- Page 1 B9500 MOBILITY SCOOTER NEW SERIES USER MANUAL “A SUBLIME COMBINATION OF POWER, SPEED & COMFORT” WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury. CAUTION! Failure to heed the cautions in this owner’s manual may result in damage to your scooter...
-
Page 2: Table Of Contents
C O N T E N T S INTRODUCTION………………………………………………………………………………………. SAFETY……………………………………………………………………………......SPECIFICATIONS………………………………………………………………………………………. 8 YOUR SCOOTER……………………………………………………………………………………….. 10 BATTERIES AND CHARGING……………………………………………………………………… 14 OPERATION………………………………………………………………….…......18 COMFORT ADJUSTMENTS……………………………………………………………………….. 20 BASIC TROUBLESHOOTING……………..…………………………………………………… 22 CARE AND MAINTENANCE…………………...…………………………...……………………. 24 10. WARRANTY…………......………………………………………....25... -
Page 3: Introduction
I n t r o d u c t i o n Congratulations on the purchase of your new B9500 Mobility Scooter! The advanced design and attractive styling of the B9500 ensures many years of enhanced trouble-free mobility. Correct use improves your mobility and quality of life. -
Page 4: Safety
S A F E T Y SAFETY PRECAUTIONS ■ Lock your seat into place and remove the key before you get on or off your scooter. ■ Lock the seat into position before you operate your scooter. ■ Do not operate your scooter with the seat in the reclined position (if so equipped). ■... - Page 5 S A F E T Y Until you are familiar with the operation of your scooter, please practice in a wide and open area such as a park, with your scooter set at the lowest speed setting. To prevent the possibility of falling off your scooter while driving bear in mind the status of the driving motion, such as accelerating, stopping, turning, reversing, up-and-down ramps etc.
- Page 6 S A F E T Y These tests were conducted with the scooter’s seat in the highest position and adjusted backward on the seat base to its farthest rearward position. Use this information as a guideline. Your scooter’s ability to travel up any incline is affected by your weight, your scooter’s speed, your angle of approach to the incline, and your scooter’s setup.
-
Page 7: Specifications
S P E C I F I C A T I O N S Figure 4. Dimensions of Scooter B9500... - Page 8 S P E C I F I C A T I O N S...
-
Page 9: Your Scooter
Y O U R S C O O T E R Your scooter is electrically motorized and designed to give you greater mobility and is suitable for use both indoors and outside. Your scooter is designed to travel primarily on smooth surfaces. For easy transportation or storage, you can disassemble your scooter into seven components. - Page 10 Y O U R S C O O T E R Battery Gauge Speed Adjustment Dial Status Light Turning Signal Turning Signal Button (Right) Button (Left) Headlight Button Throttle Control (Backward) Throttle Control (Forward) Hazard Button Horn Button Figure 6. Control Console Assembly Throttle Control Lever This lever allows you to control the forward and reverse speed of your scooter up to the maximum speed pre-set on the speed adjustment dial.
- Page 11 Y O U R S C O O T E R Horn Button ■ This button activates a warning horn. Light Button ■ This button activates the headlight system. ■ Press once to activate, press again to deactivate. Turning Signals (L/R) ■...
- Page 12 Y O U R S C O O T E R Batteries The batteries store the electrical energy to power the scooter. Please see the section on: “Batteries and Charging” later in this manual. Electronic Controller Module The electronic controller module is located behind the batteries towards the rear of the scooter. This module receives electrical signals from the console controls and sends power to the motor, the brakes, the headlight, and the optional lighting system.
- Page 13 Y O U R S C O O T E R Manual Free-wheel Lever Engaging the free-wheel lever will enable the scooter to be pushed manually, (for instance to make small adjustments when parking). WARNING! Before placing your scooter in or out of freewheel mode, make certain that the key is removed from the key switch.
