Home Depot Wireless Push Button Use And Care Manual

TOOLS REQUIRED

Phillips screwdriver Flat Head Screwdriver
5/64 in. Drill Bit

Installation

1
ACTIVATING THE PUSH BUTTON BATTERY
□ Remove the front cover of the push button by inserting a flat
head screwdriver in the slot on the bottom of the button and
pulling up slightly.
□ Remove the plastic tab from the battery compartment to
allow connection to the terminal.
□ Snap the front cover onto the base by first hooking the tops
together, then snapping the base on.
□ Repeat for second button if applicable.
3
SYNCING THE CHIME AND PUSH BUTTON
□ Follow the instructions included in the chime.
Wireless Push Buttons
ITEM #206 049 303,#1001 406 887,
#1001 406 886,#1001 406 884
MODEL #216592, #216593,
#216594, & #216595
Drill
216595Inst.ai
216595Inst.ai
#4x3/4

HARDWARE INCLUDED

#6x3/4
#4x3/4
(2) #4 x 3/4 in. Screws
#4x1 White Zinc
#6x3/4
ScrewHardware.ai
#4x1 White Zinc
2
POWERING THE CHIME
□ Install the chime batteries or plug in the chime, following the
instructions included in the chime.
ScrewHardware.ai
4
MOUNTING THE PUSH BUTTON
□ Remove the front cover from the base by following step 1.
□ Mount the push button base to a clean wall or door jamb
with included screws or mounting tape. If mounting with
screws, predrill a pilot hole through the push button base in
the desired location using a 5/64 in. drill bit.
□ Snap the push button cover onto the base by first hooking
the tops together, then snapping the base on.

Use and Care

Guide
(1) Adhesive Sticker
#6x1 Self Tapping
#6x1 Self Tapping
Please contact 1-855-556-1852 for further assistance.
216595Inst.ai
HOMEDEPOT.COM
