PRECISION DIGITAL ProtEX Series Instruction Manual

Explosion-proof modbus scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ProtEX PD8-6080/PD8-6081 Explosion-Proof
Modbus
• Modbus
®
RTU Master, Slave, or Snooper Mode
• Poll and Display up to 16 Process Variables
• Two (2) 0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V Inputs
• Math functions Capabilities
• Isolated 24 VDC @ 25 mA Transmitter Power Supply
• Multi-Pump Alternation Control
• Signal Input Conditioning for Flow & Round Horizontal Tank
• Programmable Displays & Function Keys
• 32-Point, Square Root, or Exponential Linearization
• Up to Three 4-20 mA Analog Outputs Available
• Modern, Sleek and Practical Enclosure
• Display Mountable at 0°, 90°, 180°, & 270° Degrees
• Explosion-Proof, IP68, NEMA 4X Enclosure
• SafeTouch
®
Through-Glass Button Programming
• Flanges for Wall or Pipe Mounting
• Superluminous Sunlight Readable Display
• Free USB Programming Software & Cable
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel (800) 343-1001 • Fax (508) 655-8990
®
Scanner Instruction Manual
Modbus Scanner
www.predig.com
