Summary of Contents for Gantner IDL 101

  • Page 1 IDL 101 Instruction Manual...
  • Page 3 IDL 101     Copyright 2004 by GANTNER INSTRUMENTS Test & Measurement GMBH, Schruns (Austria). Copyrights: Operating instructions, manuals and software are protected by copyright ©. All rights are reserved. Copying, duplication, translation, installation in any electronic medium or machine-readable form in whole or in part is prohibited. The sole exception is represented by creation of a back-up copy of software for own use as a safeguard, so far as this is technically possible and recommended by us.
  • Page 4 IDL 101 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 5 We congratulate you on having selected a product of Gantner Instruments Test & Measurement GmbH (in the following: Gantner Instruments). So that our product functions in your installation with safety and to your complete satisfaction, we take this opportunity to familiarize you with the following ground rules: Installation, commissioning, operation and maintenance of the product purchased must be carried out in accordance with instructions, i.e.
  • Page 6 Should you discover any fault with the product or in its accompanying documentation, or have any suggestions for improvement, you may confidently approach either your customer adviser or Gantner Instruments directly. However, even if you just want to tell us that everything has functioned perfectly, we still look forward to hearing from you.
  • Page 7: Table Of Contents

    Digital Inputs/Outputs ............................33 5.3. Internal Reference Voltage........................... 34 5.4. Internal Processing.............................. 34 5.5. Measurement Rate .............................. 35 5.6. Signal Preparation ............................... 35 FUNCTIONAL DESCRIPTION .......................... 36 6.1. Analog Input Variable ............................36 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 8 10.4.2. Telegram Format ..............................77 10.4.3. Instruction Set..............................77 10.4.4. Register Contents ............................... 81 10.5. Sample Program ..............................85 SPECIFICATIONS ............................86 11.1. Power Supply ..............................86 11.2. Signal Inputs/Outputs ............................86 11.3. Signal Processing ..............................86 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 9 11.11. Circuit ................................91 11.12. Accessories ................................. 91 SIMPLIFIED DRAWINGS ..........................93 12.1. Front View ................................93 12.2. Side View ................................93 PINOUT ARRANGEMENTS FOR ANALOG SENSORS ..................94 PINOUT ARRANGEMENTS FOR DIGITAL SENSORS..................95 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 10: General Preliminary Remarks

    Therefore if you have not yet worked with the Datalogger IDL 101 , you should first of all study the manual on hand thoroughly. While initiating or operating the appliance or in case service is required always observe the notices given in this manual.
  • Page 11: System Description

    Thus there are two series of devices at the moment: The modules of the series "100", where the ISM 111 , ISM 112, IDL 100 and IDL 101 belong to, are free configurable, multi-variable sensor modules.
  • Page 12: Features Of Performance

    IDL 101 SYSTEM DESCRIPTION 2.3. Features of Performance The features of performance of the Datalogger IDL 101 are the following: Function: measurement inputs for all common types of sensors for current, voltage, resistance and thermocouples (with ICJ104) several and different sensors can be connected simultaneously...
  • Page 13 (field length/decimals/unit) simple instruction set Shell: compact structural shape attractive design fast mounting snap-on mounting on DIN rail 35 mm (1.4 inch) protection system IP20 detachable terminal strip separate Cold Junction Terminal Module Jack HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 14: Configuration Software Icp 100

    “100“ series (e.g. ISM 111 , ISM 112 , Datalogger IDL 100 and IDL 101 ) individually to their desired application. The channels can be defined in the Variable Settings Table by simple mouse clicks. Additional sensors can be created at any time and inserted to the database.
  • Page 15 SYSTEM DESCRIPTION Column 1 The type of variable is indicated by a short designation. Up to 32 variables can be input and parameterized for the Datalogger IDL 101. The short designations and corresponding channels are: : Analog Input Channel •...
  • Page 16 Possible additional functions for each variable and type of measurement are listed in the Short Description of the Configuration Software ICP 100. In the “Module Settings“ window the location, date and name of the user will be defined. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 17 Additional functions: • Signal filtering • Averaging Test and initiation: • Read out of sensor channels • Pre-setting of setpoint channels • Controlling of digital outputs • Fine adjustment • Tare • Reset HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 18: Installation

    INSTALLATION 3.1. Mounting / Fixing The Datalogger IDL 101 has a snap-on mounting for installation on standard profile rails 35 mm (1.4 inch) according to DIN EN 50022. The four straps on the backside of the module will perform the mounting on the DIN rail. First you push the two straps on the bottom behind the notch of the DIN rail and then you press the module on the DIN rail until the two straps on the top snap in.
  • Page 19: Front Of The Appliance / Pin Assignment

