  • Page 1   User Manual         TREK-570           Computer...
  • Page 2 Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer.           Part No. Edition 1 Printed in Taiwan November 2014 TREK-570/303 User Manual  ...
  • Page 3 According to FCC 15.407(e), the device is intended to operate in the frequency band of 5.15GHz to 5.25GHz under all conditions of normal operation. Normal operation of this device is restricted to indoor used only to reduce any potential for harmful interference to co-channel MSS operations.     TREK-570/303 User Manual  ...
  • Page 4 Description of your peripheral attachments – Description of your software (operating system, version, application software, etc.) – A complete description of the problem – The exact wording of any error messages             TREK-570/303 User Manual  ...
  • Page 5 Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately. TREK-570 series In-Vehicle Computing Box „ USB/Audio cable clip „...
  • Page 6 The equipment has been dropped and damaged. „ The equipment has obvious signs of breakage. „ CAUTION: The computer is provided with a battery-powered real-time clock cir- cuit. There is a danger of explosion if battery is incorrectly replaced. Replace TREK-570/303 User Manual  ...
  • Page 8 D) Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuits might have on over current protection and supply wiring. Appropriate consid- TREK-570 /303 User Manual...
  • Page 9 CompactFlash: Turn off the power before inserting or removing CompactFlash storage cards.     European Contact Information:   Advantech Europe GmbH Kolberger Straße 7 D-40599 Düsseldorf, Germany Tel: 49-211-97477350 Fax: 49-211-97477300 TREK-570 /303 User Manual  ...

  • Page 10: Table Of Contents

        Chapter System Setup ........7   A Quick Tour of the TREK-570 Computing Box ........8   Figure 2.1 Front view of TREK-570 ..........8   Figure 2.2 Rear view of TREK-570 ..........8   Figure 2.3 Side view of TREK-570 ..........8  ...
  • Page 12   Table 4.1: Jumpers on Motherboard ......... 20 Table 4.2: Jumpers on Daughter Board ........20 4.1.3 Connectors ................. 20   Table 4.3: Connectors on Motherboard........20     Table 4.4: Connectors on Daughter Board........ 20     Jump r Settings ..................21 4.2.1 CMOS Clear for External RTC (JP2) ..........
  • Page 13 Dead Reckoning..................38 G-sensor (3-axis Accelerometer) ............38     Appendix A TREK-303..........39   TREK-303 Specifications ................ 40 Table A.1: TREK-303 Specification ........... 40 Table A.2: Smart Display Connector.......... 41 Figure A.1 Hotkey utility ............. 43 TREK-570 /303 User Manual  ...

  • Page 14: Chapter 1 General Information

                        Chapter   General Information   This chapter gives background information on the TREK-570 In- Vehicle Computing Box. Sections include: „ Introduction „ General Specifications „ Dimensions TREK-550 A2/303 User  ...

  • Page 16: Introduction

    TREK-570 combined with variety of I/O connectors can be connected to devices like TPMS (Tire Pressure Monitoring System), Rear view Camera ( for parking monitoring) and CAN Bus devices. It has dual CAN BUS ports and support several kind of vehicle protocols (e.g.

  • Page 17: General Specifications

    Serial ports: Two CAN Bus „ Two 4-wire RS232,1 x RS485, 1 x J1708 ports Universal serial bus (USB) port: one USB3.0 Type A, one USB 2.0 Type A „ LAN port: 1 x 10/100/1000 Ethernet by RJ45 „ TREK-570/303 User Manual  ...
  • Page 18 J1708 bus: 9600 bps, by DB-9 connector on Vehicle I/O cable . GNSS (Ublox MAX-M8Q/W): GPS, GLONASS, BEIDOU Audio: 2 audio codecs, one is for smart display, one is for TREK-570 line out „      and mic in phone jack by Generic I/O cable.

  • Page 19: Dimensions

      1.3 Dimensions                       Figure 1.1 TREK-570 dimensions TREK-570/303 User Manual  ...

  • Page 20: Chapter 2 System Setup

              Chapter   System Setup   This chapter details system setup on TREK-570 Sections include: „ A Quick Tour of the Computer „ Installation Procedures „ Running the BIOS Setup Pro- gram TREK-570/303 User Manual  ...

