T1
User Manual V1.4
2016.07.20 Revision
For Firmware Version V3.30 or above
& Adjusting-parameter software Version V1.40 or above
Please strictly follow these steps to mount and use this product, as well as to install adjusting-parameter software
on your computer or phone.
Thank you for purchasing TopXGun product. There are web pages of T1 at our website www.topxgun.com, which is
updated regularly. You can obtain product information, technical updates and manual corrections. TopXGun
recommends you to download and use the newest user manual. The information contained in this manual is
subject to change without notice.
This manual is only for basic assembly and configuration; you can obtain more details and advanced instructions
when using adjusting-parameter software, if you find the information on software and user manual are not
consistent, adjusting-parameter software shall prevail.
©2016 TopXGun All Rights Reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T1 and is the answer not in the manual?

Questions and answers

Related Manuals for TopXGun T1

Summary of Contents for TopXGun T1

  • Page 1 Please strictly follow these steps to mount and use this product, as well as to install adjusting-parameter software on your computer or phone. Thank you for purchasing TopXGun product. There are web pages of T1 at our website www.topxgun.com, which is updated regularly. You can obtain product information, technical updates and manual corrections. TopXGun recommends you to download and use the newest user manual.

  • Page 2: Table Of Contents

    LIGHT MODE AND CORRESPONDING RESPONDING ........................... 15 INDICATOR DESCRIPTIONS ..............................17 IRMWARE PDATE ..............................20 IRST TEST FLIGHT ADVANCED FUNCTIONS ............................22 ..............................22 ............................22 NTELLIGENT DIRECTION ............................22 AIL SAFE AND ............................22 OLTAGE ROTECTION ©2016 TopXGun All Rights Reserved.
  • Page 3 Keep the aircraft away from people, dangerous objects and fragile objects. TopXGun accepts no liability for damage or injuries incurred directly or indirectly from the use of this product in the following conditions: 1.

  • Page 4: Introduction

    Introduction Product introduction TopXGun T1 can be installed on a variety of models from quad-rotor to octo-rotor, it has the characteristics as follows:  Support 9 types of multi-rotor platform  Two basic control modes: Attitude Mode and GPS Mode ...

  • Page 5: Installation & Test

    1 Installation & Test 1.1 Hardware installation Step1. Confirm multi-rotor type, forward direction and rotation direction of the motor/propeller. Figure 1-1 Confirm multi-rotor type Step2. Install the controller unit, connect every part. ©2016 TopXGun All Rights Reserved.
  • Page 6  Connection of ESC: Connect M1～M8 to ESC, T1 supports up to eight motors at most (ESC signal wire is down and earth wire is up ) ...

  • Page 7: Installation And Test For Adjusting-Parameter Software

    1.2 Installation and test for adjusting-parameter software Preparation before installation and configuration T1 flight controller supports PC, Mobile phone to adjust parameters  If you do the configuration on phone, you only have to install phone app and buy bluetooth module, no need to install any driver.
  • Page 8 PC will automatically detect flight control and connect it. When using a USB to connect flight controller and PC, there should be power given to flight controller. Step2. Choose the type of aircraft, as shown in Figure 1-4. ©2016 TopXGun All Rights Reserved.
  • Page 9 1. Set the End Point of CH5 to 30%～70% 2. Set the rudder angle in the range of normal mode. You can verify the Fail-Safe setting by shutting down the transmitter, the control mode will automatically jump to red „Fail-Safe‟ area. ©2016 TopXGun All Rights Reserved.
  • Page 10 2. You can adjust adjust the sensitivity according to the instruction of adjusting-parameter software. 3. You can obtain the best sensitivity of flight by the process of „ test flight and readjusting‟ ©2016 TopXGun All Rights Reserved.
  • Page 11 No matter the auto-return or land in stand point, you can switch CH5 mode twice to terminate low-voltage protection at any time . If the low-voltage protection is triggered, you are unable to switch to any kind of flight mode except for attitude mode and returning mode and landing mode. ©2016 TopXGun All Rights Reserved.

  • Page 12: Unlock And Lock

    1.3 Unlock and lock T1 has only one way to unlock the aircraft, follow the figure 1 to unlock no matter whether you are using Japan TX or US TX, and follow the figure 2 to lock the aircraft. The aircraft will automatically lock after landing with the throttle stick maintaining minimum for 3 seconds.

  • Page 13: Esc And Compass Calibration

    After the MC is repowerd, the motor will After the LED blinks red and blue beep twice, pull the throttle stick to alternatively, it turns to normal indication minimum position within two seconds Figure 1-8 Procedure of T1 ESC calibration ©2016 TopXGun All Rights Reserved.

  • Page 14: Horizontal Calibration

    LIU is normal, which shows that the calibration is successful. Calibration process takes about 25 seconds altogether. If the drone still on one side during the flight attitude mode, you are suggested to do horizontal calibration once again. ©2016 TopXGun All Rights Reserved.

  • Page 15: Fly Test Instructions

    GPS mode, with no roll Fly mode input or pitch input GPS mode, with roll input （2） or pitch input This LED blinks during automatic pilot Automatic pilot mode mode or automatic return mode ©2016 TopXGun All Rights Reserved.
  • Page 16 （N）means LED blinks yellow N times； (2) { }（N）means LED blinks yellow and purple alternatively N times； （∞）means LED continuously blinks； （N）means LED is continuously on for N seconds. ©2016 TopXGun All Rights Reserved.

  • Page 17: Firmware Update

    ‟ button, the system will indicate the firmware version number need to be updated. Then click „yes‟‟ button and firmware update will be conducted. It will be as shown in Figure 2-2 and Figure 2-3. ©2016 TopXGun All Rights Reserved.
  • Page 18 Figure 2-2 Firmware Update 2 ©2016 TopXGun All Rights Reserved.
  • Page 19 Figure 2-3 Firmware Update 3 Step3. After the update is finished, „No available update‟ displayed in the column of „Update‟, it means the current firmware is the latest one as shown in Figure 2-4. ©2016 TopXGun All Rights Reserved.

  • Page 20: First Test Flight

    Please check the following content to avoid the accident.  Check the nose direction,  Check MC installation direction,  Make sure each motor rotating direction is matched  Make sure the connection between every part is solid. ©2016 TopXGun All Rights Reserved.
  • Page 21 Step4. Do every channel operation below 2 meters height , if responding is ok, you can explore the best performance by yourself. ©2016 TopXGun All Rights Reserved.

  • Page 22: Advanced Functions

    There are two levels of low voltage protection, the first level protection has LED warning( ), during （∞）), then lock after second level protection the aircraft will land automatically with LED warning( landed. You can switch to attitude mode to quit protection after automatic landing of low-voltage protection executed. ©2016 TopXGun All Rights Reserved.