    * The terminal designations A and B are exchanged, compared with the PROFIBUS-definitions, for all devices of the ISM series “100“ and the Datalogger IDL 101. This means that in multi-vendor-systems the bus lines A and B must be exchanged when they are connected to a device of the ISM-line or a Datalogger IDL 101.
  • Page 20: Connection Technique

    Figure 3.2 Connection of the distribution voltage Non-regulated DC voltage between +10 and +30 VDC is sufficient for the power supply of the Datalogger IDL 101 . The input is protected against excess voltage and current and against polarity conversion. The power consumption remains approximately constant over the total voltage range, due to the integrated switching regulator.
  • Page 21: Grounding

    3.7. Grounding The shell of the Datalogger IDL 101 has to be connected to earth. For this purpose an M3-thread for attaching an grounding cable is located on the back side of the shell.
  • Page 22: Bus Connection

    Figure 3.4 Connection of the IDL 101 to the bus A´ B´ RS 485 Fieldbus SUPPLY RS 485 RS 232 DIGITAL INTELLIGENT DATA LOGGER Figure 3.5 Connection of the IDL 101 to the bus by a stub cable HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 23: Sensor Connection

    3.11. Several Sensors at one Module The Datalogger IDL 101 can take up and process sensor signals from several heterogeneous sensors simultaneously. As many sensors can be connected as there are analog and digital signal inputs and outputs available. At the Datalogger IDL 101 this means the maximum of 22 sensors, 6 analog and 16 digital sensors.
  • Page 24 A N A L O G Profile Rail 35 mm (1.4 inch) Rapid Bus Link Plugs ICM 100 Figure 3.7 Connection of two ISM modules to the Datalogger IDL 101 with a Module Jack ICM 100 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 25: Cold Junction Terminal Icj 104

    AGND in the ICJ 104 - terminal strip. Via the resistance thermometer the Datalogger IDL 101 determines the terminal temperature and executes the cold junction compensation. Up to 6 ICJ 104 can be connected to one IDL 101. Figure 3.8 Cold Junction Terminal ICJ 104 HB_IDL101_E_V222.doc...
  • Page 26: Structure Of The Bus Topology

    STRUCTURE OF THE BUS TOPOLOGY The coupling of the Datalogger IDL 101 to a host computer can be performed via the integrated RS-485 interface or via the integrated RS-232 interface. The RS-232 interface is suitable only for point-to-point connections over a maximum distance of 20 m.
  • Page 27: Bus Interface

    The following figures show a few examples for a possible set-up of bus topologies. The meaning of the symbols is: : bus user : repeater : bus termination..Figure 4.2 Simple line structure ....Figure 4.3 Extended line structure HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 28: Number Of Parties

    4.4. Transmission Speed and Line Length The transmission speed with the Datalogger IDL 101 can be adjusted for each protocol. The permissible line lengths depend on the transmission speed. With transmission speeds lower than 93.75 kbps these line lengths amount to 1,200 m (3,900 feet) per bus segment;...
  • Page 29: Bus Cable

    R to ground (DataGround). These resistors provide a defined quiescent potential in case there is no data transmission on the bus. This quiescent potential is level high . HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 30 Notice: The terminal designations A and B are exchanged, compared with the PROFIBUS-definitions, for the Datalogger IDL 101 and all devices of the ISM series “100“ . This means that in multi-vendor-systems the bus lines A and B must be exchanged when they are connected to a Datalogger IDL 101 and a device of the ISM-line.
  • Page 31: Shielding

    These are already branched off before via the protective grounding. The Datalogger IDL 101 does not have a direct shield connection on the device itself. Here the shield of the bus cable can be connected to earth e.g. by so-called shield clamps.
  • Page 32: Pc Bus Connection

    RS-485 drivers is required for conversion purposes. Gantner Instruments offers a compact interface converter with integrated mains power supply called ISK 200 . Mains power supply, bus connection and a separate 24 VDC-output are dc decoupled. The interface converter is also applicable for remote power feeding.
  • Page 33: Equipotential Bonding

