- Page 1 CRUISE...
- Page 2 CRUISE Quick Start Guide Guide de démarrage rapide What’s in the box Design for M8 PE bag M8*60 bolt Adjust screw M8 Design for Design for Harley Davidson 1200 custom PE bag Design for M10 PE bag M10 Adjust screw M10 Nut Φ10 Spring washer for M10...
- Page 3 CRUISE Quick Start Guide Guide de démarrage rapide Speaker for M10 installation Share parts for M8&Harley Davidson 1200 custom PE bag 1. Disassemble left M10 mirror from motorcycle Mirror Disassemble M10 mirror from motorcycle Φ8.5 Spring washer Φ8.5 washer M8 Nut 2: Take the M10 bolt with M10 nut 2pcs, ¢10.5 washer 2pcs and...
- Page 4 CRUISE Quick Start Guide Guide de démarrage rapide 3. Screw M10 bolt into the left speaker holder 5. Screw M10 Adjust screw into left speaker holder hole Speaker holder M10 Adjust screw Speaker holder M10 bolt 4. Screw M10 bolt into left motorcycle mirror hole 6.
- Page 5 CRUISE Quick Start Guide Guide de démarrage rapide Speaker for M8 installation 3. Screw M8 nut, ¢8.5 washer and ¢8.5 spring washer onto M8*60 bolt 1. Disassemble M8 mirror from motorcycle Mirror Disassemble M8 mirror from ¢8.5 washer motorcycle ¢8.5 spring washer...
- Page 6 CRUISE Quick Start Guide Guide de démarrage rapide 4. Screw M8*60 bolt into the Left speaker holder 6. Screw M8 Adjust screw into hole of the left speaker holder Speaker holder M8 Adjust screw Speaker holder M8 bolt 5. Screw M8*60 bolt into left mirror hole after assembled ¢8.5 7.Screw M8 Left mirror into speaker holder hole...
- Page 7 CRUISE Quick Start Guide Guide de démarrage rapide Speaker for Harley Davidson 1200 custom installation 3. Screw M8 nut, ¢8.5 washer and ¢8.5 spring washer onto M8*90 bolt 1. Disassemble UNF5/16'' left mirror from motorcycle Mirror ¢8.5 washer ¢8.5 spring washer...
- Page 8 CRUISE Quick Start Guide Guide de démarrage rapide 4. Screw M8*60 bolt into the Left speaker holder 6. Screw UNF5/16” Adjust screw into hole of the left speaker holder Speaker holder UNF5/16” Adjust screw Speaker holder M8*90 bolt 5. Screw M8*90 bolt into left mirror hole after assembled ¢8.5 7.
- Page 9 Short press to enter Bluetooth pairing mode WARNING THERE MAY BE UNEXPECTED SHAKE AND VIBRATION DURING YOUR DRIVE. PLEASE MAKE SURE THE SPEAKER IS MOUNTED TIGHTLY TO YOUR VISOR AND WON’ T FALL DOWN DURING JBL Cruise YOUR DRIVE. Choose “JBL Cruise” to connect...
- Page 10 CRUISE Quick Start Guide Guide de démarrage rapide • Transducer: 2 x 65mm • Rated Power: 2 x 20W • Operation Frequency: 2402MHz – 2480MHz • Max Output Power：<4dBm • Bluetooth Version: 3.0 • Support: A2DP V1.3, AVRCP V1.4 • Multi-points (up to 2 phones) •...
- Page 11 CRUISE Quick Start Guide Guide de démarrage rapide Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em carater primario”...
