Page 1: Installation Manual
Container shelter / Containerüberdachung / Containeroverkapping Kroftman TC606 (6,00 x 6,05 m) Installation manual Montageanleitung Installatiehandleiding V02.02KR 171201... - Page 2 Teileliste Rahmen+Plane Parts list frame+cover Onderdelenlijst frame+zeildoek TC606 Teil: Zahl: Umschreibung: Länge: Part: Qty.: Description: Length: Dachrohr oben / top roof tube / nok buis 48x1.8 Dachrohr mitte / middle roof tube / buis midden 48x1.8 1935 Dachrohr unten / lower roof tube / buis onder 48x1.8...
- Page 3 590cm 590cm Schnitt / SECTION / doorsnede A-A SCALE 1:100 DIN125A_M8 DIN985_M8 TCA0008 DIN933_M8X70 Detail B (1:8) DIN125A_M8 DIN985_M8 DIN603_M8X60 DIN933_M8X70 TCA0008 DIN985_M8 DIN125A_M8 Detail A (1:8)
- Page 4 DIN603_M8X60 DIN125A_M8 DIN985_M8 detail C (1:8) DIN603_M8X70 DIN985_M8 Detail D DIN125A_M8 (1:8)
- Page 5 Detail K (1:8) Siehe Blatt 7 see sheet 7 zie blad 7 Detail V (3:50)
- Page 6 Teileliste Vorderwand (Optionel) Parts List front wall (optional) Onderdelenlijst voorwand (optie) TC606 Teil: Zahl: Umschreibung: Länge: Part: Qty.: Description: Length: Rohr unteren Teil / lower tube/ onderste buis 48x1.8 2223 Rohr oberen Teil / top tube/ bovenste buis 48x1.8 1622 Rohr / tube/ buis 48x1.8...
- Page 7 DIN985_M10 DIN603_M8X60 DIN933_M8X30 DIN125A_M10 DIN603_M8X60 DIN125A_M10 DIN985_M8 DIN125A_M8 DIN985_M10 DIN125A_M8 DIN603_M10X70 DIN125A_M10 DIN985_M8 DIN603_M10X70 Detail F(1:8) DIN985_M8 Detail G(1:8) Detail E (1:8) Detail H(1:8)
- Page 8 Detail J(1:8) Detail I(1:8) Vorderseite gleich Hinterseite Front side equal back side Voorzijde is gelijk aan achterzijde Band festschnallen an 7 secure strap to 7 spanband vastzetten aan 7 SCALE 1:100 Detail L (1:8)
