. Maintenance 7.2.1 Replacing the battery... - Page 21 CX6182 LEANING AND MAINTENANCE Remove empty batteries and insert the new batteries, paying attention to the polarity. Press sleeve locking pins and again slide on the knob module sleeve. Ensure that the locking pin latches correctly in the sleeve.
- Page 22 CX6182 LEANING AND MAINTENANCE 7.2.2 Replacing the sealing ring ATTENTION Damage to the sealing ring caused by improper handling Do not use any sharp objects and do not stretch the sealing ring more than what is required for mounting.
-
Page 23: Faults During Operation
CX6182 AULTS DURING OPERATION Faults during operation Fault indications Function Audible signal Explanation Memory fault / 5 long audible ▬ ▬ ▬ ▬ ▬ ● configuration fault signals, 1 brief audible signal Engaging fault 5 long audible ▬ ▬ ▬ ▬ ▬ ● ●... -
Page 24: Disassembly And Disposal
CX6182 ISASSEMBLY AND DISPOSAL Disassembly and disposal Disassembly Bring the knob module into the disassembly position by presenting a key with disassembly authorization or using ClexTouch CX6522 or the service device CX6510. Turn the knob module by lightly pulling it until it can be removed from the ... -
Page 25: Disposal
CX6182 ISASSEMBLY AND DISPOSAL Disposal Do not dispose the knob cylinder with domestic waste. Disposal should be in accordance with the European Directive 2002/96/EC at a collection point for electrical waste. Defective or used batteries should be recycled in accordance with the ... -
Page 26: Glossary
CX6182 LOSSARY Glossary Definition Description ClexTouch Software for Windows handheld computer for configuring a locking system Intrusion detection system Keyvi Software for managing a locking system MIFARE ® Technology for contactless transfer of identification data Data carrier that contains the authorization information. This can, for example, be an ISO card or a chip.