  • Page 22: A Quick Tour Of The Trek-570 Computing Box

    2.1 A Quick Tour of the TREK-570 Computing Box Before starting to set up the In-Vehicle Computing Box, take a moment to become familiar with the locations and functions of the controls, drives, connectors and ports, which are illustrated in the figures below. When the Computer box is placed inside truck glove cabinet or under the passenger’s seat next to the driver, its front appears...

  • Page 23: Installation Procedures

    TREK-550 A2 vehicle ignition switch.         Table 2.1: Pin Definition of Power Cord     Definition Color Black Ignition Orange         2.2.2 Power Connector       Figure 2.6 Power connector outlook       TREK-570/303 User Manual...
  • Page 24 CMOS RAM and compares them to the equipment check conducted during the power on self-test (POST). If an error occurs, an error message is displayed on screen, and the user is prompted to run the setup program. TREK-570 /303 User Manual...

  • Page 25: Chapter 3 Hardware & Peripheral Installation

                                                            Chapter   Hardware & Peripheral Installation   This chapter details the installa- tion of hardware for TREK-550 Sections include: „...

  • Page 26: Overview Of Hardware Installation & Upgrading

      3.3 Installing Optional Accessories   Optional accessories, like RAM mount kits or other functional modules are available for purchase to complement TREK-570. The following are instructions for accessory installation.   3.3.1 Installing TREK-570 Peripheral Modules There are 6 screws on the bottom of TREK-550 A2, if you want to install the peripherals in TREK-550 A2, please use M2 type screw to open the system.

  • Page 27: Installing The Minipci Type Wwan, Sim Card And Coin Battery

      Figure 3.1 Install peripheral in the system         3.3.3 installing the MiniPCI Type WWAN, SIM Card and Coin Battery   The WWAN module is on the Mini PCI slot can be easily installed, just undo the 6 screws from the bottom cover to install WWAN, SIM card, and battery.
  • Page 28 TREK-570/303 User Manual...

  • Page 29: Chapter 4 Jumper Settings And Connectors

                                                            Chapter   Jumper Settings and Connectors   This chapter explains how to set up the In-Vehicle Computing Box hardware, including instructions on setting jumpers and connect-...

