- Page 1 Base Station Installation Guide All rights reserved © Baicells Technologies Co., Ltd.
- Page 2 Base Station Installation Guide About This Document This document is a guidance of pBS2120 hardware installation for installation personnel, which includes the preparation of installation tools and supporting materials before installation, the demands of installation environment, installation of base station, connection of cable and power on.
-
Page 3: Table Of Contents
Base Station Installation Guide Contents Product Overview ......................1 Introduction ....................... 1 Features ........................1 Appearance ........................ 2 Technical Specification ....................3 1.4.1 Hardware Specification..................3 1.4.2 Software Specification ..................4 1.4.3 Environment Specification .................. 4 Out-of-Box Audit ......................5 Installation Preparation .................... -
Page 4: Product Overview
Introduction Baicells pBS2120 is a high performance outdoor 3650MHz~3700MHz micro base station based on TD-LTE technology, which is developed by Baicells. The pBS2120 supports wired backhaul connections to backbone networks, and provides LTE access to user terminals, implemented voice and data service transmissions. -
Page 5: Appearance
Base Station Installation Guide Appearance The pBS2120 base station appearance is shown in Figure 1-1. Figure 1-1 pBS2120 Appearance The pBS2120 interfaces and indicators are shown in Figure 1-2. Figure 1-2 pBS2120 Interfaces and Indicators The pBS2120 interfaces are described in Table 1-1. -
Page 6: Technical Specification
Base Station Installation Guide The pBS2120 interface indicators are described in Table 1-2. Table 1-2 pBS2120 Interface Indicators Identity Color Status Description Steady On Power On Green No Power Supply Steady On The cell is activated. Green The cell is not activeated. -
Page 7: Software Specification
Base Station Installation Guide 1.4.2 Software Specification Item Description LTE Standard LTE TDD 3GPP Release 9 Maximum 20MHz: DL 110Mbps, UL 20Mbps Throughput 10MHz: DL 55Mbps, UL 9Mbps Business 32 concurrent users (support software upgrading the users to... -
Page 8: Out-Of-Box Audit
Base Station Installation Guide 2. Out-of-Box Audit Before opening the box, make sure the package is in good condition, undamaged and not wet. During the unpacking, avoid potential damaging impacts from hits or excessive force. Once unpacked, check the contents to see if they are consistent with that in the shipping list shown in Table 2-1. -
Page 9: Installation Preparation
Base Station Installation Guide 3. Installation Preparation Support Materials Prepare the following support materials accordingly, as given in Table 3-1. Table 3-1 Support Materials for Installing Base Station Item Description Ethernet cable Outdoor CAT6 Shorter than 100m (330 feet) Ground cable 16mm²... -
Page 10: Installation Environment
(large radar stations, transmitting stations, transformer substations) are not suitable for the operation of pBS2120, and thus should be avoided. Places prone to have impounded water, soaking, leakage, or condensation, should also be avoided. -
Page 11: Regulatory Compliance
Base Station Installation Guide The ground wire adopts yellow-green wire that is no smaller than 16 mm² . Grounding principle: as near as possible. The eNodeB connects to the reliable outdoor grounding point (earth) through one ground screw. - Page 12 Base Station Installation Guide cause interference, and (2) This device must accept any interference, including i nterference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d' Innovation, Science et Développement économique Canada applicables aux appareils radio exempts de licence.
-
Page 13: Base Station Installation
Base Station Installation Guide 4. Base Station Installation Install on Pole Required diameter of the pole: 40mm ~ 100mm. As the following figure, assemble the bracket for pole installation, and fasten screws. Mounting bracket installs is complete as shown in the following figure. -
Page 14: Install On Wall
Base Station Installation Guide Adjust base station to proper angle and fasten the screws. Install on Wall The wall must bear four times of the base station weight. Fit the base station on the wall, and mark the drilling locations. -
Page 15: Connect Ground Cable
4.3.2 Connect Ground Cable Make the grounding cable according the actual situation of the installation site. The grounding screws of pBS2120 located on the bottom of the base station, as shown in Figure 4-1. Figure 4-1 Location of Grounding Screws Unscrew the grounding screw, connect one end of the grounding cable to the grounding screw, and fasten it again. -
Page 16: Power On
Base Station Installation Guide 5. Power On Power on the pBS2120, and the indicators will light up, as shown in Figure 5-1. Figure 5-1 LED Indicators The explanation of the indicator signal is given in Table 5-1. Table 5-1 pBS2120 Indicator Description...
