amadeus PHILARMONIA Getting Started

Hide thumbs
Table of Contents

Advertisement

Quick Links

Getting Started with
PRELIMINARY V.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHILARMONIA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for amadeus PHILARMONIA

Summary of Contents for amadeus PHILARMONIA

  • Page 1 Getting Started with PRELIMINARY V.1.1...

  • Page 3: Table Of Contents

    Amadeus DSPControl software installation and network configuration ........

  • Page 4: Foreword

    They do not present all criteria and UNPACKING Unpack your Amadeus system carefully and make sure it We advise you strongly to keep the cardboard, packaging is not damaged. and shipping accessories, even if the speakers are not damaged, if you need to ship the speakers in the future.

  • Page 5: Features

    FEATURES ACOUSTICAL SPECIFICATIONS Amplitude linearity (±2dB) : 43 Hz - 22 kHz Cut-off frequencies (-6dB) : 35 Hz Peak SPL 1-meter (Pair, IEC Short Term) : 124 dB peak TECHNICAL SPECIFICATIONS Crossover frequency (HF, LMF) : 2170 Hz and 2170 Hz (DSP generated) Crossover slope (HF, LMF) : 24 dB/Oct and 24 dB/Oct Transducer (HF) : Ø...
  • Page 6 LOUDSPEAKER PROCESSING Crossover : Multiple filter types (Butterworth, Linkwitz- Riley, Bell, High Shelf, Low Shelf, Notch, All Pass, Band Pass, High Pass, Low Pass) up to 24 dB / Oct. Delay : 1 second Control and monitoring interface : Full configuration and real-time monitoring via PC and Mac.

  • Page 7: Elementary Precautions

    ELEMENTARY PRECAUTIONS PLEASE READ ATTENTIVELY THESE INSTRUCTIONS BEFORE USING THE AMADEUS SYSTEM IN ANY WAY ! DO NOT OPEN Never open the system, and avoid pulling apart internal elements or modifying them in any way. No internal component of the system has been designed to allow user intervention.

  • Page 8: Speaker Placement And Positioning

    SPEAKER PLACEMENT AND POSITIONING INTRODUCTION Having acoustics and electro-acoustics match up is a us able to create perfectly imagined spaces where the basic premise of our design philosophy when designing acoustical response has been perfected, ready to house and outfitting spaces dedicated to creation, mixing, the monitoring systems we design in parallel.
  • Page 9 IMPROVING BASS PERFORMANCE Typically, moving the Philharmonia loudspeakers experimenting moving both ways for the most pleasing towards the walls will increase low bass output, but can sound. result in more unevenness higher up the musical scale. Changes in loudspeaker position of as little as a few Moving them closer to the side walls will not produce inches can have a large effect upon bass performance, the same effect as moving closer to the back wall, so try...

  • Page 10: Front Panel

    FRONT PANEL POWER SWITCH AND POWER INDICATOR The power switch is located on the front panel of your Turn the system off by briefly touching the sensor area loudspeaker, just under the Philharmonia letters. Turn again. The underline will light up red indicating that the the system on by briefly touching the sensor area.
  • Page 11 +26 dBu. AES3 INPUTS A latching XLR-F connector accepts an AES3 digital or digital inputs is made via the Amadeus DSPControl audio signal. Input impedance is 110 ohms. Ensure that software. 110 ohm digital audio cables are used. Standard XLR...

  • Page 12: Network Connection And Configuration (Optional)

    However, no adjustments of levels or parameters will be possible using Amadeus However, most newer laptop computers will work with DSPControl until the network connection is restored.

  • Page 13: Amadeus Dspcontrol Software Installation And Network Configuration

    AMADEUS DSPCONTROL SOFTWARE INSTALLATION AND NETWORK CONFIGURATION DOWNLOADING THE INSTALLATION FOLDER The installation files for Amadeus DSPControl may be For Windows 32 bit systems: Use _32_bit.msi downloaded free of charge. For Windows 64 bit systems: Use _64_bit.msi Version 3.8.10.110659 is available for download.
  • Page 14 Available RAM : 256 MB 5. Follow the prompts given by the Installation Wizard. To install Amadeus DSPControl : In order for Amadeus DSPControl to function, it must be given permission to pass through the Windows Firewall 1. Locate the compressed (zipped) downloaded folder.
  • Page 15 MAC SOFTWARE INSTALLATION To install Amadeus DSPControl : 3. Open the uncompressed folder. 1. Locate the compressed (zipped) downloaded folder. 4. Double click/tap on the ‘Amadeus_DSPControl.mpkg’ installation package. 2. Click/tap on Extract all files. 5. Follow the prompts given by the Installation Wizard.

  • Page 16: Amadeus Dspcontrol Overview

    Acoustical engineers trained in electro-acoustical by Philharmonia systems. monitoring systems calibration, and authorized and selected by Amadeus, are the ideal solution for tuning of For close to twenty-five years, we have been providing a Philharmonia system. support to opera houses, theaters, venues and studios...
  • Page 17 MAIN VIEW The Main View accesses the following functions : Input levels Linking of inputs and outputs Input mixing Device name Input mute (per channel) Temperature reading Output mute (per channel) Current preset Output levels Preset store and recall (device or computer) INPUT EQ VIEW Input EQ View is selectable per channel.

  • Page 18: Set-Up And Dsp Configuration

    SET-UP AND DSP CONFIGURATION SETTING UP AND MODIFYING LOUDSPEAKER GROUPS 3. Members Loudspeakers on the network may be set up in groups to allow easier monitoring of status and simultaneous configuration grouped loudspeakers. Click on Select to add or remove units from the Group. Loudspeaker units may be assigned to more than one There is no group master control panel.
  • Page 19 INPUT EQ AND DELAY SETTING 1. Equalizer setting 3. Filter tools Click/tap on the Input EQ 1 or Input EQ 2 tabs to bring The following filter tools are available on the left side of up the parametric equalizer and delay setting windows. the EQ display : Equalizer setting may be accomplished using any of a.
  • Page 20 PRESET STORE AND RECALL Presets may be stored to the device and the host 4. Computer Recall computer, and recalled from either the device or the host computer. Click/tap the RECALL ON COMPUTER button. Select the desired preset from the list of available preset files and 1.

  • Page 21: Customer Service

    CUSTOMER SERVICE If you need additional help in solving problems, contact your Amadeus dealer. For online support, please visit Amadeus Web site at www.amadeusaudio.fr For further information, please contact Amadeus at info@amadeusaudio.fr...
  • Page 22 Amadeus is a registered trademark. All rights reserved.