  • Page 30: Setting Jumpers And Switches

    To “open” a jumper, remove the clip. Sometimes a jumper has three pins, labeled 1, 2, and 3. In this case, connect either pins 1 and 2, or pins 2 and 3.       TREK-570 /303 User Manual...
  • Page 31                                                                             Chapter   Pin Assignments  ...
  • Page 32   5.2 Rear Side Connectors         5.3 Power Connector (12/24 V; 6 ~ 32 V)                                                     TREK-570 /303 User Manual  ...
  • Page 33     5.4 Smart Display Connector         Table 5.2: Smart Display Connector   Signal Signal Backlight Enable output # Panel Power Enable output # LVDS Ground Reset Button Input # LVDS Clock + LVDS Clock - LVDS Ground LVDS Ground LVDS Data2 + LVDS Data2 -...
  • Page 34 RS-232 CTS Ground RS-485 D- RS-485 D+ J1708 D- J1708 D+         5.7 VIO Connector A(DSUB15) Define B(Housing) CAN_L CAN_H J1708_DN J1708_DP DGND ODB_CAN_L ODB_CAN_H DGND DR_SPEED#_R DR_SPEED_R DR_DIRECTION#_R DR_DIRECTION_R     TREK-570 /303 User Manual  ...
  • Page 35    ...
  • Page 36 TREK-570/303 User Manual...
  • Page 37                                                         Chapter   Software Demo Utility Setup   This appendix explains the soft- ware demo utility for TREK-550 Sections include: „...
  • Page 38 6.1 Introduction To make the hardware easier to access for programmers, Advantech has developed and demo program in order to let customer test the functions on TREK-572. This document describes detailed information for each Advantech demo program so that application developers can become more familiar with using them. For technical support, contact Advantech application engineers worldwide.
  • Page 39 Note: Each channel only can select one bus type at same time. CAN Page CAN page as below figure Bus Speed Read Data control (Press "Start" to monitor bus to read) Read Data method Read Data list Write Data control CAN bus message mask control TREK-570/303 User Manual...
  • Page 40 J1708 Page J1708 page as below figure Read Data control (Press "Start" to monitor bus to read) Read Data list Write Data control J1708 bus message filter control Message filter list J1939 Page J1939 page as below figure Read Data control (Press "Start" to monitor bus to read) Read Data list Write Data control J1939 bus message filter control...
  • Page 41 Write Data control J1587 bus message filter control Message filter list ODB2 Page ODB2 page as below figure Read Data control (Press "Start" to monitor bus to read) Read Data list Write Data control ODB2 bus message filter control TREK-570/303 User Manual...
  • Page 42 6.1.2 Testing VCIL 1. Opening "TREK_V3_Sample_Code_VCIL.exe" 2. Select VCIL port and speed for your platform. For example, select the port number 8 on TREK-674 3. Selecting "VCIL Control" page as below figure 4. You should see the firmware version on this page when success opening VCIL. TREK 570/303 User Manual...
  • Page 43 Note: Each channel only can select one bus type at same time. Reset Module 1. Selecting "VCIL Control" page 2. Press "Reset Module" button as below figure CAUTION: When reset module, all configure for each bus reset to default value. 6.1.3 Testing CAN TREK-570/303 User Manual...
  • Page 44 1. Selecting "VCIL Control" page 2. Press combo box on the channel and select "CAN" as below figure Reading Data 1. Selecting "CAN" page as below figure Set CAN bus speed. For example 250K 2. Checked "Show Data" 3. Press "Start" button to receive CAN bus data 4.
  • Page 45 3. Press "Write" button to send CAN bus data as above figure 4. You should see the data on the receiver Testing Message Mask 1. Selecting "VCIL Control" page 2. Press combo box on the channel and select "CAN + Mask" as below figure Set Mask TREK-570/303 User Manual...
  • Page 46 1. Selecting "CAN" page as below figure Set CAN bus speed. For example 250K 2. Configure the Message mask 3. Press "Set Mask" button to apply the mask to bus 4. You should see the mask was applied on the bus. 5.
  • Page 47 1. Selecting "J1939" page as below figure 2. Checked "Show Data" 3. Pull TrackBar "ON" to receive J1939 data 4. You should see the data came from the J1939 and show on the list Writing Data 1. Selecting "J1939" page as below figure TREK-570/303 User Manual...
  • Page 48 2. Filling the J1939 data prepare to send 3. Press "Write" button to send J1939 data as above figure 4. You should see the data on the receiver Testing Message Filter 1. Selecting "VCIL Control" page 2. Press combo box on the channel and select "J1939 + Mask" as below figure Set Message Filter 1.
  • Page 49 For example, as above figure setting. The system can receive the PGN equal to 0xFEF6, otherwise no. 6.1.5 Testing ODB2 1. Selecting "VCIL Control" page 2. Press combo box on the channel and select "ODB2" as below figure Reading Data 1. Selecting "ODB2" page as below figure TREK-570/303 User Manual...
  • Page 50 2. Checked "Show Data" 3. Pull TrackBar "ON" to receive ODB2 data 4. You should see the data came from the ODB2 and show on the list Writing Data 1. Selecting "ODB2" page as below figure 2. Filling the ODB2 data prepare to send 3.
