- Page 1 R1580MB Multimedia Speaker User manual Page 1: What’s in the Box Box Contents: Passive speaker Active speaker Remote control RCA to RCA audio cable (1.7M/5.5ft) 3.5mm to RCA audio cable (1.7M/5.5ft) Speaker connecting cable (5M/16.4ft) User manual...
- Page 2 Page2 Speaker control PC/AUX input MIC1 port MIC2 port Bass volume knob Power switch Power cable Connect to passive speaker Connect to active speaker Microphone volume adjustment 10. PC/AUX/Bluetooth volume adjustment 11. Master volume knob Press: audio source mode selection Press and hold: disconnect Bluetooth under Bluetooth mode;...
- Page 3 Page 3 Remote control ON/standby Volume increase Press: Bluetooth Press and hold: Disconnect Bluetooth Volume decrease PC/AUX input Previous track (for Bluetooth Next track (for Bluetooth mode) mode) Play/pause (for Bluetooth mode) Mute/de-mute Battery loading: Please refer to the illustration to open the battery compartment, insert the CR 2025 battery and close the compartment.
- Page 4 2. Set your Bluetooth device (mobile phone, tablet etc.) to search and connect "EDIFIER R1580MB". Note: * The Bluetooth on R1580MB can only be searched and connected after the speaker switched into Bluetooth mode. The existing Bluetooth connection will be disconnected once the speaker is switched into other audio inputs.
- Page 5 Page 5 Bluetooth operation Specifications Power output: R/L: 21W + 21W Noise level: ≤25dB(A) Frequency response: 55Hz~20KHz Microphone dynamic range: -50~30dBV Input sensitivity: PC: 700±50mV AUX: 550±50mV Bluetooth: 550±50mFFs Treble unit: ½ inch (13mm) Mid-range and bass unit: 4 inch (116mm) Bluetooth version: V4.0, A2DP and AVRCP protocol Input type:...