    38,400 bps 38,400 bps Table 4.3 Setting variants for address and baud rate for the Datalogger IDL 101 If no other specifications are made on delivery, the sensor modules have address 1 and baud rate 19,200 bps as default. The adjustment can be changed via the bus by means of the Configuration Software ICP100 .
  • Page 34 Adjusting via RS-232 interface with the configuration software: The Datalogger IDL 101 has as an additional to the RS-485 bus interface a RS-232 host interface. Configurations can be programmed over the RS-232 interface as well as over the RS-485 interface with the help of the configurations software ICP100.
  • Page 35: Signal Processing

    5.2. Digital Inputs/Outputs The 16 digital inputs/outputs of the Datalogger IDL 101 can be configured - independent of each other - as inputs or as outputs. The current status (in/out) is signalized by one (for power saving via software disconnectable) LED each.
  • Page 36: Internal Reference Voltage

    Figure 5.2 Internal pull-up resistor at the digital I/Os 5.3. Internal Reference Voltage An internal reference voltage serves to adjust the entire analog signal processing automatically. 5.4. Internal Processing Figure 5.3 Block diagram Datalogger IDL 101 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 37: Measurement Rate

    The averaging interval can be set for all channels same to a value between 1 s and 12 h. The number of measurement values for an averaging depends to the interval and sampling rate (e.g. Interval = 15 s, Sampling rate = 1 s => Number of measurements = 15). HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 38: Functional Description

    IDL 101 FUNCTIONAL DESCRIPTION FUNCTIONAL DESCRIPTION The Datalogger IDL 101 has altogether 32 logical variables for the collection, processing and output of various kinds of sensor information. These 32 variables can be configured as: Analog Input Variable Analog Output Variable...
  • Page 39 U = U1 - U2 Figure 6.2 Measurement of voltage - differential Two types of measurement are available for measurement of voltage with the Datalogger IDL 101 : single-ended and differential measurement. With the single-ended type of measurement the voltage to be measured is injected between an analog input (AIn +) and analog ground (A ).
  • Page 40 I = U / R Figure 6.3 Measurement of current with external shunt For measurement of current with the Datalogger IDL 101 the source of electricity is connected between an analog input (AIn +) and analog ground (A ). The load on the source of electricity that is required for the measuring is regulated by an external resistor R to the amount of 50Ω.
  • Page 41 . The measuring range amounts to between 0 and 2 kΩ and for measuring temperature with a Pt 100 sensor the possible measuring ranges are –40 to +60 °C and –40 to +250 °C. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 42 IDL 101 FUNCTIONAL DESCRIPTION Notice: The Datalogger IDL 101 supports resistance measuring in 2 and 4-wire technique. With resistance measuring in 2-wire technique the supply lines cause an additional fall of potential, thus distorting the measuring result and influencing the measuring accuracy. Therefore it is necessary to pay attention specially with resistance measuring in 2- wire-technique to use as low-impedance leads as possible to the sensors and to make sure that the leads are well- connected with the data logger and the sensor.
  • Page 43 It can be measured and can be used for temperature measurement purposes. With the Datalogger IDL 101 the thermoelectric voltage is measured differentially. Since thermocouples can only measure a temperature difference (difference between temperature to be measured and temperature at the connecting terminals on the sensor module), a terminal temperature or a known temperature reference also have to be determined.
  • Page 44: Analog Output Channel

    0 and 10 V by means of the Configuration Software ICP 100. Via the analog output (AOut +, AGND) at the Datalogger IDL 101 actual measuring values or sensor variables can be output depending on the configuration. Thus for example it is possible to assign the value of a Setpoint Channel or the result of an Arithmetic Channel to the Analog Output Channel and to output them as analog set values.
  • Page 45: Digital Input Variable

    For the acquisition of digital status information (on/off, closed/open, left/right, etc.) the signal applied at the digital input is collected and is held ready for further processing in the Datalogger IDL 101 or for transmission via bus. The digital input is set (switch closed) as long as the applied signal voltage remains under the threshold value of 1.0 V.
  • Page 46 Notice: Frequency measurements can only be performed at the digital inputs I/O 01 to I/O 06 at 2000 Hz. As soon as more than 6 frequency measurements have to be realized, the high-end frequency is 100Hz. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 47 When configuring a digital input as a progressive counter the Datalogger IDL 101 constantly monitors the digital input for a signal variation. If a negative signal edge (1 -> 0) occurs at the input, the current result is increased by 1.
  • Page 48: Digital Output Variable

