CAREU WT1
Vehicle Tracker
User Guide
Version: 0.1
Reference No.:
Date: November 20, 2012
SYSTEMS & TECHNOLOGY CORP.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAREU WT1 and is the answer not in the manual?

Questions and answers

Related Manuals for Systems & Technology CAREU WT1

Summary of Contents for Systems & Technology CAREU WT1

  • Page 1 CAREU WT1 Vehicle Tracker User Guide Version: 0.1 Reference No.: Date: November 20, 2012 SYSTEMS & TECHNOLOGY CORP.
  • Page 2 General Information If any breakdown occurs due to the operation of the described product or users’ improper handling in accordance with the instructions of the document, S&T shall be liable for the General Conditions based on the delivery of the described product and the content of the document. This product is not designed for the use of life support appliances, devices or systems and thence a malfunction of the product might reasonably be expected to make personal injury.

  • Page 3: Table Of Contents

    1.2 Scope ....................... 6 1.3 About WT1 ..................…………….6 1.4 Hardware Architecture ..................7 1.5 Related Document ................... 8 Chapter 2 Taking a Tour of CAREU WT1 ..............2.1 Dimensions ...................... 9 2.2 Laterel View.....................10 2.3 Front View......................11 Chapter 3 Getting Started with CAREU WT1 ..............12...

  • Page 4: Chapter 1 Introduction

    Mobile Communication) and GIS (Geographic Information Systems) with each other. Designed with the latest GPS technology, the CAREU WT1 delivers positioning message by GSM wireless transmission to GIS platform, and then helps back-end users proceed with the analysis and the applications of vehicle transport, management, anti-theft, security and tracking.

  • Page 5: Scope

    CAREU WT1 Lite Vehicle Tracker User Guide Scope This document will guides you to start the CAREU WT1 Vehicle Tracker. However, as this document contains basic device configuration only, please see the CAREU WT1 Protocol Document for the advanced information.

  • Page 6: Hardware Architecture

    CAREU WT1 Vehicle Tracker User Hardware Architecture As hardware is concerned, the CAREU WT1 is comprised of a micro-controller, regulator, GPS receiver, GSM/GPRS modem, G-Force sensor, flash memory data storage, I/Os interface and LED status indicators. • Users can connect PC's HyperTerminal to the Diagnostic/setting port for the AVL configuration.

  • Page 7: Related Document

    CAREU WT1 Lite Vehicle Tracker User Guide Related Document [1] CAREU WT1 Protocol Document...

  • Page 8: Chapter 2 Taking A Tour Of Careu Wt1

    CAREU WT1 Vehicle Tracker User Chapter 2. Taking a Tour of CAREU WT1 This chapter will guide you to the major connectors of the WT1 device. Dimensions...

  • Page 9: Laterel View

    CAREU WT1 Lite Vehicle Tracker User Guide Lateral view Name Description Red Button SOS Function,User define Message & Action mode Blue Button Page LCD View change key,User define function.

  • Page 10: Front View

    CAREU WT1 Vehicle Tracker User Front View Name Description Micro USB USB for change battery & Function set. Reset Button Reset H/W Reset Key.

  • Page 11: Chapter 3 Getting Started With Careu Wt1

    The CAREU WT1 communicates with your host computer by either RS-232 or USB interface. In some newer editions of Windows XP, the CAREU WT1 device can be installed as a "virtual COM port" device whereby the CAREU WT1 would automatically access Windows XP's inbox USB drivers.
  • Page 12 CAREU WT1 Vehicle Tracker User 1. Automatic Installation If the wizard prompts to help you install the software for "STMicroelectronics Virtual COM Port". Select Install the software automatically (Recommended). Press the Next button to proceed. The wizard proceeds to install the driver.
  • Page 13 CAREU WT1 Lite Vehicle Tracker User Guide The installation completes. In [Device Manager], the CAREU WT1 device is included under Ports (COM & LPT) as "STMicroelectronics Virtual COM Port". COM port number is displayed as well.
  • Page 14 CAREU WT1 Vehicle Tracker User 2. Manual Installation After you select No, not this time, if the wizard only prompts to help you install software for "USB device", you need to manually install the driver. Select Install from a list or...
  • Page 15 CAREU WT1 Lite Vehicle Tracker User Guide Select Search for the best driver in these locations. Check Include this location in the search. Press the Browse button to assign where your the CAREU WT1 device driver locates on your local disk. Press the OK button.
  • Page 16 CAREU WT1 Vehicle Tracker User Press the Next button to proceed. The wizard proceeds to install the driver.
  • Page 17 CAREU WT1 Lite Vehicle Tracker User Guide The installation completes. In [Device Manager], the CAREU WT1 device is included under Ports (COM & LPT) as "S&T Tracker". COM port number is displayed as well.

