RFRemotech MS12Q Manual

RFRemotech MS12Q Manual

Wireless firing system. for pyrotechnics and fireworks show

Advertisement

Quick Links

Model:RF12A
MS12Q
Wireless Firing System
For Pyrotechnics and Fireworks Show
RFRemotech Radio Frequency Remote Technology
Remote Control Products, Remote Controllable Service

Warnings:

The purpose of this device is to cause the ignition of fireworks. Fireworks are explosives and may cause
personal injuries or death to yourself or others, including spectators. You are responsible for the safe and
legal use of this device according to the laws and regulations of your country and/or state/province/district.
RFRemotech is not responsible for illegal or unsafe use of this device. The buyer/user assumes all
responsibility and liability in the use of this device and further agrees, by purchase and/or use of this device,
to indemnify and hold harmless RFRemotech against all liability for injury, loss, or damage direct or
consequential arising out of the use of, or inability to use this device.
You must perform the safety tests (Page 4) every time you use the system.