  • Page 51 4. You should see the filter was applied on the bus 5. The system ignores all PID is not on the list For example, as above figure setting. The system can receive the PID equal to 0x00, otherwise no. TREK-570/303 User Manual...
  • Page 52 6.1.6 Testing J1708 1. Selecting "VCIL Control" page 2. Press combo box on the channel and select "J1708" as below figure Reading Data 1. Selecting "J1708" page as below figure 2. Checked "Show Data" 3. Press "Start" button to receive J1708 data 4.
  • Page 53 2. Enter specified MID to filter 3. Press "Add MID" button to add the rule to filter 4. You should see the filter was applied on the bus 5. The system ignores all MID is not on the list TREK-570/303 User Manual...
  • Page 54 6.1.7 Testing J1587 1. Selecting "VCIL Control" page 2. Press combo box on the channel and select "J1587" as below figure Reading Data 1. Selecting "J1587" page as below figure 2. Checked "Show Data" 3. Press "Start" button to receive J1587 data 4.
  • Page 55 2. Enter specified MID to filter 3. Press "Add MID" button to add the rule to filter 4. You should see the filter was applied on the bus 5. The system ignores all MID is not on the list TREK-570/303 User Manual...
  • Page 56   6.3 Vehicle Power Management   6.3.1 Power Management Mechanism The feature of Vehicle Power Management (VPM) is provided for users to fulfill the special requirements on in-vehicle applications.   Ignition on/off „ – Turn on the system by ignition For the cases of in-vehicle applications, an ignition signal is often used to turn on or shutdown the system.
  • Page 58 1 ~ 18000 seconds LOW_THRESHOLD (12V mode) 11.42 V 10.09 ~ 12.25 V LOW_THRESHOLD (24V mode) 22.44 V 21.11 ~ 23.28 V LOW_DELAY 30 seconds 1 ~ 3600 seconds LOW_ HARD_DELAY 60 seconds 1 ~ 3600 seconds TREK-570/303 User Manual...
  • Page 60 System Menu • TREK V3 VPM Sample Code as below figure Common page Low Battery Protection & Ignition Control page Backup Battery Information page Alarm Wakeup Control page Common page • VPM Common page as below figure TREK-570/303 User Manual  ...
  • Page 61 Low Battery Protection & Ignition Control page • VPM Low Battery Protection & Ignition Control page as below figure Low Battery Protection Control Ignition Control Backup Battery Information page • VPM Common page as below figure Alarm Wakeup Control page TREK-570/303 User Manual    ...
  • Page 62 RTC Timer Control Alarm Wakeup Time Control Testing VPM Opening "TREK_V3_Sample_Code_VPM.exe" You should see the firmware version and voltage below figure 6.4 WatchDog Sample Code TREK V3 Watch Dog Sample Code is demonstration of controlling Watch Dog. TREK-570/303 User Manual  ...
  • Page 63 CAUTION: This demonstration may reboot your system, if you enable watch dog timer and not trigger watch dog timer in time. Peripheral Control Demo Program TREK V3 Peripheral Control Sample Code is demonstration of controlling peripheral power. TREK-570/303 User Manual    ...
  • Page 64 Selecting module, For example "WIFI" Selecting "Set" radio button Press "Enable/Disable" combo box and selecting "Enable" Press "Apply" button You should see the peripheral power is on Note: System need a little time to enable peripheral. Closing Peripheral Power TREK-570/303 User Manual  ...
  • Page 65 If you want close the specified peripheral power, following the instruction: Opening "TREK_V3_Sample_Code_PeripheralCtrl.exe" Selecting module, For example "WIFI" Selecting "Set" radio button Press "Enable/Disable" combo box and selecting "Disable" Press "Apply" button You should see the peripheral power is closed TREK-570/303 User Manual    ...
  • Page 66                                                 Appendix   TREK-303   This appendix explains the TREK- 303 detailed information. TREK-570/303 User Manual  ...
  • Page 68 A.1 TREK-303 Specifications Table A.1: TREK-303 Specification Models TREK-303R-LA0E TREK-303R-HA0E Design compatible models Paired with TREK-510 Paired with TREK-550 Resoultion (pixel) 480 x 234 800 x 480 Number of colors 262 K (supports 18-bit) 262 K (supports 24-bit) Pixel pitch 0.107(W) x 0.37 (H) 0.2168(H) x 0.2168 (V) Display...
  • Page 69         Pin out for TREK-303 LVDS connector         Table A.2: Smart Display Connector   Signal Signal Backlight Enable input # Panel Power Enable input # LVDS Ground Reset Button Input # LVDS Clock + LVDS Clock - LVDS Ground LVDS Ground...
  • Page 70 Pin assignment P1 1 10 11 12 13 14 15 17 18 P2 1 10 11 12 13 14 15 17 18 Color Brown White Ground Brown red white Ground Ground Orange white red Orange yellow white Ground Ground Green white  ...
  • Page 71 Key Status: When you press Hot key, the status will change from 0 to 1. Key function Definition: Set the parameters to connect to the application pro- gram function of the hot key.                       TREK-570/303 User Manual    ...
  • Page 72                             www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher.