  • Page 18: Device Configuration

    CAREU WT1 Vehicle Tracker User Device Configuration 1. In Windows XP desktop, click Start | All Programs | Accessories | Communications | HyperTerminal. 2. If you are prompted to input the information of your location, complete them to proceed. 3. On the File menu of HyperTerminal, click New Connection.
  • Page 19 CAREU WT1 Lite Vehicle Tracker User Guide 6. In the connection that you have just set up, click File | Properties. Select the [Connect To] tab. From the [Connect using] drop down list, select the correct com port by checking it up at Windows XP's [DeviceManager] as previously mentioned on page 21.
  • Page 20 CAREU WT1 Vehicle Tracker User 7. In the File menu, click Properties. Click the [Settings] tab. Press the ASCII Setup button. 8. In the [ASCII Sending] group box. Select both Send line ends with line feeds and Echo typed characters locally. Press the OK button.
  • Page 21 CAREU WT1 Lite Vehicle Tracker User Guide 9. Connect your the CAREU WT1 device to power as mentioned in Power and I/O Cable Connection on page The device startup message will be displayed. 10. In [HyperTerminal] window, type in the command "AT$VERSION?" and press the Enter key.

  • Page 22: Communication Settings

    CAREU WT1 Vehicle Tracker User Communication Settings The CAREU WT1 Vehicle Tracker communicates with your control center by either SMS or GPRS (TCP/UDP). Before the device is installed into a vehicle, communication parameters should be set. SMS Configuration Use AT$SMSDST command to set a SMS control center phone number or short code.
  • Page 23 AT$APN=internet,username,password (APN=internet, Username=username, Password=password) OK AT$HOSTS=1,0,60.148.19.10,6000 (Server IP address = 60.148.19.10 and Port number =6000) AT$RETRY=5,10 (Message retry settings) AT$IPTYPE=1 (Using TCP/IP mode) AT$GPRSEN=1 (GPRS enable) AT$HB=60,1 (Heartbeat setting) Please refer to the CAREU WT1 Protocol Document for more command details.

  • Page 24: Gps Tracking Configurations

    CAREU WT1 Vehicle Tracker User GPS Tracking Configurations After the device communication settings are done, the remote GPS tracking is ready to function. The setting of GPS tracking can be done by using AT$PDSR command. For example, AT$PDSR=1,30,0,0,2,0,0,1,1 (Tracking through GPRS by time interval 30 seconds) For simple testing GPRS, run the TCP Server U-Series software which is provided by S&T.
  • Page 25 CAREU WT1 Lite Vehicle Tracker User Guide For advanced testing, you need the software Intelli TracerPlus. Please request this software through your sales contact. You can also apply for a testing account from S&T's FleetWeb solution through your sales contact.
  • Page 26 CAREU WT1 Vehicle Tracker User The main page of the Intelli FleetWeb appears as below:...

  • Page 27: Firmware Upgrade

    Guide Firmware Upgrade The firmware of the CAREU WT1 can only be updated through USB interface. With the firmware loader tool provided by S&T, firmware update can be done for the device. Such firmware loader runs on Windows-based systems. To upgrade the firmware, follow the procedure below: Connect the device to your PC with the USB cable.

  • Page 28: Chapter 4 Technical Specification

    CAREU WT1 Lite Vehicle Tracker User Guide Chapter 4. Technical Specification Characteristics Dimensions (L x W x H) 108 x 72 x 31mm Weight 165g Radio Performance Frequency Quad-band 850/900/1800/1900MHz GSM Functionality / GPRS GPRS Mode Multi-slot class 10 GPRS Coding Scheme CS1,CS2,CS3 and CS4...
  • Page 29 CAREU WT1 Vehicle Tracker User Interface I/O Button Key Emergency Button Controls Function Button Electrical Power Source 500mA @ +5V Environment Operating Temperature –20 ° C to +60 ° C Battery 3.7V / 550mAH Rechargeable Backup Battery Note: The specification herein is subject to change without prior notice.
  • Page 30 CAREU WT1 Lite Vehicle Tracker User Guide Systems & Technology Corp. (S&T), founded in 1987, is a market leader in Automatic Vehicle Locating (AVL) solutions, Geographical Information Systems (GIS) and navigation. It has formed a professional development team to innovate the most advanced and comprehensive GPS tracking products for the customers and has built a global service network to provide non-stop services and support.

  • Page 31: Chapter 5 Regulation

    CAREU WT1 Vehicle Tracker User Chapter 5. Regulation Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 32 CAREU WT1 Lite Vehicle Tracker User Guide Česky [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se [Czech] základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Dansk Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr [Danish] [udstyrets typebetegnelse] overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 33 CAREU WT1 Vehicle Tracker User fid-Dirrettiva 1999/5/EC. Magyar Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó [Hungarian] alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Polski Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z [Polish] zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami...
  • Page 34 CAREU WT1 Lite Vehicle Tracker User Guide DoC 法規版本 法規版本 法規版本 法規版本 Declaration of Conformity Chapter 4...
