Marantz Icemaker Service Manual page 70

Pin
New Pin/Pad Name
N0.
83 IO .USBB_MCK_OUT
84 IO .M/SEL
85 IO .AUDIO_DSD/PCM
86 IO .CONT5.
87 IO CLK22.5792Mhz
.SLAVE_
88 IO
MCK_33.8688M
89 IO .OCXO_IN_22.5792M AK8142
90 IO AMUTE
91 IO NC
92 IO NC
93 GNDIO GND
94 VCCIO2 33_VCCIO
95 IO NC
96 IO NC
97 IO NC
98 IO NC
99 IO NC
100 IO NC
Connect Device Direction
"TMS320C6748BZWT3
/PCM9211"
N3305 7P FFC Connector
M3062LFGPGP
M3062LFGPGP
AK8142
AK8142
AUDIO UNIT
-
-
DGND
DA3.3V
-
-
-
-
-
-
70
OUT MCK for USB-DAC,DIR
OUT M/SEL for SYSCON Update
IN Audio Gain (SACD : Hi/Others : Lo) Detect
IN MCK (USB-A/Others) Detect
OUT AK8142 22.5792MHz
IN AK8142 MCK 33.8688MHz
OUT AK8142 22.5792MHz
IN DV3.2 AMUTE (L : MUTE/H : MUTE Off)
- NC
- NC
- Ground
- Power Supply
- NC
- NC
- NC
- NC
- NC
- NC
Detail
