BioTrack BioFace Quick Installation Manual

QUICK INSTALLATION GUIDE OF
For more information about BioFace, refer to the
Downloads section of our website,
www.BioTrackSoftware.com.

1) Recommended installation environment:

The installation of BioFace must be done indoors, 3 meters (approx. 10 ft.)
away from windows and 2 meters (about 6.5 ft.) away from light bulbs,
with an intensity of light no larger than 800 lux (average office lighting
is about 400 lux).
Places NOT recommended:

2) Installation steps:

Step # 1: Fix the paper template on the wall and drill holes on the three marked circles.
We recommend placing the template at1.20 m (4ft), assuming the average height of
its users is 1.50-1.80 m (5-6 ft.).
Step # 2: Secure the metal base to the wall by placing screws in the previously mentioned circles.
Step # 3: Hang the BioFace to the metal base (the top first) and hold it with a screw on the bottom.

3) Recommended approaching distance::

For users between 1.50-1.80 m (5-6 ft.), we recommend standing about ½ m (about 2 ft.) away from
the wall. The device must be located 1.20 m (4 ft.) from the ground.
When you see your image on the BioFace screen, you should step away if it is too bright,
and step closer if it is too dark.

4) 4) Facial expression and posture while using the BioFace:

YES
Note: During the registration and verification, maintain a relaxed facial expression and stand up straight.
Outdoors Under direct sunlight
through a window
www.BioTrackSoftware.com
BioFace BioFace
Under indirect sunlight
through a window
4'
YES
See reverse page
Too close to
light bulbs
1.
4'
2.
3.
2'
