Baicells Nova R9 2.5GHz 10W Base Station Ins tallation Guide
V 1.0
All rights reserved © Baicells Technologies Co., Ltd .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nova R9 and is the answer not in the manual?

Questions and answers

Related Manuals for Bai cells Nova R9

Summary of Contents for Bai cells Nova R9

  • Page 1 Baicells Nova R9 2.5GHz 10W Base Station Ins tallation Guide V 1.0 All rights reserved © Baicells Technologies Co., Ltd .
  • Page 2 Baicells Nova R9 2.5GHz 10W Base Station Installation Guide About This Document This document is a user guide for the hardware installation of the Nova R9 2.5Ghz 10W base station. Copyright Notice Baicells copyrights this specification. No part of this specification may be reproduced in any form or means, without the prior written consent of Baicells.

  • Page 3: Table Of Contents

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Contents Out-of-Box Audit ....................... Shipping List ......................1 Appearance ......................2 Base Station Accessories ..................2 Installation Preparation ................... 5 Supporting Materials ....................5 Installation Tools ...................... 5 Installation Environment ..................6 2.3.1...
  • Page 4 Figure 1-1 Appearance of Nova R9 2.5GHz 10W Series..........2 Figure 2-1 Grounding and Lightning Protection ............7 Figure 3-1 Installation procedure of Nova R9 2.5GHz 10W ........8 Figure 3-2 Install on Wall ................... 9 Figure 3-3 Drilling Locations on Wall ................. 9 Figure 3-4 Install Mounting Bracket on Base Station ..........
  • Page 5 Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Figure 3-22 Connect Power Adaptor to grounding........... 21 Figure 3-23 LED Indicator ..................22 Table Contents Table 1-1 Shipping List ....................1 Table 1-2 Base Station Accessories ................2 Table 2-1 Supporting Materials for Installing Base Station ........5 Table 2-2 Environmental Requirements of the Base Station ........

  • Page 6: Out-Of-Box Audit

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide 1. Out-of-Box Audit Shipping List Before opening the box, make sure the packaging is not damaged or wet. Take care to avoid potential damage to the base station by handling the package gently.

  • Page 7: Appearance

    Figure 1-1 Appearance of Nova R9 2.5GHz 10W Dimensions: 440mm (length) x 240mm (width) x 140mm (height) Weight: about 11kg Base Station Accessories Table 1-3 shows the accessories of the Nova R9 2.5GHz 10W base station. Table 1-2 Base Station Accessories Accessory Name...
  • Page 8 Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Accessory Name Mounting bracket on pole Omega M10*160 outer hex bolts M10 nuts M10 ball pats M10 flat gaskets Mounting bracket on wall, used on upper of the base station Mounting bracket on wall,...
  • Page 9 Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Ultraviolet-proof tie Accessory Name Waterproof daub Ultraviolet-proof tape OT terminal Hydraulic terminal...

  • Page 10: Installation Preparation

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide 2. Installation Preparation Supporting Materials Prepare following supporting materials, given in Table 2-1. Table 2-1 Supporting Materials for Base Station Installation Name Description Power line < AWG16，e.g., AWG14 Shorter than 1150 feet...

  • Page 11: Installation Environment

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Installation Environment 2.3.1 Locational Requirements Environments with high-temperatures, harmful gases, unstable voltages, volatile vibrations, loud noises, flames, explosives, and electromagnetic interference (large radar stations, transmitting stations, transformer substations) are not suitable for the operation of Nova R9, and thus should be avoided.

  • Page 12: Install The Base Station

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Note that the wire must be inserted in the GND port and fastened with an M6 screw, then welded with an anticorrosive process. The wire should be no smaller than 16 mm , as short as possible, and without coiling.

  • Page 13: Installation Steps

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Figure 3-1 Installation procedure of BRU3500 Series Installation Steps 1. The base station supports wall-mounted and pole-mounted installations. The following steps will go through these separately. 2. Fix three mounting hooks on both ends of the base station with M6*16 screw, as shown in Figure 3-2.