-
Page 14: Batteries And Charging
B A T T E R I E S A N D C H A R G I N G Your scooter uses two long-lasting, 12-volt deep-cycle batteries that are sealed and maintenance free. ■ Fully charge the batteries prior to using the scooter for the first time. ■... - Page 15 B A T T E R I E S A N D C H A R G I N G How can I get maximum range or distance per charge? ■ Always fully charge your scooter’s batteries prior to your daily use. ■...
- Page 16 B A T T E R I E S A N D C H A R G I N G Use these specifications to reorder deep-cycle batteries： Type： Deep-cycle (sealed lead-acid or gel cell) Voltage： 12-volts each Amperage： 75 AH Approx Size: 260mm x 170mm x 206mm To change a battery...
-
Page 17: Operation
88% of its peak performance level. 2. Operate your new scooter in familiar and safe areas. Drive slowly at first, and do not travel too far from your home or familiar surroundings until you have become accustomed to your scooter’s controls and have maximised the capacity of the batteries. - Page 18 2. Stand at the side of your scooter. 3. Pull forward the seat lock lever and rotate the seat until it is facing you. 4. Make certain that the seat is locked securely in position. 5. Position yourself comfortably and securely in the seat. 6.
-
Page 19: Comfort Adjustments
■ To slow down partially release the throttle control lever. ■ To stop fully release the throttle control lever. ■ The electric brake automatically engages when your scooter comes to a stop. NOTE: The rear wheel drive transaxle gives your scooter maximum traction with minimal steering effort GETTING OFF YOUR SCOOTER 1. - Page 20 Tiller Adjustment Lever Figure 9. Tiller Angle Adjustment SEAT HEIGHT ADJUSTMENT Seat Pedestal The seat can be repositioned to five different heights. See figure 10. 1. Remove the seat from your scooter. See section 9. “Disassembly and Assembly.” 2. Use the ring to pull and remove the ball Upper Seat post detent pin from the lower seat post.
-
Page 21: Basic Troubleshooting
SEAT LOCK LEVER The seat lock lever locks the seat in one of 5 positions. 1. Pull forward the seat lock lever to unlock the seat. 2. Rotate the seat to the desired lock position. Figure 11. Seat Adjustment and 3. - Page 22 ■ Check that the batteries are fully charged. See 5. “Batteries and charging.” ■ Push in the reset button to reset the main circuit breaker. See 4. “Your scooter.” ■ Make certain that both battery harnesses are firmly connected to the electronic controller module and to the battery terminals.
-
Page 23: Care And Maintenance
If the connections are good, charge the battery. High Battery Fault. The battery voltage is too high. This may occur if overcharged and/or travelling down a long slope. If travelling down a slope, reduce your speed to minimise the amount of regenerative charging. Check the battery charger. Current Limit or Controller Overheated. -
Page 24: Warranty
REMOVABLE FOOTMAT ■Your scooter’s foot-mat is held on with fasteners. It can be removed, cleaned, and reinstalled as necessary. EXTERIOR SURFACES ■Bumpers and trim also benefit from an occasional application of rubber or vinyl conditioner. ■Do not apply rubber or vinyl conditioner on the scooter’s vinyl seat or handlebars; they may become dangerously slippery! TERMINAL CONNECTIONS ■Make certain that the terminal connections remain tight and un-corroded. - Page 25 SERVICE CHECKS AND WARRANTY SERVICE An authorised dealer can perform warranty service. Please contact your authorised dealer for advice on the current cost of a service visit. Thank you for reading this manual. Now you can safely enjoy your increased mobility. 1 1 .
- Page 26 Date Purchased_________________________________________________________________________ Owners Name__________________________________________________________________________ Address_______________________________________________________________________________ City__________________________________________________ Post Code_____________________ Signature______________________________________________ Telephone_____________________ Dealer Name_____________________________________ Dealer Telephone_______________________ Comments____________________________________________________________________________ _____________________________________________________________________________________ Please Return to: One Rehab Ltd Unit 1 Fernwood Estate Shillinglee GU8 4SX...
