- Page 1 Vacuum toilet system Instruction manual 4800 Series 4600 Series 4800 and 4600 Series VacuFlush ® Toilets...
- Page 2 Dometic VacuFlush Toilet...
-
Page 3: Table Of Contents
. Modification of this product may result in property damage . Dometic recommends that a qualified marine technician or electrician install or service this product . Equipment damage, injury to personnel or death could result from improper installation . DOMETIC... -
Page 4: Intended Use
Dometic DTM01C tank monitor or DTM04 four-level tank monitor system . Intended use The Dometic VacuFlush toilet provides an electric-flush toilet that vacuums waste from the bowl and pumps it to a holding tank or other effluent storage/disposal system . Operated by a wall-mounted flush switch, the toilet allows the user to add water to the bowl (before using or flushing) and to flush the toilet by pushing a button . -
Page 5: Components
Dometic VacuFlush Toilet Components Components VacuFlush all-ceramic toilet (fig . , page 2) (fig . , page 2) Ref. Description Ref. Description Service mode switch VacuFlush switch panel Water supply check valve VacuFlush status panel (for toilet with flush handle only) - Page 6 Horizontal run 50 ft ./15 m maximum to vacuum source Vertical run 6 ft ./1 .8 m maximum to vacuum source Electric flush switch Dometic VFS or VFP switch (purchased separately) Required VacuFlush vacuum generator or components Vacuum source VacuFlush holding tank system (purchased separately) * Circuit board fuse resets by turning toilet’s electrical power off, then back on .
-
Page 7: Operation
Make sure all guests understand toilet operation before use. Changing flush modes Dometic VacuFlush all-ceramic toilets offer two flush settings to help manage water consumption: Normal flush – Uses 1 quart (0 .95 liter) per flush . Adds water to bowl after every flush . - Page 8 Operation Dometic VacuFlush Toilet Indicator lights “OK TO FLUSH” INDICATOR A steady green “OK to Flush” light indicates when the toilet is ready to flush . A momentary flashing green light indicates when flush mode is changing . “DO NOT FLUSH” INDICATOR A red “Do Not Flush”...
-
Page 9: Maintenance/Winterizing/Service
Dometic VacuFlush Toilet Maintenance/Winterizing/Service Maintenance / Winterizing / Service Cleaning the toilet To maintain the toilet’s original, lustrous appearance, use Dometic Toilet Bowl Cleaner or ® other non-abrasive bathroom and toilet bowl cleaners . Please follow label directions . Caution To avoid damaging the toilet system’s seals and... - Page 10 Maintenance/Winterizing/Service Dometic VacuFlush Toilet During extended periods of non-use Toilet system sanitation hoses should be cleared if toilet will not be needed for an extended period of time (more than two weeks) . 1 . Fill toilet bowl with water and add 4 oz . (120 ml) of liquid biodegradable laundry detergent (should NOT contain bleach) .
- Page 11 Dometic VacuFlush Toilet Maintenance/Winterizing/Service Note Use nontoxic antifreeze designated for potable water systems . (See boat or vehicle owner’s manual .) Caution Never use automotive-type antifreeze in freshwater systems . Troubleshooting guide Toilet base assembly Sealing Grommet Check Valve SERVICE MODE...
- Page 12 Maintenance/Winterizing/Service Dometic VacuFlush Toilet Problem Possible Cause Service Instruction 2 . Water enters toilet bowl, but a . “OK to Flush” light is not lit on a . Check for loose/defective wires toilet does not flush . status panel .
- Page 13 Dometic VacuFlush Toilet Maintenance/Winterizing/Service Problem Possible Cause Service Instruction 9 . Flush ball does not open a . Rotor cam shaft is loose or a . See instructions for repair or completely . defective . replacement on page 15 .
- Page 14 Maintenance/Winterizing/Service Dometic VacuFlush Toilet Servicing toilet base components ALIGNING CAM SWITCH/FLUSH BALL The flush ball should be properly positioned so that the “A” and “B” distances are equal (see illustration at right) . If the flush ball becomes misaligned (resulting in water leaking from bowl or other flushing problems), follow instructions below to resolve problem .
- Page 15 Dometic VacuFlush Toilet Maintenance/Winterizing/Service REPLACING THE FLUSH BALL 4 . Lubricate moving parts with silicone grease . 5 . Reverse the disassembly procedure . 1 . Turn off water to toilet . 6 . Before attaching base to toilet, the cam 2 .
-
Page 16: Warranty
. If this Dometic product is placed in commercial or business use, it will be warranted to the original purchaser only to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase . -
Page 17: Customer Service
Customer Service department . Any damage due to improper use is not covered by the warranty . The warranty does not cover any modifications to the product or the use of non-original Dometic parts; the warranty does not apply if the installation and operating instructions are not adhered to and no liability shall be entertained . - Page 18 Dometic VacuFlush Toilet...
- Page 19 Dometic VacuFlush Toilet...
- Page 20 Dometic VacuFlush Toilet Dometic Corporation, Sanitation Division 13128 State Rt. 226, P.O. Box 38 REVISION A Big Prairie, OH 44611 USA Form No. 600345371 9/17 1-800-321-9886 • Fax: 330-496-3097 ©2017 Dometic Corporation www.Dometic.com...