  • Page 14: Install On Pole

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide 3.2.1 Wall Installations 3. Fix three mounting hooks on both ends of the base station with M6*16 screw, as shown in Figure 3-2. 4. Put the base station with mounting hook on the wall, mark the drilling locations, as shown in Figure 3-3.

  • Page 15: Figure 3-4 Install Mounting Bracket On Base Station

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Figure 3-4 Install Mounting Bracket on Base Station Install the mounting bracket on a pole with a diameter of 30mm~100mm, as shown in Figure 3-5. Figure 3-5 Install Mounting Bracket on Pole Fasten the base station onto the mounting bracket on pole using the M6 fixed screws, as shown in Figure 3-6.

  • Page 16: Install Antenna Feeder System

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Figure 3-6 Installation on Pole Complete 3.2.3 Install Antenna Feeder System There are two kinds of outdoor antennas: omnidirectional outdoor antennas and directional outdoor antennas. Installation for each antenna type will be explained respectively.

  • Page 17: Figure 3-8 Omnidirectional Antenna Installation (2)

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide  In principle, no lightening rod can be welded to pole (no metal object is allowed within 1m range in the horizontal direction of the omnidirectional antennas), when installing the omnidirectional antennas. Instead, an independent lightening rod should be installed between two poles, where the lightening rod is high enough to keep all antenna tops under its protective cover.

  • Page 18: Figure 3-9 Assembling Procedure Of Directional Antennas

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide 3.2.3.2 Install Directional Antennas First, assemble the antennas, as shown in Figure 3-9. Figure 3-9 Assembling Procedure of Directional Antennas Use a pulley to transport the assembled antenna to the platform at the tower, as shown in Figure 3-10.

  • Page 19: Figure 3-11 Directional Antenna Installation

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Figure 3-11 Directional Antenna Installation When the base station has been installed in a proper position connect all cables and wires and fix them. Perform tests, then waterproof all the connections the tests have been finished.

  • Page 20: Figure 3-13 Antenna Waterproof Protection

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Be aware that at least three layers of tapes are needed, and make sure that the last layer is wrapped from the bottom up. The last layer should be in tight to keep it from cracking.

  • Page 21: Optional) Install Gps Antenna

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Notes about grounding:  Ground wire uses yellow-green wire that is no smaller than 16 mm².  Grounding principle: as near as possible.  The connection to the grounding terminals and grounding bar needs to be tight and reliable.

  • Page 22: Figure 3-16 Gps Pole Installation

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide  GPS working frequency bands ~ L1: 1575.42MHz ± 1.023MHz.  GPS antenna feeder connector is N type. Pass one end of the GPS antenna feeder through the support tube, connect it to the N type of GPS antenna, and then fasten the support tube to the GPS antenna.

  • Page 23: Connection The Wire

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide GPS antenna feeder should be as short as possible to reduce the signal attenuation. GPS connector connects to the base station, as shown in Figure 3-18. Figure 3-18 GPS Connector Connect to Base Station Waterproofing measures need to be taken on the GPS connector and GPS antenna connector, using the waterproof daub and waterproof tape.

  • Page 24: Figure 3-20 Connect Ethernet Cable

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Connect the Ethernet cable. Connect the Ethernet cable to the ETH0 interface of the base station, fix the cable on the ETH0, and fasten the screw, as shown in Figure 3-20.

  • Page 25: Figure 3-22 Connect Power Adaptor To Grounding

    Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Figure 3-22 Connect Power Adaptor to grounding Power On Power on the base station, and the indicators will light up, as shown in Figure 3-23. Figure 3-23 LED Indicator Explanations of the indicator signals are given in Table 3-1.
  • Page 26 Baicells Nova R9 2.5GHz 10W Base Station Installation Guide Table 3-1 Indicator Description Identity Color Status Description Fast flash: 0.125s on,0.125s off The board is loading. Slow flash: 1s on,1s off The board is normal. Green No power input or board fault Steady On Hardware alarm, e.g.