    Via the digital inputs/outputs I/O 01 to I/O 16 on the Datalogger IDL 101 digital status information or measured quantities and sensor variables respectively can be output in digital form, according to the configuration. Digital status information can be withdrawn from the process (Process Out).
  • Page 49 The distribution voltage of the load can range from 10 to 30 VDC (load current max. 100mA). It has to be either supplied externally or be picked up by the power supply of the data logger. The status of the digital output can be scanned as 1/0 information via bus. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 50 The distribution voltage of the load can amount from 10 up to 30 VDC (load current max. 100mA). It has to be supplied externally or picked up by the power supply of the data logger. The status of the digital output can be scanned as 1/0 information via bus. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 51: Arithmetic Channel

    Spec2 Application specific function 3 Spec3 Application specific function 4 Spec4 No specifications available as the time depends to the specific function and the program. Table 6.3 Arithmetic operators and the calculation times HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 52 Special functions for their solution the commands are not sufficient, can be done by an application respectively user specific download program for the Datalogger IDL 101 . Notice: The calculation time of an Arithmetic Variable is 0.6 ms. The overall calculation time is the sum of the times of all operands in the formula plus 0.6 ms.
  • Page 53: Setpoint Variable

    The Alarm Variable has the same features as the process-controlled Digital Output Variable, the only difference being that the status information is not output locally at the digital output, but can only be scanned via the bus. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 54: Threshold Values

    6.8. Error Handling The Datalogger IDL 101 can independently detect certain defects, which are consequence of a line break, short circuit, or communication interrupt for example. For these defects the user can preset a certain behavior for the module via the Configuration Software ICP 100 .
  • Page 55: Master Function

    (slaves). This technique is used to enlarge the number of inputs and outputs of the Datalogger IDL 101 if the 6 analog inputs and 16 digital inputs/outputs of the data logger are not sufficient. Modules of the series “ ISM 100 “ can be connected to the RS-485 interface as slaves.
  • Page 56: Normal Mode

    Notice: In an RS-485 bus system only one master is possible. If more than one Datalogger IDL 101 is installed in an RS-485 bus system only one device can be set to the master function!
  • Page 57: Transparent Mode

    7.1.2. Transparent Mode In service mode “Transparent“ the Datalogger IDL 101 operates as interface converter from RS-232 to RS-485. This means the data logger is connected to the host via RS-232 interface and further modules, which can be handled by the host, are connected at the RS-485 interface.
  • Page 58: Data Storage

    8.1. General Remarks to Data Storage The Datalogger IDL 101 has 512 Kbytes RAM memory. For data recording 508 Kbytes memory is available as circulate memory. If this memory is full, the oldest record will be overwritten if a new record is stored. If the memory is read out, the oldest record will be output and the corresponding space enabled.
  • Page 59: Modes Of Data Storage

    DATA STORAGE 8.2. Modes of Data Storage 8.2.1. No Data Storage In this mode the Datalogger IDL 101 operates as measuring module, records and processes measuring values and sends the results on inquiry to a superposition host. 8.2.2. Continuous Data Storage The measured values, selected for storage, will continuously be written to internal or external memory with the pre-set averaging interval.
  • Page 60: Initiation And Test

    A telegram has just been dispatched from the data logger via bus to a control system or to a PC. Table 9.1 Meanings of the LEDs (flash frequency approx. 1Hz) HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 61: Communication

    10.1. General Remarks 10.1.1. Bus Interface The bus interface of the Datalogger IDL 101 is a RS485 interface according to the specifications of the EIA-RS485 USA standard. The host interface is a RS-232 interface according to the specifications of the EIA-RS232.
  • Page 62: Output Format

    E . 3 0 9 4 0 5 0 . 3 0 9 4 0 E . 3 0 9 4 0 0 Table 10.5 Output formats for transmission in the ASCII-format ("_":blank). HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 63 With a transmission in PROFIBUS- and MODBUS-format no identification key is given in case of an overflow. The number of decimals must, however, not be selected too large, if the value is to be transmitted in integer-format (range of values in integer-format limited to -32768 to +32767). HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 64: Ascii-Protocol

    The corresponding is valid for requests with check sum. Furthermore there are two short telegrams with a length of one character each. With these telegrams a positive or negative acknowledge respectively can be performed. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 65 DA address. ResDataUnit : Response-Data-Unit (length = 1 ... n byte): The Response-Data-Unit identifies a data field in the response telegram, which contains the data for the calling communication partner. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 66: Instruction Set

    # aa W kk d..d cc <cr> without $ aa W kk d..d <cr> Reset/tare a channel with # aa D kk cc <cr> without $ aa D kk <cr> HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 67 # aa T1 cc <cr> without $ aa T1 <cr> Transparent mode off (only at masterfunction) with # aa T0 cc <cr> without $ aa T= <cr> Table 10.9 Instruction set in ASCII-protocol HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 68: Instruction Parameters

    ... “A“ : application specific prog. y.yy : version x ... “R“ : MODBUS-RTU program device information (s...s) length = 28 char <location> ......ASCII ............20 char <serial number>....ASCII ............6 char <number of variables>..ASCII ............2 char HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 69 Coding <channel configuration>: Bit1: Tare/Reset enable Bit2: Average value storage configured Coding <Data Format>: ASCII "0": no format ASCII "1": B O O L ASCII "2": INTEGER ASCII "3": R E A L HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 70 <Minute>......ASCII ..........2 char <Second> ......ASCII ..........2 char Measuring rate and averaging interval (n...n) length = 7 char <Measuring rate in sec.> ..ASCII ..........2 char <Averaging interval in sec.> .ASCII ..........5 char HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 71: Profibus-Protocol

    6.8, error handling) can be adjusted by means of the Configuration Software ICP100 . The default values for the time T is 1.5 CT and for the time T 3 CT. 2max HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 72: Telegram Format

    IDL 101 COMMUNICATION 10.3.2. Telegram Format For data transmission via PROFIBUS the following telegram formats are relevant for the Datalogger IDL 101 : Formats with fixed information section length without data field: Formats with variable information section length with data field:...
  • Page 73 The Short-Acknowledgement-Frame SC identifies a telegram that can be sent back to the communication partner as an acknowledgement. With SDA-requests it can be used as a positive receive acknowledgement. With SRD-requests it can be returned as a negative acknowledgement. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 74: Instruction Set

    With PROFIBUS every bus user has so-called "service access points" (SAPs), via which he can exchange data with the communication partners. With the Datalogger IDL 101 the SAPs are used for identifying (addressing) the various data and commands of the data logger. By specifying the DSAP-number (DSAP: Destination SAP) in the data field of the request telegram the data logger can be informed as to which data shall be transmitted or which function the data logger shall carry out.
  • Page 75: Instruction Parameters

    : monitor program x ... “T“ : calibration and test program x ... “U“ : universal program x ... “A“ : application specific program y.yy : version x ... “R“ : MODBUS-RTU program HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 76 Digital Output Var. (DO) hex 09: PID Controller (CO) hex 06: Analog Output (AO) Coding <data format>: hex 00: no format hex 01: B O O L hex 02: INTEGER hex 03: R E A L HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 77 If a bit is set in the <tare/reset> byte, the corresponding sensor variable is tared or reset respectively. The values following the <tare/reset> byte are allocated to the writeable variables of the data logger, according to the order of their appearance. Writeable variables are Setpoint Variables and Digital Output Variables. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 78: Modbus-Protocol

    6.8, error handling) can be adjusted by means of the Configuration Software ICP 100 . The default values for the time T is 1 ms and for the time T 3.5 CT. 2min 3max HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 79: Telegram Format

    (read/write register) 04 hex read input register (read only register) 06 hex preset single register 08 hex Diagnostic 10 hex preset multiple register Table 10.15 MODBUS commands supported by the IDL 101 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 80 REGSTA REGNUM response telegram BYTNUM ADR ..... IDL 101 address ( hex 00..7F) FNR ..... function number ( hex 03) REGSTA ....address of the first register to be read REGNUM ....number of registers to be read BYTNUM ....number of databytes (max. 64) D0 - Dn ....
  • Page 81 REGADR DATA response telegram REGADR DATA ADR ..... IDL 101 address ( hex 00..7F) FNR ..... function number ( hex 06) REGADR ....address of the register to be written DATA ....dataword ( hex 0000..FFFF) CRC ..... check sum...
  • Page 82 SUBFCT DATA response telegram SUBFCT DATA ADR ..... IDL 101 address ( hex 00..7F) FNR ..... function number ( hex 08) SUBFCT ....subfunction number ( hex 0000) DATA ....dataword ( hex A537) CRC ..... check sum CRC polynomial: u...
  • Page 83: Register Contents

    IDL 101 COMMUNICATION ADR ..... IDL 101 address ( hex 00..7F) FNR ..... function number ( hex 10) REGSTA ....address of the first register to be written REGNUM ....number of registers to be written BYTNUM ....number of databytes (max. 64) D0 - Dn ....
  • Page 84 02 Arithmetic Variable (AR) hex 03 Digital Output Variable (DO) hex 04 Digital Input Variable (DI) hex 05 Setpoint Variable (VO) hex 06 Alarm Variable (AL) hex 09 PID Controller (CO) hex 10 Analog Output (AO) HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 85 : monitor program x ... “U“ : universal program x ... “T“ : calibration and test program x ... “A“ : application specific program x ... “R“ : MODBUS-RTU program y.yy : version HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 86 20076 ... ro/rw.....variable 60 real value high word......0 ... 65535 20077 ... ro/rw.....variable 60 real value low word......0 ... 65535 Attention: The low word and the high word of a variable always have to be read or written simultaneously. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 87: Sample Program

    Notice: In some programming languages the initialization of the serial interface with even parity and 8 data bits will not be supported. The COM-interface in the PC and the bus interface in the sensor module have to be adjusted and configured to "(N)o parity". HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 88: Specifications

    (1) Data for T=20°C and 80% of the measuring range, (2) Data based on component specifications. All values valid after a warm up phase of 15 minutes. The percentage correspondent to the measuring range. HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 89: Measurement Of Current

    All values valid after a warm up phase of 15 minutes. The percentage correspondent to the measuring range. 11.5. Analog Output (1 per Module) Output Voltage: 0 .. 10 V Accuracy: 0.5 % Resolution: 40 mV Swing-In-Time: 10 ms HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 90: Digital Inputs/Outputs (6 Per Module)

    9.600 / 19.200 bps □ 11.8. Operating Conditions Ambient temperature: -30 to +60 °C □ Storing temperature: -40 to +85 °C □ Humidity: 0 to 95 % at +50 °C, non condensing □ HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 91: Electromagnetic Compatibility

    The Datalogger IDL 101 meets the protection requirements of the EMC-guidelines 89/336/EEC. EN50081-1:92/-2:93 (interference emission) and EN50082-1:92/-2:95 (interference immunity) for industrial and residential areas. The stricter requirements have been applied. At present, further standards concerning CE-marking are not relevant for the IDL 101 . The IDL 101 is Labelled with the CE-Sign.
  • Page 92 A release of the watchdog or a reset with an automatic restart without any loss of data or change of the operating mode. Influences during test value recording, -processing and -trans-mission if they are short, sporadic and self- recovering (e.g. short interrupt of test value updating, checksum error, delayed answer, timeout,...) HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 93: Chassis

    Others enable a larger number of data logger to be connected with one another. A PC can be connected to a bus via an interface converter or directly (RS-232) to the Datalogger IDL 101 , so that the whole system by means of the Configuration Software ICP 100 can be rapidly installed.
  • Page 94 To convert from RS 232 to RS 485 or to regenerate signals in RS 485 field bus systems up to 500 kbps ICJ 104 4-Contact Cold Junction Terminal For connection thermocouples to the IDL 101 / IDL 100 ICJ 108 8-Contact Cold Junction Terminal For connection thermocouples to the ISM 111 and ISM 112...
  • Page 95: Simplified Drawings

    INTELLIGENT DATA LOGGER 165.0 mm (6.4 inch) 185.0 mm (7.2 inch) 189.0 mm (7.4 inch) 12.2. Side View middle of the frontside and the DIN rail 10 mm (0.4 inch) 83 mm (3.3 inch) HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 96: A. Pinout Arrangements For Analog Sensors

    In + In + In - In + AGND AGND AGND measurement of resistance measurement of resistance in 2-wire technique in 4-wire technique SOURCE SOURCE In + In - AGND AGND HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 97: B. Pinout Arrangements For Digital Sensors

    IDL 101 PINOUT ARRANGEMENTS FOR DIGITAL SENSORS digital output I/O 1 ..16 status recording frequency measurement I/O 1 ..16 I/O 1 ..16 progressive counter I/O 1 ..16 HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 98 ISM 111 ACCURACY / RESOLUTION HB_IDL101_E_V222.doc Gantner Instruments Test & Measurement GmbH...
  • Page 99 Notice: Information in this manual are valid from 19 April 2004 until revocation. Further changes and completion of the manual are reserved and possible without notice.
  • Page 100 . g a n t n e r - i n s t r u m e n t s . c o m GANTNER Instruments Test & Measurement GmbH Montafonerstraße 8 • A-6780 Schruns/Austria Tel.: +43 (0)5556-73784-410 • Fax: +43 (0)5556-73784-419...
